DSR4

Four Channel Digital Slot Receiver

DSR4-A1B1, DSR4-B1C1, DSR4-941, DSR4-961

INSTRUCTION MANUAL

Rio Rancho, NM, USA

www.lectrosonics.com

Fill in for your records:

Serial Number:

Purchase Date:

• Four independent channels, compact

design

• Two diversity options for maximum

exibility

• 24 bit/48 kHz digital for awless audio

• AES 256-bit, CTR mode encryption, with

4 dierent key policies available

• High IP3 performance of +15 dBm for

tough RF environments

• Analog and AES3 digital audio outputs

• External DC powering options and USB

input for rmware updates and data

transfer

scan for our DSR4

Deep Dive product videos

DSR4

LECTROSONICS, INC.

FCC Notice

NOTE: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined

by turning the equipment o and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modications to this equipment not expressly approved by

Lectrosonics, Inc. could void the user’s authority to operate it.

Installation & Operating Instructions

The following checklist includes the minimum required settings to start using the receiver:

• Install either a battery sled, camera slot adapter or other power source via EXT BOTTOM PLATE.

• Connect power to the receiver.

• Set the COMPAT (compatibility) mode for the transmitters to be used.

• Find clear operating frequencies for one or both receivers using SmartTune or manual scanning.

• Set transmitters on the matching frequencies, manually or by using IR sync.

• Verify transmitters are set to the same compatibility mode as the receiver (see transmitter manual).

• Adjust transmitter input gain to match voice level and mic position (see transmitter manual).

• Adjust receiver output level as needed for the camera or mixer input level desired.
