Side 1/32

Full HD LED touchscreen monitor

QUICK SETUP GUIDE

PROFESSIONAL e-Screen 65" ETD

E N G L I S H

D E U T S C H

F R A N Ç A I S

NEDERLANDS

T ü R k Ç E

For further information, see the User

Manual that is downloadable from the

e-legamaster.com website. Please retain

this Quick setup guide for future reference.

Please contact Legamaster directly if you

have questions on the use of the touch

monitor after reading the Setup Guide

and User Manual.

Important:

Please read the PRECAUTIONS, SAFETY

INSTRUCTIONS and this SETUP GUIDE

carefully before installing the touch

monitor.

Before using the touch monitor, please read this quick setup

guide thoroughly to help protect against damage to your own

and other people's property and ensure your own and other

people's personal safety.

Be sure to observe the following instructions.

For your safety, be sure to observe the warnings contained

in this guide.

For installation or adjustment, please follow this quick setup

guide and refer all servicing to qualiﬁed service personnel.

Safety Precautions

If smoke or a peculiar smell comes from the monitor, remove the

power plug from the socket immediately.

Failure to do so may result in ﬁre or electric shock.

Contact your dealer for inspection.

If the monitor has been turned on but there isn’t a picture,

remove the power plug from the socket immediately.

Failure to do so may result in ﬁre or electric shock.

Contact your dealer for inspection.

If water is spilled or objects are dropped inside the monitor,

remove the power plug from the socket immediately.

Failure to do so may result in ﬁre or electric shock.

Contact your dealer for inspection.

If the monitor is dropped or the cabinet is damaged, remove the

power plug from the socket immediately.

Failure to do so may result in ﬁre or electric shock.

Contact your dealer for inspection.

To turn off the power of the monitor, press ” ” on the main

power switch at side of monitor.

The power standby/on indicator will go off and the monitor

cannot to be turned on/off by using the POWER button on the

remote control. (To turn on/off the monitor by the remote control,

press the main power switch again and the power standby/on

indicator light will come on again.)

When turning off the monitor by pressing the POWER button

on the remote control, the main power of the monitor is not

turned off completely.

To disconnect the monitor completely from the power supply,

remove the plug from the socket.

Press “ ” to turn off

the monitor completely

If the power cord or plug is damaged or becomes hot, turn off the

main power switch of the monitor, make sure the plug has cooled

down and remove the plug from the socket.

If the monitor is still used in this condition, it may cause a ﬁre or

an electric shock. Contact your dealer for replacement.

Moving and Carrying Notice

Moving Notice:

Moving the monitor requires at least two people. If not, it may drop and a serious

injury may result. When moving/shipping the monitor, please hold the white handles.

Carrying Notice:

This monitor is heavy; please follow the instructions below when you are ready to

carry the monitor. Failure to do so may cause injury.

Installation

(when installing the monitor, please follow the instructions in this

quick setup guide)

Don't install in a high-temperature environment.

If the monitor is used in a high-temperature environment or in

direct sunlight, it may cause the case or other parts to become

distorted or damaged resulting in overheating or electric shock.

Don't install in a high-humidity environment.

This may cause overheating or electric shock.

Don't install near any heat sources such as radiators, hot-air

outlets, stoves, or other apparatus that produce heat.

This may cause a ﬁre or electric shock.

Don't overload sockets or cables beyond electrical capacity.

Don't use extension leads as this may cause a ﬁre or electric shock.

Don't insert the power plug into an socket other than 100~240V AC.

This may cause a ﬁre or electric shock.

Don’t use a damaged power plug or worn socket.

Don't insert the wrong plug as it may cause a ﬁre or electric

shock.

QUICK SETUP GUIDE

1 Precautions and safety instructions

Produkt Specifikationer

Mærke:	Legamaster
Kategori:	overvåge
Model:	7-194116
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Produktfarve:	Sort
Skærm diagonal:	65 "
Skærmopløsning:	1920 x 1080 pixel
Berøringsskærm:	Ja
HD-type:	Fuld HD
Skærmteknologi:	LED
Skærmens lysstyrke:	360 cd/m²
Responstid:	5.5 ms
Synsvinkel, horisontal:	178 °
Synsvinkel, vertikal:	178 °
Skærm form:	Flad
Skærm diagonal (metrisk):	165.1 cm
3D:	Ingen
Indbyggede højttaler(e):	Ja
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	0 - 85 %
Relativ luftfugtighed ved opbevaring (H-H):	0 - 85 %
Antal højttalere:	2
Udgangseffekt (RMS):	20 W
Antal HDMI-porte:	2
DVI-port:	Ja
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	1
Komponentvideo (YPbPr/YCbCr) indgang:	1
Skærmvisning (OSD):	Ja
Panel montering grænseflade:	400 x 400,600 x 400 mm
Strømforbrug (standby):	1 W
Strømforbrug (typisk):	226 W
Bredde (uden stativ):	1539.8 mm
Dybde (uden stativ):	113 mm
Højde (uden stativ):	909.8 mm
Vægt (uden stativ):	70000 g
Driftstemperatur (T-T):	0 - 35 °C
Strømforsyningstype:	Vekselstrøm
Dimensioner (BxDxH):	1539.8 x 113 x 909.8 mm
Fjernbetjening inkluderet:	Ja
Kan monteres på væggen:	Ja
Full HD:	Ja
HDMI:	Ja
Billede-i-billede:	Ja
LED-baggrundsbelysning:	Ja
Kompatible operativsystemer:	Windows XP/Vista/7\r\nMac OS X \r\nLinux
Billedformat:	16:9
Vis antal farver:	1.073 milliarder farver
Plug and play:	Ja
Grænsefladetype:	USB
AV-indgang:	Ja
Kontrastforhold (typisk):	4000:1
Horisontal scanningsområde:	23 - 92 kHz
AMD FreeSync:	Ingen
NVIDIA G-SYNC:	Ingen
Antal DisplayPorts:	1
Antal VGA-porte (D-sub):	1
Berøringsskærmstype:	Bordplade
Antal produkter inkluderet:	1 stk
Vertikalt scanningsområde:	49 - 86 Hz
RS-232-porte:	1
Antal af S-video-indgange:	1
Digital vertikal frekvens:	23 - 85 Hz
Lydudgang:	1
Digital horisontal frekvens:	15 - 94 kHz
Antal DVI-D-porte:	1
