LevelOne FSW-0808TX Manual

LevelOne Skifte FSW-0808TX

Læs gratis den danske manual til LevelOne FSW-0808TX (4 sider) i kategorien Skifte. Denne vejledning er vurderet som hjælpsom af 34 personer og har en gennemsnitlig bedømmelse på 5.0 stjerner ud af 17.5 anmeldelser. Har du et spørgsmål om LevelOne FSW-0808TX, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/4

7/30/24

FSW-0808TX 8-Port Fast

Ethernet Switch

Product Images

Short Description

Provides exibility of 8 x 10/100BASE-TX ports

7/30/24

10/100Mbps, full/half-duplex, auto-negotiation, auto-MDI/MDIX

Supports 1K MAC address auto-learning and auto-aging

IEEE 802.3x Flow Control protects against lost packets for reliable data transmission

Magnetic base for easy placement

Quick and easy installation

Description

The LevelOne FSW-0808 is a wire-speed, non-blocking networking device that provides 8

ports 10/100Mbps Ethernet connections. All ports support auto-negotiation and auto-

MDI/MDIX sensing, eliminating the need for crossover cables or Uplink Ports. Each port

can be used as general network port or as connecting port into a router, server, hub or

another network switch.Easy Conguration and MaintenanceThe LevelOne FSW-0808TX

does not require software conguration. Users can immediately use any features of this

product simply by attaching the cables and turning on the power. For instant error

detection, the switch is equipped with a full range of LEDs to help you monitor and

troubleshoot problems on your network.Compact Size DesignThis switch is compact

specially designed to t on the desktop or in other space-limited locations. The

FSW-0808TX provides an ideal solution for businesses that crave a reliable network to

exchange large data les and multimedia information with bandwidth-starving

workgroup, departments, and oces.

Produkt Specifikationer

Mærke:	LevelOne
Kategori:	Skifte
Model:	FSW-0808TX
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	125 mm
Dybde:	69 mm
Højde:	30 mm
Produktfarve:	Grå
Pakkevægt:	300 g
Pakkedybde:	130 mm
Pakkebredde:	75 mm
Pakkehøjde:	90 mm
Opbevaringstemperatur (T-T):	-40 - 70 °C
Relativ luftfugtighed ved drift (H-H):	5 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	10 - 90 %
Strømforbrug (typisk):	2.8 W
Driftstemperatur (T-T):	0 - 40 °C
Hurtig start guide:	Ja
Certificering:	FCC, CE, RoHS
Netværksstandarder:	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
LED-indikatorer:	Activity, Link, Power
Udgangsspænding:	5 V
Udgangsstrøm:	1 A
AC-adapter inkluderet:	Ja
Harmoniseret systemkode (HS):	85176990
Oprindelsesland:	Kina
Fuld duplex:	Ja
Strøm over Ethernet (PoE):	Ingen
Switch-type:	Ikke administreret
10G understøttelse:	Ingen
Auto MDI/MDI-X:	Ja
Flowkontrol support:	Ja
Kobber ethernet kabelteknologi:	10BASE-T, 100BASE-TX
Basis omskiftning RJ-45 Ethernet porte, antal:	8
Basis omskiftning RJ-45 Ethernet porttype:	Fast Ethernet (10/100)
Opbevar-og-frem:	Ja
MAC adresselabel:	1024 entries
Switch kapacitet:	1.6 Gbit/sek.
Stativ-montering:	Ingen
Bufferstørrelse:	96 KB
Strømstik:	DC-in-stik
Stabelbar:	Ingen
Auto-forhandling:	Ja
Pakke videresendelsesrate (100 Mbps):	148000 pps
Pakke videresendelsesrate (10 Mbps):	14880 pps
