Side 1/25
For Enquiries, Please Call 7038-100-400 or write to customercare.lhi@liebherr.com
@
7754385 - 00
.
TC..24..27..TD..31..42..

TC..24..27..TD..31..42..
The appliance is suitable solely for cooling
food in a domestic environment or similar.
Use the appliance solely as is customary
within a domestic environment. All other
types of use are not permitted & make cause
warranty to be void (refer warranty T & C's for
more details). The appliance is not suitable
for storing and cooling medicines, blood
plasma, laboratory preparations or similar
substances and products. Misuse of the
appliance can deteriorate or spoil the stored
food items. Furthermore, the appliance is not
suitable for operation in potentially explosive
atmospheres.
The appliance is set to operate within specific
ambient temperature limits according to its
climate rating. Refer below table and
information regarding various climate rating
and relevant rating for your product.
1.2 Range of appliance use
Note
uRefrigerator should be used within the
indicated ambient temperature range
otherwise the cooling performance is
reduced.
Climate
rating
for ambient temperatures of
SN
N
ST
T
0 0
10C to 32C
0 0
16C to 32C
0 0
16C to 38C
0 0
16C to 43C
1.3 External dimensions of
the appliance
Always ensure good ventilation.
- Do not place appliance in areas of direct
sunlight or next to a stove, heater or similar
object.
1.4 Saving energy
2
SN-T
For climate rating, net weight, refrigerant quantity
and electrical rating of your refrigerator model,
please refer circuit diagram sticker on the backside
of the refrigerator.
0 0
10C to 43C
Note
uAbove mentioned dimensions are
measured from extreme surfaces of product
as shown in below image and are subjected
to change as per variant.
Model Dimensions
W D H
595/597
706
676/716
782
1495
1595
TC..24..-...
TC..27..-...
1850
Note : Product images in this manual are for representation purpose only.
TD..31..-...
1850
TD..42..-...
W
H
D
TC..24..-...
TC..27..-...
TD..31..-...
TD..42..-...
- The energy consumption depends on the
installation conditions, e.g. the ambient
temperature.
- Limit the frequency and time of door
opening to minimum for better energy
efficiency.
- Ensure that all food is well packed and
covered for storage. This will prevent frost
formation.
- Empty and switch off refrigerating unit for
longer vacation periods.
2 General Safety Information
This appliance is not designed for persons
(including children) with physical or mental
impairment or persons not having sufficient
experience and knowledge, unless they are
instructed in the use of the appliance and are
initially supervised by a person responsible
for their safety. Keep children under
supervision to ensure they do not play with
the appliance.
- When disconnecting the appliance, make
sure that electric supply is turned off. Always
take hold of the plug while pulling plug out of
the socket. Do not pull the cable.
- In the event of a fault, turn off the power
supply.
Danger for the user:
595/597
595/597
676/716
676/716
The appliance is designed for use in
enclosed areas. Do not operate the
appliance outdoors or in areas where it is
exposed to water or damp conditions.
u
Risk of fire due to short circuit!
If the mains cable/connector of the appliance
or of another appliance touch the rear of the
appliance, the mains cable/connector may
be damaged by the appliance vibrations,
leading to a short circuit.
Stand the appliance so that it is not
touched by connectors or main cables.
Do not plug the appliance plug or any
others plugs into sockets located near the
rear of the appliance.
u
u
WARNING
Fire hazard due to refrigerant!
The refrigerant R600a is environmentally
friendly but flammable. Leaking refrigerant
may ignite.
Do not damage the piping of the
refrigeration circuit.
u
WARNING
Fire hazard and danger of damage!
Do not place appliances emitting heat
e.g. microwaves, toasters etc. near the
appliance.
u
WARNING
Blocked ventilation openings pose a risk of
fire and damage!
Always keep the ventilation openings
clear. Always ensure that the appliance is
properly ventilated!
u
WARNING
Risk of damage due to condensate!
Do not install the appliance directly
alongside a further refrigerator/freezer.
u
NOTICE
4
=In the event that the appliance damaged,
contact service immediately. Do not connect
power plug to the mains.
=The floor at which refrigerator is to be kept
must be flat & in level.
=Do not install the appliance in a location
where it is exposed to direct radiation of the
sun, next to a cooker, heater, microwave
oven and similar appliances.
=Always stand the appliance with its back
directly to the wall.
=The appliance must be moved only when
it is empty & switched off.
=Do not install the appliance without
assistance.
=Standard EN 378 specifies that the room
in which you install your appliance must have
3
a volume of 1m per 8g of R 600a refrigerant
used in the appliance, if the room in which the
appliance is installed is too small, a
flammable gas-air mixture may form in the
event of a leakage in the refrigeration circuit.
The quantity of refrigerant used in your
appliance is indicated on the circuit diagram
sticker at the backside of the appliance.
3.3 Disposing of Packaging
WARNING
Danger of suffocation due to packing material
and plastic film !
Do not allow children to play with packing
material.
u
The packaging is made of following
recyclable materials :
- corrugated board/cardboard
- expanded polystyrene parts
- polythene bags and sheets
- polypropylene straps
Note : Product images in this manual are for representation purpose only.
The Refrigerator doors are provided with a
high-quality surface coating and must be
cleaned using non corrosive cleaning agent.
Do not wipe the door with too much pressure
as it may lead to scratches / damages.
uWipe the coated door surfaces using a
soft, clean micro fiber cloth only.
uApply a stainless steel cleaner to the
stainless steel side surface evenly, wiping
with the grain. As a result cleaning becomes
easier.
NOTICE
u
u
u
Wipe side walls with a paint finish using a
soft, clean cloth only.
Remove all transit supports.
Align the appliance so that it stands
firmly and on a level by adjusting the legs
given at the bottom of refrigerator.
Important for the ventilation:
- At the back of the stack cabinet there has
to be a ventilation area of at least 120mm
depth throughout the width of the stack
cabinet from its extreme back surface.
- There has to be at least 300mm gap from
Both sides of Refrigerator surface and side
wall.
- The ventilation gap over the top has to be
at least 300mm.
3.5 Connecting the appliance
Risk of damage to the electronic control
system!
uWe do not suggest use of stand-alone
inverters (conversion of DC to AC/ three-
phase) or energy saving plugs.
NOTICE
WARNING
Fire and overheating hazard!
Do not use extension cables or multiple
socket outlets.
u
The recommended type of current (alternating
current) and voltage for the refrigerator must
confirm with the data on the circuit diagram.
The power socket where refrigerator is
plugged in must be provided with proper
earth connection and suitable safety
provisions such as Fuse / MCB.
It must be easily accessible so that the
appliance can be quickly disconnected from
the supply in an emergency.
uCheck the electrical connection.
uPlug in the power plug.
5
If the appliance is installed in a very damp
environment, condensation may form on the
outside of the appliance.
Always see to good ventilation near the
refrigerator.
u
- The larger the ventilation space, the
more energy-saving the appliance is in
operation.
Align appliance so that it stands firmly and in
level by rotating adjustable leveling legs
provided at the front bottom corners of the
refrigerator (see appliance at a glance) in
clockwise and counter clockwise direction as
shown below.
3.4 Appliance Leveling & Leg
adjustment
Rotated in clockwise
& counter clockwise
direction
Note : Product images in this manual are for representation purpose only.
300mm
120mm
300mm
4 Temperature Setting &
Control
4.1 Food refrigeration
The energy consumption increases and the
cooling performance decreases if the
ventilation is inadequate.
Always keep the air duct openings free.u
NOTE
uDo not store food too close to each other
or near to the duct opening to enable good air
circulation.
uTo safeguard bottles from tipping over :
adjust the bottle separator.
4.2 Freezer compartment
You can store frozen food, make ice
cubes and freeze fresh food in the freezer
compartment.
The product sticker indicates the freezing
capacity of refrigerator under “Freezing
capacity ... kg/24h".
4.3.1 Setting the temperature
The temperature depends on the following
factors:
-the door opening frequency
-the room temperature at the site where the
appliance is installed
