Thanks for your choosing our product, please carefully read this manual and operate it obey the specicaon in order to make
sure you can correct and safety installing, operang and maintaining it.
Power Input DC 9-12V 500ma Min
DMX In/Out 3 Pin female/male XLR socket X 1
Midi In5 Pin mulple socket
12 Scanners of 16channels each
23 Banks of 8 programmable scenes
6 Programmable chases of 184 scenes
8 Sliders for manual control of channels
Auto mode program controlled by speed and fade me sliders
Reversible DMX channels allows xture to react opposite to others in a chase
Manual override allows you to grab any xture on the y
Built in microphone for music triggering
Midi control over banks, chases and blackout
Master Packing Size: 570 *360 * 570mm(10pcs)
Net Weight: 2.3KG, Gross Weight: 2.6KG
1. To prevent or reduce the risk of electrical shock or re, do not expose this unit to rain or moisture
2. Clearing memory repeatedly may cause damage to the memory chip be careful not to inialize your units frequency
1. Enable the program mode
2. Select the chase that contains the step you wish to delete
3. Press the “Bank Up/Down” buon and scroll to the step you wish to delete
4. Press the “Auto/Del” buon to delete the step.
1. Press the buon corresponding to the chase you wish to delete
2. Press and hold down the “Auto/Del” buon while holding down the chase buon.
There are three modes in which to run scenes and chases. They are manual mode, auto mode and music mode.
1. When the power is turned on, the unit enters manual mode automacally.
2. Select the chase you wish to run by pressing the corresponding chase buon pressing this buon second me
1. Press the “Auto/Del” buon to acvate Auto Mode
2. Select the desired chase by pressing one of six chase buons. Press this buon a second me will negate this selecon
3. Use the “Speed” and “Fade” me sliders to adjust the chase to your specicaons.Music Mode
Press the scene buons to load or store your scenes. There are a maximum of programmable scenes. 184
These faders are used to control the intensity of channels 1-8 and 9-16 on page B
