Losi Tenacity Manual

Losi Radiostyret legetøj Tenacity

Læs gratis den danske manual til Losi Tenacity (16 sider) i kategorien Radiostyret legetøj. Denne vejledning er vurderet som hjælpsom af 34 personer og har en gennemsnitlig bedømmelse på 4.7 stjerner ud af 17.5 anmeldelser. Har du et spørgsmål om Losi Tenacity, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/16

Before operating this vehicle, please read all printed materials thoroughly.

Horizon Hobby is not responsible for inadvertent errors in this manual.

INSTRUCTION MANUAL

BEDIENUNGSANLEITUNG

MANUEL D’UTILISATION

MANUALE DI ISTRUZIONI

TENACITY SCT RTR, AVC: 1:10 4WD SCT • INSTRUCTION MANUAL

Age Recommendation: Not for children under 14 years. This is not a toy.

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product correctly can result in dam-

age to the product, personal property and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate this Product in a safe and

responsible manner could result in injury or damage to the product or other property. This product is not intended for use by children without direct adult supervision. Do not use with

incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for safety, operation and mainte-

nance. It is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.

WARNING AGAINST COUNTERFEIT PRODUCTS Always purchase from a Horizon Hobby, LLC authorized dealer to ensure authentic high-quality Spektrum product. Horizon

Hobby, LLC disclaims all support and warranty with regards, but not limited to, compatibility and performance of counterfeit products

or products claiming compatibility with DSM or Spektrum.

NOTICE

All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC.

For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product.

MEANING OF SPECIAL LANGUAGE

The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:

NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury.

CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury.

WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high probability of superﬁ cial injury.

updates and more. Click on the Support tab at WWW.LOSI.COM and follow the product

registration link to stay connected.

As the user of this product, you are solely responsible for operating in a manner that does not

endanger yourself and others or result in damage to the product or property of others.

This model is controlled by a radio signal subject to interference from many sources outside

your control. This interference can cause momentary loss of control, so it is advisable to

always keep a safe distance in all directions around your model as this margin will help avoid

collisions or injury.

• Never operate your model with low transmitter batteries.

• Always operate your model in open spaces away from full-size vehicles, traffic and people.

• Never operate the model in the street or in populated areas for any reason.

• Carefully follow the directions and warnings for this and any optional support equipment

(chargers, rechargeable battery packs, etc.) you use.

• Keep all chemicals, small parts and anything electrical out of the reach of children.

• Never lick or place any portion of the model in your mouth as it could cause serious injury

or even death.

• Exercise caution when using tools and sharp instruments.

• Take care during maintenance as some parts may have sharp edges.

• Immediately after using your model, do NOT touch equipment such as the motor, electronic

speed control and battery, because they generate high temperatures. You may burn yourself

seriously touching them.

• Do not put ﬁ ngers or any objects inside rotating and moving parts, as this may cause

damage or serious injury.

• Always turn on your transmitter before you turn on the receiver in the car. Always turn off the

receiver before turning your transmitter off.

• Keep the wheels of the model off the ground when checking the operation of the radio

equipment.

SAFETY PRECAUTIONS AND WARNINGS

TABLE OF CONTENTS

BOX CONTENTS ........................................................................................................3

COMPONENTS ..................................................................................................................3

WATER-RESISTANT VEHICLE WITH WATERPROOF ELECTRONICS ..............................3

GENERAL PRECAUTIONS ...................................................................................................3

WET CONDITIONS MAINTENANCE ....................................................................................3

QUICK START ............................................................................................................3

CHARGING THE BATTERY .........................................................................................3

INSTALLING THE BATTERY ........................................................................................4

SPEKTRUM DX2E ACTIVE RADIO SYSTEM ................................................................4

INSTALLING THE TRANSMITTER BATTERIES ........................................................................4

SRS6000 AVC TECHNOLOGY RECEIVER ....................................................................4

AUX CHANNELS ................................................................................................................4

BINDING AND CALIBRATING THE RECEIVER .....................................................................5

DISABLING THE STABILITY ASSIST FUNCTION ....................................................................5

DRIVING PRECAUTIONS ..........................................................................................5

POWERING ON THE VEHICLE ....................................................................................5

BEFORE RUNNING YOUR VEHICLE ............................................................................5

AVC

SENSITIVITY ....................................................................................................5

RUN TIME .................................................................................................................6

TO IMPROVE RUN TIMES ...................................................................................................6

PERFORMING A CONTROL DIRECTION TEST.............................................................6

CHANGING THE TRAVEL ADJUST SETTINGS .............................................................6

DYNAMITE® FUZE™ 130A SENSORLESS BRUSHLESS ESC (DYN4955) ....................6

SPECIFICATIONS ...............................................................................................................6

ESC LED STATUS ...............................................................................................................6

AUDIBLE WARNING TONES ...............................................................................................6

ESC CALIBRATION PROCEDURE ........................................................................................6

ESC FUNCTIONS AND MODES ...........................................................................................7

ESC PROGRAMMING PROCEDURE ....................................................................................7

DESCRIPTIONS ..................................................................................................................7

DYNAMITE® FUZE™ 3800KV BRUSHLESS MOTOR (DYNS1616) ..............................8

PRECAUTIONS ..................................................................................................................8

GEARING .........................................................................................................................8

CHANGING THE PINION GEAR/GEAR RATIO ......................................................................8

SETTING THE GEAR MESH .................................................................................................8

TROUBLESHOOTING GUIDE ......................................................................................8

LIMITED WARRANTY ...............................................................................................8

WARRANTY AND SERVICE CONTACT INFORMATION ................................................9

FCC STATEMENT .......................................................................................................9

IC INFORMATION .....................................................................................................9

COMPLIANCE INFORMATION FOR THE EUROPEAN UNION ......................................9

REPLACEMENT PARTS ............................................................................................34

OPTIONAL PARTS ...................................................................................................35

EXPLODED VIEW ....................................................................................................36
