Table of Contents and Warnings 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Part List 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Assembly and Installation
Adjust upper and lower poles 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Attaching to the base assembly 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Install steel cross rods 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Height adjustment 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Media shelf assembly 7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Assemble at panel mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9
Install mount to the frame 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Install camera mount 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cable and wire installation 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VESA mounting patterns 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Severe personal injury and property damage can result from improper installation. Read
instructions carefully before beginning.
• If you do not understand the instructions or have any concerns please contact a
qualied local installer.
• Do not install or assemble if the product or hardware is damaged or missing, if you
require replacement parts contact your local dealer.
• This product ts most 40˝- 60˝ at panel displays; maximum weight for the display
• Do not use this product for anything other than what it was originally designed.
• This product contains moving parts, please use caution.
• The manufacturer disclaims any liability for the modications, improper installation
and installation exceeding maximum weight capacity. The manufacturer will not be
liable for any damages arising out of the use of, or inability to use the product.
