Side 1/8

READ ME FIRST

Fo ld Fo ld Fo ld

QUICK INSTALL GUIDE

High Power Wireless 300N

Outdoor Access Point

XAP-1240

Includes:



One: XAP-1240 Wireless Access Point



One: PoE Injector and Power Cord



One: Ethernet Cable



Two: Cable Ties

READ ME FIRST - AP COMPATIBILITY

This XAP-1240 is compatible with the Luxul XWC-1000 Wireless Controller for

fast, easy conﬁguration and deployment of wireless networks with multiple APs.

n Note: If you’ll be using this AP with a Wireless Controller, refer to

the Quick Install Guide included with the Wireless Controller for

setup instructions.

If you’re using separately-purchased Luxul APs or installing this AP along

with a Wireless Controller in an existing Luxul deployment, you may

need to manually upgrade ﬁrmware for some of those APs before installing

the Wireless Controller.

Luxul APs running ﬁrmware version 5 or later (like the one in

this package) are Wireless Controller-compatible and can

be used with the Controller as-is. When purchasing Luxul

APs for use with the Wireless Controller, look for an orange

“Version 5 Firmware” sticker on the box to avoid the manual

upgrade process.

n Note: Visit http://luxul.com/ap-upgrade for help upgrading your AP’s

ﬁrmware to version 5 or newer.

AP SETUP AND CONFIGURATION

Physical Installation

The XAP-1240 access point is designed for simple and efﬁcient installation.

Four keyholes allow for easy wall-mounting, or for mounting to a pole, use the

included cable ties (zip ties) to secure the AP to the pole. Loosely secure two

cable ties, one through each mounting ﬂange slot, then tighten the cable ties.

Single Access Point Placement: Because the signal generated by the

XAP-1240 is directional, the unit should be located at the perimeter

of the desired coverage area, with the large ﬂat surface aimed toward

the center.

XAP-1240 Single AP Coverage Pattern

Multiple Access Point Placement: You may need to experiment with

AP placement to optimize the roaming experience. Place APs to ensure

adequate coverage, but not so far apart that there is no signal overlap.

Adjacent APs should overlap enough that the client device has a good

connection to the AP to which it is currently attached, but also sees the

next-nearest AP. Ideally, roaming clients should see signal strength of

two overlapping APs in the range of -60 to -70 dBm at the midway

point between two APs. To learn more about AP placement, visit

luxul.com/ap-placement.

Ideally, roaming clients should see

signal strength of two overlapping

APs in the range of -60 to -70 dBm at

the midway point between two APs

XAP-1240 Multiple AP Coverage and Overlap

n Note: Consider using Ekahau HeatMapper to assist with this process,

available from www.ekahau.com. Luxul also offers an informative

“How-To” video on HeatMapper at luxul.com/how-to-videos.

LEGAL AND REGULATORY INFORMATION

No part of this publication, or any other publication may be modiﬁed or adapt-

ed in any way, for any purposes without permission in writing from Luxul. The

material in this manual is subject to change without notice. Luxul reserves the

right to make changes to any product to improve reliability, function, or design.

No license is granted, either expressly or by implication or otherwise under any

Luxul intellectual property rights. An implied license only exists for equipment,

circuits and subsystems contained in this or any Luxul product.

FCC Compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) this device may not cause harmful inter-

ference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

FCC ID: W59XAP1230

IC: 8584A-XAP1230

FCC Statement—Wireless FCC 2.4GHz 802.11bgn

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules.

Hereby, Luxul, 14203 Minuteman Drive, Suite 201, Draper, Utah, 84020,

declares that this Luxul XAP-1240 is in compliance with the essential

requirements and other relevant provisions of Directive 1995/5/EC.

For a copy of this report send a self addressed stamped envelope

to: Luxul CE, 14203 Minuteman Drive, Suite 201, Draper, Utah, 84020.

Industry Canada (RSS-Gen Issue 4)

CAN ICES-3(B)/NMB-3(B)

Sales

P: 801-822-5450

E: sales@luxul.com

Technical Support

P: 801-822-5450 Option 3

E: support@luxul.com

•
