Side 1/38

3138 155 24272
S M A R T. V E R Y S M A R T.
User Manual
26MF/32MF231D
LCD TV
Read your user Manual and/or
Quick-Use Guide first for quick tips
that make using your Magnavox
product more enjoyable.
If you have read your instructions and
still need assistance,
you may access our online help at:
www.usasupport.magnavox.com
or call
1-800-705-2000
while with your product
(and Model / Serial number)
Thank you for choosing Magnavox.
Need help fast?
Model No: Serial No:

2
Know these safety symbols
This “bolt of lightning” indicates
uninsulated material within your unit may
cause an electrical shock. For the safety of ev
-
eryone in your household, please do not remove
product covering.
The “exclamation point” calls attention
to features for which you should read the
enclosed literature closely to
prevent operating and maintenance problems.
WARNING: To reduce the risk of fire or
electric shock, this apparatus should not be
exposed to rain or moisture and objects filled
with liquids, such as vases, should not be placed
on this apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
ATTENTION: Pour éviter les choc
électriques, introduire la lame la plus large de la
fiche dans la borne correspondante de la prise et
pousser jusqu’au fond.
For Customer Use
Enter below the Serial No. which is located
on the rear of the cabinet. Retain this
information for future reference.
Model No._______________________
Serial No. _______________________
Registering your model with MAGNAVOX makes you eligible for all of the valuable benefits listed below, so don’t miss
out. Complete and return your Product Registration Card at once to ensure:
*Proof of Purchase
Returning the enclosed card
guarantees that your date of
purchase will be on file, so no
additional paperwork will be
required from you to obtain
warranty service.
*Product Safety
Notification
By registering your product, you’ll
receive notification directly from
the manufacturer - in the rare
case of a product recall or safety
defect.
*Additional Benefits of
Product Ownership
Registering your product
guarantees that you’ll receive all
of the privileges to which you’re
entitled, including special
money-saving offers.
Congratulations on your purchase,
and welcome to the “family!”
Dear MAGNAVOX product owner:
Thank you for your confidence in
MAGNAVOX. You’ve selected one of the
best-built, best-backed products available today.
We’ll do everything in our power to keep you
happy with your purchase for many years to come.
As a member of the MAGNAVOX “family,” you’re
entitled to protection by one of the most
comprehensive warranties and
outstanding service networks in the industry.
What’s more, your purchase guarantees you’ll
receive all the information and special offers for
which you qualify, plus easy access to
accessories from our convenient home
shopping network.
Most importantly, you can count on our
uncompromising commitment to your total
satisfaction.
All of this is our way of saying welcome - and
thanks for investing in a MAGNAVOX product.
P.S. To get the most from your MAGNAVOX
purchase, be sure to complete and return
your Warranty Registration Card at once.
Visit our World Wide Web Site at http://www.usasupport.magnavox.com
RETURN YOUR PRODUCT REGISTRATION CARD TODAY
TO GET THE VERY MOST FROM YOUR PURCHASE.

Content
Welcome/registration of your TV . . . . . . . . . . . . . . . .2
IMPORTANT SAFETY INSTRUCTIONS
. . . . . . . . . 3
Precaution
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Conten
t . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Preparation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Use of the remote control
. . . . . . . . . . . . . . . . . . . . . . .9
Buttons on the top of the TV
. . . . . . . . . . . . . . . . . . . .11
To use the menus . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . 12
How to navigate through the Settings menu
12
Introduction
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Installation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Select the menu language
13
Store TV channels
13
Weak channel installation 14
Setup menu
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Preferences 15
Source
18
Clock
19
TV menu
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Picture menu 20
Sound menu 22
Features menu 23
Channels menu
24
Connect accessory devices
. . . . . . . . . . . . . . . . . . . . . 28
Recorder (vcr-dvd+rw) 28
Recorder and other A/V devices 29
Recorder and cable box with RF output 2
9
Satellite Receiver / cable box with AV outputs 29
Recorder and satellite Receiver / cable box with AV outputs 30
Digital Surround receiver 30
DVD Player or other accessory digital source devices
31
HDMI (High Definition Multimedia interface) connectors 32
Side connections
32
Record with your recorder. . . . . . . . . . . . . . . . .
. . . . . 33
Record a TV program 33
To select connected devices. . . . . . . . . . .
. . . . . . . . . .33
Trouble shooting tips
. . . . . . . . . . . . . . . . . . . . . . . . . . 34
Care and cleaning
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Regulatory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Annex 1- Magnavox TV software upgrade with portable memory . .36
Limited
warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
If this instruction manual does not give an
answer or if ‘Trouble shooting tips’ does
not solve your TV problem, you can call
your Local Magnavox Customer or
Service Center.
Please, have the Model and Serial number
which you can find at the back of your
television set or on the packaging, ready,
before calling the Magnavox helpline
1-800-705-2000
Model: 26MF231D/32MF231D
Serial No:.............................................
Help
Care of the screen See Tips, p. 35
Magnavox is paying a lot of attention to pro-
ducing environmentally-friendly in
product. Your new TV contains materials
which can be recycled and reused. At the
end of its life specialized companies can
dismantle the discarded TV to recycle the
reusable materials and to minimize the
amount of materials to be disposed of.
Please ensure you dispose of your old TV
according to local regulations.
5

7
- Cable TV
Connect the cable TV signal to the CABLE/
ANTENNA 75 jack at the bottom of the TV.
See page 14 for details on using Autoprogram to store
channels in the TV’s memory.
Note: This connection will supply stereo sound to the TV if
the station you are viewing broadcasts stereo sound.
- Cable box with RF IN/OUT
• Connect the incoming cable TV signal to the cable IN
jack on the back of the cable box.
• Connect a coaxial cable (not supplied) from the TO TV
jack on the back of the cable box to the CABLE/
ANTENNA 75 jack at the bottom of the TV.
Note: Your cable box may have a different label for the TO
TV jack. Commonly used labels include OUTPUT or OUT.
• Set the OUTPUT CH switch on the cable box to CH
3 or 4 (whichever is correct for your cable box), Next,
tune the TV to the corresponding channel. Once
tuned,change channels using the cable box, not the TV.
Note: This connection will not supply stereo sound to the TV. The
reason is that the RF output on a cable box - labeled TO TV, OUT
or OUTPUT for example - will not send a stereo signal to the tuner
(VHF/UHF) input on a TV.
- Cable box with A/V outputs
• Connect the incoming cable TV signal to a signal
splitter (not supplied). The signal splitter enables you to avoid
having to use the TO TV jack on the back of the cable box.
This jack will not supply stereo sound to the TV.
Note: Your cable box may have a different label for the TO
TV jack. Commonly used labels include OUTPUT or OUT.
• Connect a coaxial cable (not supplied) to a connector on
the signal splitter and to the CABLE/ANTENNA 75
jack on the TV.
• Connect another coaxial cable (not supplied) to a
connector on the signal splitter and to the cable IN jack
on the back of the cable box.
• Connect A/V cables (not supplied) to the VIDEO and
AUDIO L and R outputs on the back of the cable box
and to the AV2 video (labeled VIDEO) and AUDIO
(labeled L and R) jacks on the back of the TV.
• To view programs from your cable box, first press the
AV button on the remote control.
• Press the cursor down or up buttons until the AV2 signal
source is selected.
• Press the OK button to confirm your selection. The AV2
input source becomes current for the viewing of cable TV
programs through your cable box.
Note: If your cable box audio/video outputs do not supply
video and stereo audio to the TV, you will need to make the
connection shown above in “Cable box with
RF IN/OUT.
CABLE OR ANTENNA
75
CABLE
2IMDH1IMDHEC
CABLE OR ANTENNA
75
Cable box
OUT
OUTPUT
TO TV
IN
CABLE
3
2
ANTENNA
ANTENNA
Watching cable TV programs that don’t
require the use of a cable box.
Since you’ve connected the cable TV signal
directly to the TV’s tuner, you can also watch
unscrambled programs by simply tuning to
the desired channel; however, you must first use
Auto program to store available channels in the
TV’s memory. (p. 13)
Note: This connection will supply stereo sound to the
TV if the station you are viewing broadcasts stereo
sound.
HDMI
YPbPr
VIDEO
RL
YPbPr
VIDEO
RL
S-VIDEO
R
L
Cable box
OUTIN
75
CABLE OR ANTENNA
SPLIT TER
3
2
CABLE
1
4
AV2:
L+R+VIDEO
ANTENNA
Note: Video In signal input can be handled by
AV1, AV3 as well.

10
Press this button to display a list of available display formats.
Available display formats are determined by the type of signal you
are receiving.
To choose the display format you prefer, press the FORMAT
button repeatedly: Formats:
Automatic, Super Zoom, 4:3, Movie expand
14:9, Movie expand 16:9, 16:9 subtitle and widescreen.
Automatic makes the picture fill the screen as much as
possible. It is recommended to press the cursor up/down or
left/right key to adjust the picture position on the screen.
Super zoom removes the black bars on the sides of 4:3
programs with minimal distortion. When in the Movie expand 14:9,
Movie expand 16:9 or Super zoom picture format, you can make
subtitles visible with the cursor up/down.
Note: Not all screen formats are available when displaying HD sources.
Automatic Super zoom 4:3 Movie expand 14:9
Movie expand 16:9 16:9 subtitle Widescreen
FORMAT

11
Buttons on the top of the TV
Should your remote be lost or broken you can still change some
of the basic settings with the buttons on the top of your TV.
Press the power switch to switch the TV on.
Press:
•the + VOLUME -button to adjust to volume;
•the + CHANNEL -buttons to select the TV channels or
sources.
The MENU button can be used to display the Settings menu
without the remote control.
Use:
•the + VOLUME - buttons and the + CHANNEL -
buttons to select menu items in the directions as shown;
•the + VOLUME button to confirm your selection.
Note:
When a menu is activated through the MENU button on the top of
the TV, a menu can be closed only by navigating to Exit and pressing
the MENU button.

12
To use the menus
The Settings menu allows you to access and change
settings and preferences settings.
• Press the MENU button on the remote control to
display the Settings menu.
- Use cursor up/down to highlight and select a menu item
on the left panel.
The right panel shows the content of the menu you have
highlighted in the left panel.
Note: Sometimes not all the menu items are visible on the
screen. Use cursor down to scroll down to additional items.
- Use the cursor right to enter the right panel.
The content of the right panel is moved to the left panel
and the right panel shows the content of the newly
highlighted item in the left panel.
Note: In some cases, you will want to watch the picture on
your screen while adjusting settings. This means that when the
highlight is on the right side panel, the other menu items are
hidden. When the cursor left is pressed again, the hidden
menu items re-appear and the highlight moves to the left
panel.
• Press the cursor left to go one menu level up again.
- Press the OK button on the highlighted item to activate
and to dismiss the menu.
- Press the MENU button again to exit the Settings menu.
Note: The menu is also dismissed by pressing one of the color
buttons (if present) referring to certain actions which may be
executed.
Settings
TV
Sound
Features
Channels
Info
Smart Picture
Contrast
Brightness
Color
Sharpness
Color temperature
Tint
Picture format
Settings
Setup
Installation
Exit
Info
TV
Sound
Features
Channels
TV
Settings
TV
Sound
Features
Channels
Info
Smart Picture
Contrast
Brightness
Color
Sharpness
Color temperature
Tint
Picture format
Settings
Setup
Installation
Exit
Info
TV
Sound
Features
Channels
TV
How to navigate through the Settings menus
Introduction
When you use a menu or take an action, convenient instructions, help texts and messages will be displayed on your TV.
Please, follow the displayed instructions and read the help text on the specific item highlighted.
The color buttons govern different actions you can take on an activated device. Press the corresponding color button on
the remote control to perform the required action on a selected device.

13
Installation
Select Autoprogram in the Installation menu.
Use the cursor right to enter the Autoprogram menu.
Press the OK button.
Select Cable or Antenna in the Installation mode.
When Antenna is selected, the TV will detect antenna
signals and will search for antenna TV (NTSC and ATSC) channels
available in your local area.
When Cable is selected, the TV will detect cable company
supplied signal sand will search for cable TV (NTSC, ATSC, QAM
modulated) channels available in your area.
Make sure that registration with your cable TV provider and
connection of equipment are completed.
Press the green button “Next” on the remote control.
Note: All channels must be unlocked in order to autoprogram. If
requested, enter your PIN code to unlock all channels. See Menu
preferences in the Settings, TV menu, p. 17.
Press the green button “Start” to start autoprogramming. The
menu screen disappears and the progress of autoprogramming is
displayed. The progress bar indicates the number of analog and
digital TV channels found.
When Autoprogramming is complete, a message appears
confirming the completion and the TV switches to the first
installed TV channel.
Settings
Setup
Exit
Info
Installation
Language
Autoprogram
Weak channel installation
Software upgrade
TV
Installation
Settings
Installation
Info
Autoprogram
Start now
Language
Autoprogram
Weak channel installation
Software upgrade
Television Installation
Installation mode
Previous Next
Antenna
Please select your
installation mode
Cable
Notes:
• When you have locked TV channels before initiating Autoprogram, a message appears asking to enter your PIN code in
order to complete Autoprogramming.
• ATSC channel information is updated automatically when the TV is in standby after 3 minutes and every 3 hours thereafter.
• When channel update is interrupted, the new updated channel information is retained along with the old un-updated
channel information.
• Background Autoprogramming occurs only when the TV is turned on.
• Channel information about an ATSC channel is updated only for the ATSC channel currently tuned.
• If an NTSC channel is tuned, then in Background Autoprogramming the TV shall scan all the possible ATSC frequencies
and update information.
• Weak channel installation allows you to manually tune weak ATSC channels in order to adjust the antenna and thus
optimize signal quality for that channel. (See Installation menu, Weak channel installation, p. 14.)
• Once you have searched for the available Antenna as well as the Cable TV channels, they are stored in the memory.
• If Antenna/cable signal is interrupted more than ten minutes, TV will go into off mode. You are requested to press Power button
or CH / button to turn on the TV.
Select the menu language
Press the MENU button on the remote control.
Use the cursor down to select Installation in the Settings menu.
Use the cursor right to enter the Installation menu.
Select Language and enter the list of available languages with the
cursor right.
Select your preferred language with the cursor up/down and press
the OK button to confirm you selection.
Proceed with the Installation menu.
Store TV channels
1
2
3
4
5
6
1
2
3
4
5
6

14
Note: Digital Channel selection delay
Due to the tuning complexity of subchannel
digital programming, the time to select and view
a digital channel may take slightly longer than
what the viewer is normally accustomed to (as
compared to analog channel programs).
Digital channel broadcasts contain program and
system data information that must be processed
before the channel selection can be displayed.
Channel tuning
Available channels:
- Cable (analog NTSC or digital QAM)
- Terrestrial (analog NTSC or digital ATSC)
If a tuned channel is not yet in the
master channel map, the TV will attempt to tune to the
channel and it will be added to the map.
If the channel is not acquired, a message will appear reporting
that the channel is not available. When you tune an audio-only
digital subchannel, a display appears with the message Audio only.
Note: Subchannel selections
The new standards employed with digital broadcasting make it possible
to receive multiple program channels under a single major channel
number which can be selected by pressing the digit remote control
direct-access channel number entry.
Important:
After the installation of the TV channels is completed, always
make a selection in the Installation menu between Antenna or
Cable whether you want to watch Antenna TV channels or Cable
TV channels.
If you make use of a signal splitter do not forget to put the switch
in the corresponding position.
Settings
Setup
Exit
Info
Installation
Language
Autoprogram
Weak channel installation
TV
Installation
Software upgrade
Antenna reception for broadcast channels may vary. If you are
having difficulties acquiring weaker signals, we suggest
you use: Weak Signal Installation feature.
Here’s how:
In the antenna mode, select a channel from the displayed list of
TV channels. Select the “Start” by red button on the remote
control; TV set will detect the signal.
The signal strength is continuously displayed and updated as the
antenna rotates.
When strength is enough to identify, user can store the channel
in the channel list by green button on the remote control.
Weak channel installation
Software upgrade
This menu allows you to upgrade your TV software using a USB
device.
USB upgrade
It is possible to initiate an upgrade procedure from a USB portable
memory (not supplied). The memory device must be filled with the
appropriate upgrade image (and structure) which can be found on
the www.usasupport.magnavox.com website. How to upload a new
software version on your portable memory device (not supplied),
see Annex 1, p. 36.
1
2

16
Digital caption service
This allows you to configure the way you choose to view digital
captioning.
Select one of the digital service channels made available by the
caption provider.
There are six standard services. Service 1 is designated as the
Primary Caption Service. This service contains the verbatim, or
near-verbatim captions for the primary language being spoken in
the accompanying program audio.
Service 2 is designated as the Secondary Language Service.
This service contains captions in a secondary language, which
is a translation of the captions in the primary Caption
Service. The other service subchannels are not pre-assigned.
It is up to the discretion of the individual caption provider to
utilize the remaining service channels.
Settings
Setting
Installation
Exit
Info
Setup
Preferences
Source
Clock
TV
Setup
Settings
Setup
Info
Preferences
Sound preferences
Features preferences
Menu preferences
Reset AV settings
Preferences
Source
Clock
Settings
Info
Sound preferences
Auto surround
Preferences
Sound preferences
Features preferences
Menu preferences
Reset AV settings
Settings
Info
Caption service
Preferences
Sound preferences
Features preferences
Menu preferences
Reset AV settings
Features preferences
Digital caption service
Digital caption options
• Reset to default
Select this option to reset the digital caption options to the
captions provider default settings.
Press the OK button to confirm.
• Size
Select this option to choose a caption display size according
to your own preference. Select Default (Automatic),
Small, Standard or Large and press the OK button to
confirm.
• Style
Select this option to choose a caption display font style
according to your own preference. Select Default, Mono
spaced serif, Serif, Monospaced sans serif, Sans serif,
Casual, Cursive or Small caps.
• Text
Select this option to choose caption display text box, text
color and/or the opacity according to your own preference.
Select a color and an opacity option.
• Background
Select this option to choose caption display character back
ground color or one of the background opacity options
according to your own preference. Select a color and one of
the opacity options.
Digital caption options
This allows you to modify how digital captions are displayed on your
TV. Select from the following options to change the visual
characteristics of your TV’s digital captioning.

17
Settings
Info
OSD
Preferences
Sound preferences
Features preferences
Menu preferences
Reset AV settings
Show emergency alerts
Change PIN
Menu preferences
OSD
Select OSD.
Press the cursor right key to select Normal or Minimum.
Normal activates a continuous display of the channel number
for a maximum of 10 minutes and extended display of TV
channel and program information on screen. For example,
information on the main or auxiliary program, input signal quality
of connected accessory devices, the display format, sound mode,
availability of Closed Caption service, the audio language, the
rating, sleep timer setup is displayed.
Minimum activates the display of reduced channel information.
Note: When Closed Captions is switched on, continuous display of the
channel number and clock is not possible.
Show emergency alerts (EAS)
This allows you to select the alert priority level of the information
disseminated by the cable operator. The standard SCTE18 defines
an Emergency Alert signalling method for use by cable TV
systems to signal emergencies to digital devices such as digital
set-top boxes, digital TVs and digital VCRs.
The Emergency alert signalling scheme defined in the standard
allows a cable operator to disseminate emergency alert
information related to state and local-level emergencies and
warnings in a cost-effective and efficient way, while minimizing
disruption of programming.
An Emergency alert message will have one of the following
priorities: Low, Medium, High or Maximum.
The Emergency alert message with priority High or Maximum
will always be presented. Low or Medium will be present or
ignored depending on the setting you select.
Important: When the TV clock is undefined (See Setup menu, Clock,
p. 19), the Emergency Alerts will be ignored.
The Emergency Alert message display will contain following
information:
- The Emergency Alert text
- The start time + date
- The end time + date.
Select Show Emergency Alerts in the Menu preferences menu.
Press the cursor right key and select one of the Emergency alerts
options:
- Always: You always want available Emergency alert messages to
be displayed;
- Skip low priority: You want low level messages to be ignored;
- Skip low/medium priority: You only want the high priority
message to be displayed.
Set/Change PIN
Select Set or Change PIN with the cursor down.
If no PIN-code exists, the menu item is set to Set PIN.
Follow the instructions on screen. If a PIN-code has previously
been entered, the menu item is set to Change PIN. Follow the
instructions on screen. All number combinations from 0000 to
9999 are valid numbers.
The Menu preferences menu reappears with a message
confirming that the PIN has been created.
Important: you have forgotten your PIN!
Note: Emergency Alert Signalling is not possible:
- when content browsing;
- with analogue video sources.
Notes:
- You always have the possibility to remove the
message from the screen.
- The message display will overlap whatever
menu element or other message is on the
screen.
Select Change PIN in the Menu preferences
menu and press the cursor right key.
Press the cursor right key to enter the
overriding PIN code 0-7-1-1.
Press the cursor again and enter a new
personal 4-digit PIN code. The previous
code is erased and your new PIN-code is
stored.
Menu preferences
1
2
1
2
1
2
3
1
2
3

20
TV menu
Settings
TV
Sound
Features
Channels
Info
Smart Picture
Contrast
Brightness
Color
Sharpness
Color temperature
Tint
Picture format
Settings
Setup
Installation
Exit
Info
TV
Sound
Features
Channels
TV
Press the cursor right key to select Picture.
Press the cursor right key again to enter the Picture menu.
Select the menu items with the cursor up/down key.
Adjust the settings with the cursor left/right key or enter the list of
submenu items with the cursor right key. Select a
submenu item with the cursor up/down key.
Press the MENU button on the remote control to display the
Settings menu. The TV menu gives you an overview of the menus you
can select.
Note: Depending on the input signal, one or more menu items may not be
selectable.
Picture menu
Note: Some menu items are not available in case of HD sources.
Select Smart picture to display a list of predefined picture
settings, each corresponding with specific factory settings.
Personal refers to the personal preference settings of picture in
the picture menu.
Note: This Magnavox TV has been set at the factory to look best in
bright store environments, which typically use fluorescent lighting. As your
home will likely not be as well lit as a store, we recommend that you
cycle through the various smart picture modes to find the one that best
suits your own viewing conditions. Most consumers will find that
Natural
is the correct choice.
Smart picture
This will adjust the intensity of bright parts in the picture but keep
the dark parts unchanged.
Contrast
This will adjust the light output of the complete picture, which will
mainly affect the darker areas of the picture.
Brightness
This will adjust the saturation level of the colors to suit your
personal preference.
Color
1
2
3
4
You can press the Smart picture button repeatedly to select
either Personal, Rich, Natural, Soft, Multimedia or Eco picture
settings.
Note: When you watch programs using VCR, it’s recommended to select
Soft Mode via smart picture.
1
2

22
Settings
Setup
Installation
Exit
Info
TV
Sound
Features
Channels
TV
Settings
TV
Features
Channels
Info
Sound
Smart Sound
Volume
Balance
Headphone volume
Sound mode
Alternate audio
Digital audio language
Mono/Stereo
Sound
Settings
TV
Features
Channels
Info
Sound
........
Mono/Stereo
AVL
Delta volume
Sound
Select Sound in the TV Settings menu.
Press the cursor right key to enter the sound menu.
Select the menu items with the cursor up/down key and adjust the
settings with the cursor left/right key.
Remember, control settings are at normal mid-range levels when the
bar scale is entered.
Settings
Setup
Installation
Exit
Info
TV
Sound
Features
Channels
TV
Settings
TV
Features
Channels
Info
Sound
Smart Sound
Volume
Balance
Headphone volume
Sound mode
Alternate audio
Digital audio language
Mono/Stereo
Sound
Settings
TV
Features
Channels
Info
Sound
........
Mono/Stereo
AVL
Delta volume
Sound
Manufactured under license from Dolby
Laboratories. “Dolby” “Pro Logic” and
the double-D symbol are trademarks of
Dolby Laboratories.
Corrects for any permanent volume differences between TV channels
or external sources.
Delta volume
Automatically reduces the volume differences between channels and
programs, providing a more constant overall level. This will also reduce
the dynamics of sound.
AVL (Automatic Volume Leveler)
(only available with analog
broadcast and non-Digital signals)
Selects per TV channel, Mono or Stereo sound when analog stereo
broadcasts are available.
Mono/Stereo
Selects your language preference when digital broadcast
signal multilingual audio track programs are available.
Note: The default language for the digital channels is the installed menu
language.
Digital Audio language
(only selectable with digital broadcast signals)
This gives you the possibility to swap between the Main and
Second Audio Program (SAP) when it is available.
Alternate audio
(only selectable with analog broadcast signals)
This select the modes for more spatial or surround sound
reproduction dependent on the broadcast signals or signals from
external inputs received.
Sound mode
This controls the level of sound through the headphones.
Headphone volume
This will adjust the output of the right and left speakers to obtain the
best stereo reproduction for your listening position.
Balance
This will adjust the sound output level.
Volume
Select Smart sound to display a list of predefined sound settings,
each corresponding with specific factory settings of Treble and Bass.
Press the cursor right key to enter the list.
Press the cursor up/down key to select a predefined sound setting.
Personal refers to the personal preference sound settings in the sound
menu.
Note: The moment you are in a predefined Smart sound setting and you
modify a setting in the Sound menu, all values of the menu will overwrite the
previously made personal setting.
Smart sound
Sound menu
1
2
3
4
1
2

23
Settings
TV
Channels
Info
Features
Closed captions
Sleeptimer
Sound
Features
Features menu
This sets a time period after which the TV automatically turns to
standby.
Select Sleeptimer.
Press the cursor right key.
Select a value with the cursor up/down key. The list will have values
from Off to 180 minutes. When Off is selected, the sleeptimer is
turned off.
You can always turn off your TV earlier or select another time set.
Sleeptimer
This displays the transmitted CC- or CS-text on the screen
according to your chosen CC or CS service in the Setup menu,
Features preferences menu, p. 15. This text can either be
permanently displayed (assuming that the service is
available in the broadcast) or only when mute is active.
Press the cursor right key after having selected Closed captions.
Select On, Off or On during mute.
Closed captions
Select Features in the TV Settings menu.
Press the cursor right key to enter the features menu.
Select the menu items with the cursor up/down key and
adjust the settings with the cursor left/right key.
1
2
3
1
2
1
2
3

24
Settings/TV
Channels
Info
Lock after
Timer
Time
Lock after
Channel lock
TV ratings lock
Movie ratings lock
Prefered channels
Region ratings lock
Clear region ratings
Settings
TV
Info
Channels
Lock after
Channel lock
TV ratings lock
Movie ratings lock
Prefered channels
Sound
Features
Channels
Region ratings lock
Clear region ratings
Settings/TV
Channels
Info
TV ratings lock
Please enter your PIN
Lock after
Channel lock
TV ratings lock
Movie ratings lock
Prefered channels
Region ratings lock
Clear region ratings
Your TV is equipped with a V-chip. This allows you to control
access to individual programs based on their movie and TV ratings. All
settings apply to all AV inputs, except HDMI. The program content
advisory data are sent by the broadcaster or program provider.
Select TV ratings lock with the cursor down. A list appears, showing
the age-based TV ratings and a corresponding content-based ratings
list.
Press the cursor right to enter the list.
Select an age-based TV rating with the cursor up/down, and enter, if
present, the list with content-based ratings with the cursor right, and
select one content-based rating.
Press OK to activate/de-activate the selected rating. You are asked to
enter your PIN-code (see Set/Change PIN, p. 17). If the code is correct,
the TV ratings lock menu reappears.
Select another content-based rating if you like and press OK again.
Channels menu
This menu can control special functions for the TV channels.
Select Channels in the TV settings menu with the cursor up/down key.
Press the cursor right to enter the channels menu.
Press the cursor up/down key to select a channels menu item.
Note: Lock after is only selectable if time and date are known. See Setup,
Clock menu p. 19.
This allows you to prevent the viewing of the channels after a selectable
time delay. Locked channels can still be tuned, but the picture is blanked
and the audio is muted.
Press the cursor right and select Timer On or Off.
When set to On this allows you to set the clock.
When having selected Timer On, you will be asked to enter your PIN
(See Set/Change PIN, p. 17). Follow the instructions on screen.
Select Time and press the cursor right. This allows you to set the time
after which the lock is set.
Select AM or PM to select the correct period of the day.
Enter the time with the digit or the cursor buttons and press OK to
confirm.
Lock after
This allows you to completely lock a certain TV channel or external
source. Select the channels or subchannels you want to lock and press
OK to confirm.
Channel lock
TV ratings lock
You need only enter your PIN-code once while the menu is active. You
can lock/unlock any number of ratings on the list without re-entering your
code.
Each ratings item has a box-graphic in front of it to indicate whether or not
programs carrying that rating are currently locked:
•
: all items in the contents-based list are locked as well;
•
: the item is unselected;
•
: some content-based ratings are selected/unselected.
1
2
3
4
1
2
3
1
2
3
4
5

25
When All has been selected, all items in the age-based and in
the contents-based lists are locked. If, while All is selected,
any other item, either an age-based or content-based item, is
unselected, then All is automatically unselected.
None is the selection for items that either have no rating
information or have a rating of None. Both will be locked.
When an item on the age-based list is selected, all items below
that item of the same group are locked as well. When you
select a content-based rating, all identical content- based
ratings in the younger age-based categories are also selected.
Age-based Rating Content-based Rating
All none
None none
TV-Y none
TV-Y7 (FV) Fantasy Violence
TV-G none
TV-PG (D) Dialog
(L) Language
(S) Sex
(V) Violence
TV-14 (D) Dialog
(L) Language
(S) Sex
(V) Violence
TV-MA (D) Dialog
(L) Language
(S) Sex
TV-Y
appropriate for children of all ages with themes and
elements suitable for children aged 2-6
TV-Y7
programs designed for children age 7 and older
TV-Y7-FV
programs include fantasy violence more intense than other
programs in the TV-Y7 category
TV-G
programs suitable for all ages. These programs contain little
or no violence, no strong language and little or no sexual
dialogue or situations
TV-PG
programs contain elements that some parents may find
unsuitable for younger children and which may need
parental guidance. The program may contain moderate
violence, sexual dialogue and/or situations and some strong
language.
TV-14
programs contain elements that may not be
suitable for children under 14 years of age. These programs
include one or more of the following: intense violence,
intense sexual situations, suggestive dialogue and strong
language.
TV-MA
programs are designed to be viewed by adults and may be
unsuitable for children under the age of 17. These programs
may contain graphic violence, explicit sexual activity and/or
crude or indecent language.

26
Settings/TV
Channels
Info
Movie ratings lock
Please enter your PIN
Lock after
Channel lock
TV ratings lock
Movie ratings lock
Prefered channels
Region ratings lock
Clear region ratings
Settings/TV
Channels
Info
Prefered channels
Channel 1
Lock after
Channel lock
TV ratings lock
Movie ratings lock
Prefered channels
Channel 2
........
Region ratings lock
Clear region ratings
This function allows you to control access to individual movies based on
their MPAA ratings (Motion Picture Association of America).
Select Movie ratings lock with the cursor down. A list appears, showing
all valid MPAA content ratings.
Press the cursor right to enter the list. You are asked to enter your
code. (See Set/Change PIN, p. 17.) If the code is correct, the Movie
ratings lock menu reappears.
Select a movie rating with the cursor up/down.
Press OK to activate/de-activate the selected rating.
Preferred channels
A channel, when installed, is marked as preferred by default and
added to the channel list. This feature provides the ability to
remove a channel number from the channel list.
Select Preferred channels with the cursor down key.
Press the cursor right key to enter a list with all stored
channel numbers.
Select the channel you want to remove with the cursor down key.
Press OK.
Repeat to remove other channels.
Movie Ratings Lock
Each rating item has a box-graphic in front of it to indicate
whether or not programs carrying that rating are currently locked:
•
: movies with this rating are locked;
•
: movies with this rating are unlocked.
When All has been selected, all items on the movie ratings list become
selected. (All movies are locked.) If, while All is selected, any other item is
unselected, then All is automatically unselected.
When NR has been selected, no other item is selected.
When any other item has been selected, all ratings below are selected as
well, thus all movies with those ratings will be locked.
Settings/TV
Channels
Info
Movie ratings lock
Please enter your PIN
Lock after
Channel lock
TV ratings lock
Movie ratings lock
Prefered channels
Region ratings lock
Clear region ratings
Settings/TV
Channels
Info
Prefered channels
Channel 1
Lock after
Channel lock
TV ratings lock
Movie ratings lock
Prefered channels
Channel 2
........
Region ratings lock
Clear region ratings
1
2
3
4
1
2
3
4
5
NR not rated
G movies with a mild content, suitable for all ages
PG movies for which parental guidance is recommended. They
may contain a few racy or violent scenes or maybe some bad
language
PG-13R movies for which parental guidance may be recommended if
under age 13
R restricted. The movies usually contain offensive sex or bad
language and may be unsuitable for children under the age of
17. Parental guidance or permission needed.
NC-17 even with parental permission, forbidden under age 17.
More offensive sex, violence or bad language.
X
movies which generally focus on sex, violence and/or bad
language. Also known as pornography.

30
Connect the RF Antenna or Cable TV cable as described above.
Connect the AV cables to the satellite receiver’s or cable box’s
AV OUT jacks and to the recorder’s AV IN jacks.
Connect the recorder’s AV OUT jacks to the TV’s AV3
jacks as described above.
Connect another RF cable from the output out of your
recorder to the TV’s input CABLE/ANTENNA jack.
Recorder and Satellite Receiver / cable box with AV outputs
Digital Surround receiver
Connect a Digital Multi Channel Surround receiver to the
DIGITAL AUDIO OUT (SPDIF OUT) connector at the bottom of
the TV.
AV3:
L + R + VIDEO
2
Pb
Y
Pr
VIDEO
R
L
Y
Pb
Pr
VIDEO
R
L
S-VIDEO
R
L
RECORDER
OUT
OUT
IN
IN
1
O
UT
STB
OUT
CABLE OR ANTENNA
7
5
3
HDMI
S-VIDEO
R
L
DIGITAL
AUDIO
OUT
1
2
3
4

31
Connect the three separate component video cables to a
Set-Top box, DVD-players, laser-disc players, video game players,
satellite receivers or other device with component video outputs
(YPbPr), and to the
Y, Pb and Pr jacks of AV1 or AV2 on the TV.
DVD Player or other accessory digital source devices
Devices with Component Video Output Connectors
(YPbPr)
This TV is capable of displaying 1080i, 720p and 480p DTV signals when
connected to a DTV tuner Set-Top Box. Select the output of the Set Top
Box to either 1080i, 720p or 480p. A DTV signal must be available in your
area.
Connect an S-Video cable to the AV3 or Side AV input . Note:
When using the S-VIDEO connector do not connect any
device to the AV VIDEO input that you are using.
Connect the audio cables to the device’s AUDIO L and R jacks and to
the L and
R audio AV3 or Side AV jacks on the TV
accordingly to where you connected the S-Video cable.
Notes:
- If necessary, you can center your screen picture position with
the cursor keys.
- Labels for the component video sockets may differ depending on
the DVD player or the device your are connecting. Although the
abbreviations may vary, the letters B and R stand for the blue
and red component signals, respectively, and Y indicates the
luminance signal. Refer to the DVD player’s or devices
instructions for definitions and connection details.
- This television is designed to accept high definition signal standards
720p and 1080i as specified by the Electronic Industries As
sociation standard EIA770.3. Digital devices from different manu
facturers may have differing output standards which may cause
difficulties for proper television display.
- Due to possible digital image distortion when displaying signals
from connected digital equipment, we suggest you select the
Soft setting from the Smart picture menu. See Picture menu,
Smart picture, p. 20.
Set the Personal setting to off before storing this setting.
Warning: If scrolling images, mismatched colors, no color, no
picture, or combinations of these appear on your screen, check
to make sure input cables are connected to their corresponding
color-coded inputs or connections or move your digital device
farther away from your TV.
Devices with an S-Video connector
Pb
YPr
VIDEO
RL
Y
PbPr
VIDEO
RL
S-VIDEO
R
L
DVD / STB
YPbPr
AV1/AV2:
L + R
2
AV1/AV2:
YPbPr
1
Pb
YPr
VIDEO
RL
Y
PbPr
VIDEO
RL
S-VIDEO
R
L
DVD / STB
AV3/Side:
L + R
2
S-VIDEO
1
L
R
S-VIDEO
VIDEO
1
1
2

33
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installa-
tion. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the
separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected. Consult the dealer or an
experienced radio or television technician for help.
Modifi cations-
The FCC requires the user to be notifi ed that any changes or
modifi cations made to this device that are not expressly
approved by Magnavox Consumer Electronics may void the user’s
authority to operate the equipment.
Cables -
Connections to this device must be made with shielded cables
with metallic RFI/EMI connector hoods to maintain compliance
with FCC Rules and Regulations.
Canadian notice -
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Avis Canadien -
Cet appareil numérique de la classe B respecte toutes les
exigences du Règlement sur le matériel brouilleur du Canada.
Regulatory Notices-Federal Communications Commission Notice
Record with your recorder
To select connected devices
Record a TV program
You can record a TV program using your recorders tuner
without affecting your TV.
Select the channel number on your recorder.
Set your recorder to record.
See the handbook for your recorder.
Note: Switching channel numbers on your TV does not disturb
recording !
Press he AV button repeatedly or select Source in the
Settings menu (see p. 18) to select AV1, AV2, AV3, HDMI, Side
or TV, according to where you connected your devices.
Press the cursor up/down.
Press OK.
1
2
1
2
3
TV
Recorder
Y
PbPr
VIDEO
RL

34
Trouble Shooting Tips
Symptoms Items to Check and Actions to follow
“Ghost” or double
images
• This may be caused by obstruction to the antenna due to high rise buildings or hills.
Using a highly directional antenna may improve the picture.
No power • Check that the TV’s AC power cord is plugged into the mains socket.
• Unplug the television, wait for 60 seconds. Then re-insert plug into the mains socket
and turn on the television again.
No picture • Check antenna connections at the bottom of the TV to see if they are properly connected to the TV.
• Possible broadcast station trouble. Try another channel.
• Adjust the contrast and brightness settings. Try another auto picture setting.
• Check the Closed Captions control. Some TEXT modes could block the screen.
• Check if you selected the correct AV source.
No picture and power
switched on
• Your TV has a protective mode in case there is too much heat build-up. Check the
clearance around the vents of the device to be certain there are no blocking walls or
cabinets which would limit the air flow.
Picture position
adjustment
When displaying a High Definition signal from the YPbPr inputs or HDMI input, if necessary, you can
adjust the picture position to the center of the screen with the cursor left/right or up/down buttons on
the remote control. This may be needed due to slight differences in output signals from different brands
and types of HD sources boxes.
Notes: Most High Definition receiver boxes also have picture-positioning controls in their menu
systems. If the TV cursor controls run out of range before the picture is correctly positioned, the
receiver box controls will need to be adjusted.
No photo, music or
video play or in poor
quality only
• Check if the source complies with a supported code.
No sound • Increase the VOLUME.
• Check that the TV is not muted, press the MUTE button on the remote control.
• When no signal is detected, the TV automatically switches off the sound. This is proper
operation and does not indicate a malfunction.
Good sound but poor
color or no picture
• Adjust the contrast, color, tint and brightness setting. Try another auto picture setting.
Snowish picture and
noise
• Check the antenna connection.
Television not
responding to
remote control
• Check whether the batteries are working. Replace if necessary.
• Clean the remote control sensor lens on the monitor.
• Operating range between TV and the remote control should not be more than approximately twenty feet.
• You can still use the buttons on the right side of your TV.
• Check if the remote control is in the correct mode.
Control of accessory
devices
• The infrared signals of the screen may influence the reception sensibility of other peripherals Solution:
replace the batteries of the remote control of other devices. E.g. keep away a wireless headphone from
within a radius of approximately four feet.
The software will not
install
Possibly the operating system is wrong.
Go to www.usasupport.magnavox.com to see which operating systems are supported.
Standby Your TV consumes energy less than 1w in the standby mode.
After improper
shutdown
If your TV has been shutdown in an improper way (e.g. power drop, power cord plug out), starting up the
TV again will take a longer time than usual.
Miscellaneous See Extras, Specifications on this user’s manual.

35
WARNING concerning stationary images on the TV
Screen: Do not leave fixed images on the screen for extended periods of time. This can cause uneven aging of the LCD
panel. Normal use of the TV should involve viewing of programs that have constantly moving or changing images. Do
not leave moving images on screen for extended periods of time. Do not display the same images too frequently; if you
do, subtle “ghost” images can be left on the LCD screen. Sources of stationary images may be Laser discs, video games,
Compact Discs Interactive (CD-i), paused Digital Video Discs (DVDs) or video tapes.
Here are some common examples of stationary images:
• DVD menus list DVD content.
• Letter box black bars that appear at the top and bottom of the TV screen when a wide screen (16:9) movie is viewed
on a TV with standard (4:3) aspect ratio. This occurs with some DVDs.
• Video game images and scoreboards
• Television station logos cause a problem if they are bright and stationary. Moving or low-contrast graphics are
less likely to damage the picture tube.
• Stock market tickers may appear at the bottom of the TV screen if the TV programming covers this news.
• Shopping channel logos, pricing displays may be bright and may appear constantly during the show.
These are usually apper in the same location on the TV screen.
TV Location
• To avoid cabinet warping, cabinet color changes, and an increased chance of TV failure, do not place the TV
where temperatures can become excessively hot -- for example, in direct sunlight or near a heating appliance.
• Allow a free flow of air around the TV.
Cleaning
• To avoid possible shock hazard, remove the TV’s power cord from the electrical outlet before cleaning.
• Regularly dust the TV with a dry, non-scratching duster.
• When cleaning the TV, take care not to scratch or damage the screen surface. Avoid wearing jewelry or using
anything abrasive.
Do not use household cleaners. Wipe the screen with a clean cloth dampened with water.
Use even, easy, vertical strokes when cleaning.
• Occasionally vacuum the vents on the rear of the TV.
• Never use thinners, insecticide sprays, or other chemicals on or near the cabinet. They may permanently blemish
the cabinet.
Care And Cleaning

37
Automatic software upgrade procedure
Power off your TV and remove all memory devices.
Insert the USB portable memory (not supplied) that contains the
downloaded software upgrade.
Switch on your TV with the power switch
at the right side of the
TV.
At startup the TV will scan the USB portable memory (not
supplied) until it finds the update content. The TV will
automatically go to the upgrade mode. After a few seconds it will
display the status of the upgrade procedure.
Warning:
• You are not allowed to remove the USB portable memory (not
supplied) during the software upgrade procedure!
• In case of a power drop during the upgrade procedure, don’t
remove the USB portable memory (not supplied) from the TV.
The TV will continue the upgrade as soon as the power comes back.
• If you try to upgrade to a software version lower than the
current version, a confirmation will be asked. Down grading to
older software should only be done incase of real necessity.
• If an error occurs during the upgrade, you should retry the
procedure or contact your dealer.
When the software upgrade was successful, remove the USB
portable memory (not supplied) and restart your TV with the
power switch
at the right side of the TV.
Your TV will start up with the new software.
Note: Once the upgrade is finished use your PC to remove the TV
software from your USB portable memory (not supplied).
Manual software upgrade procedure
For a manual software upgrade copy the “autorun.upg” file in a
directory called “Upgrades” located in the root of the USB
portable memory (not supplied).
Insert the portable memory (not supplied) that contains the down
-
loaded software upgrade.
Select Software Upgrade in the Installation menu. Go to Local
upgrades/applications. The TV will list all compatible images
available on the USB portable memory (not supplied) and display
the data for each selected upgrade image.
Select the correct upgrade image and press the red color button to
start the upgrade. Your TV will restart and will automatically go to
the upgrade mode. After a few seconds it will display the status of
the upgrade procedure.
Warning:
If you try to upgrade to a software version equal or lower than the
current version, a confirmation will be asked. Downgrading to older
software should only be done in case of real necessity.
When the software upgrade was successful, remove the USB
portable memory (not supplied) and restart your TV with the
power switch
at the right side of the TV. Your TV will start up
with the new
software.
3
4
1
2
Software Id: TL32E-234
Loading
Validating
Done
Done
Programming
Please wait ...
Software Upgrade Application
Settings
Installation
Info
Software upgrade
Local upgrades/applications
Current software info
Language
Autoprogram
Weak channel installation
Software upgrade
1
2
3
4
5
Produkt Specifikationer
Mærke: | Magnavox |
Kategori: | televisión |
Model: | 26MF231D |
Har du brug for hjælp?
Hvis du har brug for hjælp til Magnavox 26MF231D stil et spørgsmål nedenfor, og andre brugere vil svare dig
televisión Magnavox Manualer
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
7 Januar 2025
televisión Manualer
Nyeste televisión Manualer
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
