2 ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: GRU02 GRU03
Handle type Bike handle Loop handle
No load speed
(at each rotation speed level)
3: 0 - 7,000 /min
2: 0 - 5,500 /min
1: 0 - 4,600 /min
Overall length
(without cutting tool and battery)
1,815 mm (71-1/2″)
Nylon cord diameter 2.0 mm (0.08″)
Applicable cutting tool and
cutting diameter
2-tooth blade
(P/N 198345-9)
255 mm (10″)
3-tooth blade
(P/N 195299-1)
255 mm (10″)
4-tooth blade
(P/N 195150-5)
(P/N 196895-8)
230 mm (9″)
255 mm (10″)
Nylon cutting head
(P/N 198893-8)
430 mm (17″)
Rated voltage D.C. 36 V - 40 V max
Net weight 5.7 - 6.3 kg (12.6 - 13.9 lbs) 5.3 - 5.9 kg (11.7 - 13.0 lbs)
• Due to our continuing program of research and development, the specications herein are subject to change
without notice.
• Specications may dier from country to country.
• The weight may dier depending on the attachment(s), including the battery cartridge. The lightest and heavi-
est combination, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge and charger
Battery cartridge BL4020 / BL4025* / BL4040* / BL4050F*
* : Recommended battery
Charger DC40RA / DC40RB / DC40RC
• Some of the battery cartridges and chargers listed above may not be available depending on your region of
residence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
and chargers may cause injury and/or re.
Recommended cord connected power source
Portable power pack PDC01 / PDC1200
• The cord connected power source(s) listed above may not be available depending on your region of residence.
• Before using the cord connected power source, read instruction and cautionary markings on them.
SAFETY WARNINGS
Important safety instructions
WARNING: When using electric gardening
appliances, basic safety precautions should
always be followed to reduce the risk of re,
electric shock, and personal injury, including the
following.
Read All Instructions
Failure to follow the warnings and instructions may
result in electric shock, re and/or serious injury.
SAVE THESE INSTRUCTIONS.
General instructions
1.
Never allow people unfamiliar with these instruc-
tions or children to use the machine. Local reg-
ulations can restrict the age of the operator. It is
dangerous in the hands of untrained users or children.
2. Be sure that anyone who is to operate the tool
has rst read the instruction manual.
