FRONT PANEL FUNCTION
1. HEADPHONE JACKS
Use to connect for audio monitoring with headphones.
2. JOG & SHUTTLE WHEELS
Shuttle : Use the dial to select the scanning direction and speed. The disc is scanned in the forward
direction when the shuttle dial is turned clockwise from the neutral position, in the reverse direction
when the shuttle dial is turned counterclockwise. The scanning speeds up when the shuttle dial is
turned faster.
Jog : In pause mode, if you turn the jog, the point at which the sound is being produced moves by a
number of frames corresponding to the number of clicks. Clockwise moves the point forward;
counterclockwise moves the point backward. In play mode, the jog increases or decreases the speed
of the song. (clockwise : increase , counterclockwise : decrease ).
3. TIME BUTTON
Use this knob to choose the time mode : Elapsed time, remaining time or total remaining time.
4. REPEAT BUTTON
Use this button to repeat one track or all the track of the CD.
5. IN BUTTON ( LOOP SYSTEM )
This button sets the beginning of the loop. The Loop indicator on the display flashes.
6. CONT. / SINGLE BUTTON
Press these to switch between the SINGLE and CONTINUOUS play mode. The selected mode is
indicated on the LCD. In SINGLE mode, after each track, the unit stops the reading. In CONTINUOUS
mode, the unit reads all track and stops.
7. PROG BUTTON
In STOP mode, you can program several tracks ( 20 tracks max. ) :
- Press the STOP button to enter in the stop mode
- Press the PROG button to enter in the program mode
- Use the skip track buttons to choose the track you want to listen then press the PROG button to
enter your choice.
-Use one more time the skip track buttons to choose the track you want to listen then press the PROG
button to enter your choice.
-Repeat the operation to select all the track you want to listen
-Press the play / pause button to start the playback
8. OUT BUTTON ( LOOP SYSTEM )
