Side 1/72
Freezers
Congélateurs
Congeladors
ML24FA
EN Installation, Operation and Maintenance Instructions
FR Instructions d’installation, d’utilisation et d’entretien
ES Instrucciones de instalación, operación y mantenimiento
2
NOTE
!CAUTION
CONTENTS
Contents:
Safety information ...............................................................2
Unpacking your appliance ..................................................3
Warranty registration .....................................................3
Installing your appliance ......................................................4
Cabinet clearances .........................................................4
Leveling the appliance ....................................................4
Electrical connection ......................................................5
Installing the anti-tip device .................................................6
Product Dimensions ...........................................................8
Starting your appliance ..................................................10
Using your Electronic control ............................................10
Sleep mode ...................................................................10
Turning your appliance "ON" or "OFF" ..........................11
Adjusting the temperature .............................................11
Temperature mode ........................................................11
Control lock ....................................................................11
Temperature sensor error codes ...................................12
Alarms ............................................................................12
Door ajar ...................................................................12
Power failure .............................................................13
Temperature alarm ....................................................13
Vacation mode .............................................................13
Overlay door panel installation .........................................14
Shelving congurations .....................................................18
Care and cleaning .............................................................20
Energy saving tips ............................................................20
Obtaining service .............................................................21
Troubleshooting ................................................................22
Warranty ...........................................................................23
!WARNING
State of California Proposition 65 Warning:
This product contains one or more chemicals known
to the State of California to cause cancer.
!WARNING
State of California Proposition 65 Warning:
This product contains one or more chemicals known
to the State of California to cause birth defects or
other reproductive harm..
Important Safety Instructions
Warnings and safety instructions appearing in this guide
are not meant to cover all possible conditions and situa-
tions that may occur. Common sense, caution, and care
must be exercised when installing, maintaining, or operat-
ing this appliance.
Recognize Safety Symbols,
Words, and Labels.
!WARNING
WARNING-You can be killed or seriously injured if
you do not follow these instructions.
CAUTION-Hazards or unsafe practices which could re-
sult in personal injury or property / product damage.
NOTE-Important information to help assure a problem
free installation and operation.
is committed to building a quality product
in an environmentally friendly manner. Our processes are
tightly controlled and closely monitored. We have achieved
certications in ISO 9001 for quality assurance, ISO 14001
for environmental management, and OHSAS 18001 for oc-
cupational health and safety from Lloyd’s Register Quality
Assurance.
Death or serious injury could result if...
3
NOTE
!CAUTION
XXXXXXXXXXXX
XXXXXXXXXXXX
UNPACKING YOUR APPLIANCE
!WARNING
WARNING - Help Prevent Tragedies
Child entrapment and suffocation are not problems of
the past. Junked or abandoned refrigerators are still
dangerous - even if they sit out for "just a few hours".
If you are getting rid of your old refrigerator, please
follow the instructions below to help prevent acci-
dents.
Before you throw away your old refrigerator or
freezer:
• Take off the doors or remove the drawers.
• Leave the shelves in place so children may not
easily climb inside.
!WARNING
WARNING - Dispose of the plastic bags which can
be a suffocation hazard.
Warranty Registration
It is important you send in your warranty registration card
immediately after taking delivery of your appliance or you
can register online at www.agamarvel.com.
The following information will
be required when registering
your appliance.
Service Number
Serial Number
Date of Purchase
Dealer’s name and address
The service number and serial number can be found on the
serial plate which is located inside the cabinet on the left
side near the top. (See gure 1).
!WARNING
EXCESSIVE WEIGHT HAZARD
Use two or more people to move product.
Failure to do so can result in personal injury.
Remove Interior Packaging
Your appliance has been packed for shipment with all parts
that could be damaged by movement securely fastened.
Remove internal packing materials and any tape holding in-
ternal components in place. The owners manual is shipped
inside the product in a plastic bag along with the warranty
registration card, and other accessory items.
Important
Keep your carton and packaging until your appliance has
been thoroughly inspected and found to be in good condi-
tion. If there is damage, the packaging will be needed as
proof of damage in transit. Afterwards please dispose of all
items responsibly.
Note to Customer
This merchandise was carefully packed and thoroughly
inspected before leaving our plant. Responsibility for its
safe delivery was assumed by the retailer upon acceptance
of the shipment. Claims for loss or damage sustained in
transit must be made to the retailer.
DO NOT RETURN DAMAGED MERCHANDISE TO THE
MANUFACTURER - FILE THE CLAIM WITH THE
RETAILER.
If the appliance was shipped, handled, or stored in other
than an upright position for any period of time, allow the ap-
pliance to sit upright for a period of at least 24 hours before
plugging in. This will assure oil returns to the compressor.
Plugging the appliance in immediately may cause damage
to internal parts.
Figure 1
Online registration
available at
www.agamarvel.com
4
!CAUTION
!WARNING
An optional stacking kit is required to stack products.
Failure to use a stacking kit could result in personal
injury. Contact your dealer or Aga Marvel customer
service at 800-223-3900 to order.
Select Location
The proper location will ensure peak performance of your
appliance. We recommend a location where the unit will
be out of direct sunlight and away from heat sources. To
ensure your product performs to specications, the recom-
mended installation location temperature range is from 55
to 100°F (13 to 38°C).
Cabinet Clearance
Ventilation is required from the bottom front of the appli-
ance. Keep this area open and clear of any obstructions.
Adjacent cabinets and counter top can be installed around
the appliance as long as the front grille remains unob-
structed. Overlay door models with articulated hinges are
intended for built-in applications only.
Front Grille
Do not obstruct the front grille. The openings within the
front grille allow air to ow through the condenser heat ex-
changer. Restrictions to this air ow will result in increased
energy usage and loss of cooling capacity. For this reason
it is important this area not be obstructed and the grille
openings kept clean. AGA MARVEL does not recommend
the use of a custom made grille as air ow may be restrict-
ed. (See Figure 2).
Front Leveling
Legs
Figure 2
Rear
Leveling
Legs
Front Grille,
keep this area
open.
INSTALLING YOUR APPLIANCE
Leveling Legs
Adjustable legs at the front and rear corners of the appli-
ance should be set so the unit is rmly positioned on the
oor and level from side to side and front to back. The over-
all height of your Marvel appliance may be adjusted higher
(by turning the leveling leg out, CCW) and lower (by turning
the leveling leg in, CW) dimensions as shown in Table "A".
To adjust the leveling legs, place the appliance on a solid
surface and protect the oor beneath the legs to avoid
scratching the oor. With the assistance of another person,
lean the appliance back to access the front leveling legs.
Raise or lower the legs to the required dimension by turning
the legs. Repeat this process for the rear by tilting the appli-
ance forward using caution. On a level surface check the
appliance for levelness and adjust accordingly.
The front grille screws may be loosened and the grille ad-
justed to the desired height. When adjustment is complete
tighten the two front grille screws. (See Figure 5).
Model Door Style
Minimum
Height
Maximum
Height
ML24* (S) 33 3⁄4"
(85.7 cm)
34 3⁄4"
(88.3 cm)
ML24* (P) 34"
(86.4 cm)
35"
(88.9 cm)
Table A
5
NOTE
Figure 6
Electrical Shock Hazard
• Do not use an extension cord with this appliance.
They can be hazardous and can degrade product
performance.
• This appliance should not, under any circumstanc-
es, be installed to an un-grounded electrical supply.
• Do not remove the grounding prong from the power
cord. (See Figure 3).
• Do not use an adapter. (See Figure 4).
• Do not splash or spray water from a hose on the
appliance. Doing so may cause an electrical shock,
which may result in severe injury or death.
!WARNING
Electrical Connection
A grounded 115 volt, 15 amp dedicated circuit is required.
This product is factory equipped with a power supply
cord that has a three-pronged, grounded plug. It must be
plugged into a mating grounding type receptacle in accor-
dance with the National Electrical Code and applicable lo-
cal codes and ordinances (see Figure 6). If the circuit does
not have a grounding type receptacle, it is the responsibility
and obligation of the customer to provide the proper power
supply. The third ground prong should not, under any cir-
cumstances, be cut or removed.
Ground Fault Circuit Interrupters (GFCI) are prone to nui-
sance tripping which will cause the appliance to shut down.
GFCI’s are generally not used on circuits with power equip-
ment that must run unattended for long periods of time, un-
less required to meet local building codes and ordinances.
Front grille screw
Front grille
Figure 5
INSTALLING YOUR APPLIANCE
Figure 3
Figure 4
Do not remove
ground prong
6
INSTALLING THE ANTI TIP DEVICE
FOR FREESTANDING INSTALLATIONS
!CAUTION
NOTE
Bottom View of
Freezer
Anti-Tip
Bracket Leveling Leg
Front of cabinet
211⁄2"
(54.6 cm)
Figure 7
Floor Mount Installation
The anti-tip bracket is to be located on the oor in the left or
right rear corner of the freezer as shown in Figure 7.
Step by step instructions for locating the
position of the bracket:
1) Decide where you want to place the freezer. Slide it into
place, being careful not to damage the oor, leaving 1" (2.5
cm) of clearance from the rear wall to allow room for the
anti-tip bracket.
2) Raise the rear leveling legs approximately 1⁄ " (6 mm) to 4
allow engagement with the anti-tip bracket. Level the unit
by adjusting all the leveling legs as required. Turning the
leveling leg counterclockwise will raise the unit and clock-
wise will lower the unit.
3) Make sure the freezer is in the desired location, then
mark on the oor the rear and side corner of the cabinet
where the anti-tip bracket will be installed. If the installation
does not allow marking the rear corner of the cabinet, then
make temporary lines on the oor marking the front corner
of the cabinet, excluding the door. Slide the freezer out of
the way. From the temporary line extend the sidewall line
back 21 1⁄ " (54.6 cm) as shown in Figure 8. 2
4) Align the anti-tip bracket to the marks on the oor so
the side of the bracket lines up with the side of the cabinet
mark, and the "V" notches on the anti-tip bracket line up
with the end of the 21 1⁄ " (54.6 cm) line (Rear of cabinet 2
line).
5) Fasten the anti-tip bracket to the oor using the supplied
screw. (See Figure 8).
6) Slide the cabinet back into position, making sure the rear
cabinet leveling leg slides under the anti-tip bracket engag-
ing the slot.
!WARNING
• ALL APPLIANCES CAN TIP
RESULTING IN INJURY.
• INSTALL THE ANTI-TIP
BRACKET PACKED WITH
THE APPLIANCE.
• -FOLLOW THE INSTRUC
TIONS BELOW
Any nished ooring should be protected with appropriate
material to avoid damage when moving the unit.
If installing on a concrete oor, concrete fasteners are
required, (not included with the anti-tip kit).
Anti-Tip Device
!WARNING
If your freezer is not located under a counter top (free
standing), you must use an anti-tip device installed as
per these instructions. If the freezer is removed from
its location for any reason, make sure that the device
is properly engaged with the anti-tip bracket when
you push the freezer back into the original location. If
the device is not properly engaged, there is a risk of
the freezer tipping over, with the potential for property
damage or personal injury.
7
INSTALLING THE ANTI TIP DEVICE
FOR FREESTANDING INSTALLATIONS
211⁄2"
(54.6 cm)
"V" notches
in bracket
"V" notches
in bracket
Side of cabinet line
Figure 8
Front of cabinet line
Rear of cabinet line
Rear Leveling leg
Screw
Figure 8a
NOTE
When the oor mounted anti-tip bracket is used the mini-
mum adjusted height of the cabinet is increased by
3⁄ " (9 mm).8
8
ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS
MODEL "A" "B" "C" "D" "E" "F" "G" "H" "J"
ML24FA(S) 24"
(61 cm)
**34" to 35"
(86.4 to 88.9 cm)
24"
(61 cm)
237⁄8"
(60.7 cm)
333⁄4" to 34 3⁄4"
(85.7 to 88.3 cm)
2323⁄32"
(60.2 cm)
2521 ⁄32"
(65.2 cm)
4613 ⁄32"
(117.9 cm)
2511 ⁄16"
(65.2 cm)
ML24FA(P) 24"
(61 cm)
**34
1⁄4" to 35 1⁄4"
(87 to 89.5 cm)
* 24"
(61 cm)
237⁄8"
(60.7 cm)
34" to 35"
(86.4 to 88.9 cm)
227⁄8"
(58.1 cm) -461⁄2"
(118.1 cm)
231⁄8"
(58.7 cm)
DOOR STYLE
(S) Solid Door
(P) Solid Overlay Door (no handle)
"A"
"B"
"C"
"D"
"E"
If necessary to gain clearance inside the rough-in
opening a hole can be cut through the adjacent cabi-
net and the power cord routed through this hole to a
power outlet. Another way to increase the available
opening depth is to recess the power outlet into the
rear wall to gain the thickness of the power cord plug.
Not all recessed outlet boxes will work for this applica-
tion as they are too narrow, but a recessed outlet box
equivalent to Arlington #DVFR1W is recommended for
this application, (see Figure 10).
PRODUCT DIMENSIONS
Figure 9
Figure 9a
Figure 10
Produkt Specifikationer
| Mærke: | Marvel |
| Kategori: | Fryser |
| Model: | ML24FAS1RS |
Har du brug for hjælp?
Hvis du har brug for hjælp til Marvel ML24FAS1RS stil et spørgsmål nedenfor, og andre brugere vil svare dig
Fryser Marvel Manualer
11 Januar 2025
22 August 2024
22 August 2024
22 August 2024
22 August 2024
22 August 2024
22 August 2024
22 August 2024
22 August 2024
22 August 2024
Fryser Manualer
- Mayer
- Sauber
- Polar
- Molino Home
- Arendo
- Ilve
- Monogram
- Rex
- Cylinda
- AEG-Electrolux
- DPM
- Baumatic
- Midea
- Swan
- Steba
Nyeste Fryser Manualer
21 Juni 2025
21 Juni 2025
21 Juni 2025
21 Juni 2025
21 Juni 2025
21 Juni 2025
21 Juni 2025
21 Juni 2025
21 Juni 2025
21 Juni 2025
