WARNING: IMPROPER CONNECTION OF THE EQUIPMENT-GROUNDING CONDUCTOR CAN
RESULT IN A RISK OF ELECTRIC SHOCK.
• Insert the grounded plug of the power supply cord into wall outlet.
• Start the dryer/blower motor by turning the variable control “clockwise” from off (0) to 100%. The
variable control enables users to “dial in” the EXACT amount of blowing power needed.
o The variable heater control (separate knob) lets users control the level of temperature.
o When using the optional attachment kit RAK-6 (additional part for purchase), the heat
must be in the OFF position.
• To achieve , the motor control must be highest speed and the variable control maximum heat at
heater control must be set to the highest setting, as well.
o The dryer should run for and it will reach maximum heat.5- minutes,8
o In general, we don’t believe in high heat as it can damage the coat or even worse hurt the
o Once the Heating Element reaches max heat, it could take up to 20 minutes to cool down.
Turning the heating element off and running the motor on high speed will help dissipate the
▪ *If you want Low speed and High heat, both knobs must be turned to high first.
Once the desired temperature is reached, you may adjust the speed setting, and
the heating element will remain hot.
• MOTOR BRUSH LIFE IS APPROXIMATELY 500 HOURS. BRUSHES SHOULD BE CHECKED
BETWEEN 200-250 HOUR INTERVALS. FILTER LIFE IS DEPENDENT ON USAGE. CHECK
AND REPLACE WHEN REQUIRED.
ADDITIONAL PARTS FOR PURCHASE (the below items are available for purchase on our website
www.MetroVac.com; use the provided product # in the search):
• Top Gun accessory kit - RAK-6
• 6' standard flexible hose - MVC- C (must be used with MVC-46Q)202
Replacing carbon brushes (ABC-3: should be changed after about 500 hours of use):
2. Find wire going to carbon brush and use flathead screwdriver to loosen tab.
3. Use Philips screwdriver to remove carbon brush mounting bracket.
4. Install tab into new carbon brush and replace mounting bracket.
Replacing / Cleaning Filter (Filter MVC-56F):
1. Pull out filter from backend and replace with new or shake out.
a. You can rinse the filter and reuse, BUT IT MUST BE COMPLETELY DRY BEFORE
PUTTING BACK INTO THE MACHINE.
b. Replace it with a new filter after 3 rinses.
This machine carries a Five Year Limited* Warranty.
The Five Year Warranty includes the unit and the motor.*
