Battery sta at In ll ion

Locking latch

Pull Notch

INSTALLATION INSTRUCTIONS

Name of components

INSTRUCTIONS FOR USE

Instructions for key of remote controller

Considerate Hint:

1. Install the battery with positive side facing up.

2. Effective Range of Remote Control: within 5m

distance and 30-degree deflection in front of

Product.

Press a key on the unit to activate a corresponding function.

For instance:

● Press [OSC.] Key to activate or deactivate Swing Function. (Note:

Manual horizontal blade allows tilting flow direction.)

● Press [SPEED] Key to adjust 3 speeds of air flow.

● Press [STYLE] Key to switch between Normal, Natural and Sleep

Functions.

● Press [TIMER] Key to set 1-12 hour timer setting.

● When [EVA./COOLER] Key is pressed, the indicator lights

up constantly if the operation is normal; when the indicator flashes, it

denotes a water shortage, please add water immediately.

Considerate Hint:

Push Buttons on the unit may differ based on the actual product model.

Front Foot-wheel

Rear Foot-wheel

Foot-Wheel Installation

Air outlet

Control panel

Water window

Water tank

Wheel

Considerate Hint:

● When humidifying, water level in the Water Tank must remain under MAX

indication; replenish water if level gets lower than MIN indication.

● The water level in the tank is below minimum scale marked on water

display window, don’t use the humidification function.

● When the tank water level is lower than the minimum scale, the unit shall

make 3 seconds buzzing warnings sound, then the water pump stop running,

this time need add water to run humidification function.

● When the tank water level exceed the maximum, the unit shall make 10

seconds buzzing warnings sound, to prevent the water in a water flooded

lead to overflow

In case the product cannot be operated normally after installation, checks shall be

made for items described bellow:

1. Power cable unplugged or faulty contact.

2. Honeycomb filter assembly not properly installed.

3. Power Switch on the back of product or in the display panel not switched on.

If product remains dysfunctional after checking, a local dealer shall be sought for

assistance.

Installation of the water tank:

fill water from top

water tank

fill water from bottom

water tank

filter frame

Ice box

Water tank fastener

Take out the water

tank cover from the

fan body

Fix the cover

on the water

tank

Add water from top: Rotate water tank's top cover, fill in water.

Add water from side: Rotate water tank's side cover, fill in water.

Put the ice box

into water tank

Ice box

1. If the supply cord is damaged, it must be replaced by manufacturer

or its service agent or a similarly qualified person in order to avoid a

hazard.

2. Household Indoor use only.

3. This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given

supervisionor instruction concerning use of the appliance by a

person responsiblefor their safety.Young children should be

supervised to ensure that they do not play with the appliance.

4. Unplug the appliance during filling and cleaning.

5. Prior to cleaning or other maintenance, the appliance must be

disconnected from the supply mains.

SAFETY INSTRUCTION

Correct Disposal of this product

This marking indicates that this product should not be

disposed with other household wastes throughout the

EU. To prevent possible harm to the environment or

human health from uncontrolled waste disposal,

recycle it responsibly to promote the sustainable

reuse of material resources. To return your used

device, please use the return and collection systems

or contact the retailer where the product was

purchased. They can take this product for

environmental safe recycling.

Never clean the product with

any abrasive tool or solvent.

Clean with detergent and wipe

dry with cloth immediately.

Never dismantle the product

or attempt to make any

modification. Regular check

and cleaning of the product is

recommended for prolonging

its lifespan.

Make sure power supply is

disconnected before cleaning

the product.

Never wash the unit in water.

For cleaning, remove

components (water tank,

honeycomb filter, etc.) and

clean them with water and soft

brush. Allow them to air-dry

before re-assembling.

INSTRUCTIONS FOR OPERATION OF BODY TROUBLESHOOTING

MAINTENANCE

ADD WATER

373006

INSTALLATION

INSTRUCTIONS

USER GUIDE

Warning notices: Before using this product,

please read this manual carefully and keep

it for future reference. The design and

speciﬁcations are subject to change without

prior notice for product improvement.

Consult with your dealer or manufacturer

for details.

MIDEA

Air Cooler
