Side 1/21

Model: MCT-70QDS, MCT-70QDS-POE, MCT-70HPQ, MCT-70HPQ-POE

Please keep this manual for future reference.

TABLE OF CONTENTS

PAGE

DECLARATION……………....…………………..............……………............…....1

PRODUCT INSTRUCTIONS……….......……..............…………………....………………1

POWERING ON THE PRODUCT………...........………………………...….....….……….2

INSERTING THE SD CARD.....………………….................………………………………3

INSERTING USB DEVICES……………..................……………......…………….……….3

HOME SCREEN.......………..…………….....................………….…......................……4

COMBINED SYSTEM BAR…....................................................................................8

USE APPS............................................................................................................…11

LANGUAGE………………......…............................................................……12

DATE & TIME……………….....….......….............................…...................................13

VOLUME………………......….......….............................…...................................14

WI-FI....................………………......….......….............................................19

ETHERNET....................………………......….......….............................................20

VIRTUAL KEYBOARD....................…....……………......…........................................23

SWITCH INPUT METHODS......................………......….......…................................24

SURF ONLINE................………………......….......….................................................29

BROWSE FILES................………………......….......…...............................................30

PLAY MEDIA................………………......….......…...................................................31

RESET TO FACTORY DEFAULT................………....................................................36

Adapt-IQ 7” User’s Manual

Mimo Monitors

info@mimomonitors.com

Sales: 1-855-YES-MIMO (937-6466)

7N-RK User Manual

Content

Declaration ........................................................................................................................... 0

Product Instruction.............................................................................................................. 1

Power on the Product ........................................................................................................ 2

Insert SD Card .................................................................................................................... 2

Insert USB Devices ............................................................................................................ 2

Home Screen ...................................................................................................................... 3

Combined System Bar ....................................................................................................... 5

Brightness ............................................................................................................................ 8

Use Apps .............................................................................................................................. 8

Language ............................................................................................................................. 9

Date & Time ....................................................................................................................... 10

Volume................................................................................................................................. 11

Wi-Fi ..................................................................................................................................... 11

Ethernet .............................................................................................................................. 12

Virtual Keyboard ............................................................................................................... 13

Switch Input Methods ....................................................................................................... 13

Surf Online ......................................................................................................................... 14

Browse Files ...................................................................................................................... 15

Play Media ......................................................................................................................... 17

Reset to Factory Default .................................................................................................. 17

Declaration

 Please read the instructions carefully before equipment installation and

using the device.

 Do not put the product in high temperature, humid or dusty environment.

 Do not drop, crash or break down this product.

 Do not power off the device when it’s formatting or upgrading, otherwise it

will cause operation system error.

 This product is not waterproof.

 Use only approved add-on enhancements.

Product Instruction

1. Camera (optional): 2M pixel camera

2. LED Indicator:

Red

System is booting.

Green

System is working properly.

Light Off

Power supply is off.

3. SD Card Slot / Cover: support external SD card

4. Escape Button: return to the previous page

5. Function Keys (Up / Down): select the up/down item

6. Function Keys (Vol+ / Vol-): adjust the system volume

7. Speaker: audio output

8. VESA Mount Holes: for installing the bracket

9. DC In Jack: powered by 12V/2A DC input

10. Ethernet RJ45 Port: support Ethernet connection (10/100Mbps LAN)

11. USB Port: support USB 2.0 high speed 480Mbps

12. Micro-USB Port: support USB 2.0 high speed 480Mbps

using the device.

 Do not put the product in high temperature, humid or dusty environment.

 Do not drop, crash or break down this product.

 Do not power off the device when it’s formatting or upgrading, otherwise it

will cause operation system error.

 This product is not waterproof.

 Use only approved add-on enhancements.

Product Instruction

1. Camera (optional): 2M pixel camera

2. LED Indicator:

Red

System is booting.

Green

System is working properly.

Light Off

Power supply is off.

3. SD Card Slot / Cover: support external SD card

4. Escape Button: return to the previous page

5. Function Keys (Up / Down): select the up/down item

6. Function Keys (Vol+ / Vol-): adjust the system volume

7. Speaker: audio output

8. VESA Mount Holes: for installing the bracket

9. DC In Jack: powered by 12V/2A DC input

10. Ethernet RJ45 Port: support Ethernet connection (10/100Mbps LAN)

11. USB Port: support USB 2.0 high speed 480Mbps

12. Micro-USB Port: support USB 2.0 high speed 480Mbps

13. Power Switch: switch power ON/OFF

14. Add-on module slot: to put optional add-on module

15. Headset + Microphone Jack

16. WIFI: 802.11b/g/n/ac 2.4G

17. Temperature：

：

Operation: 0℃ ~ 40℃ ( 32F ~104F)

Storage: -10°C ~ 55°C (14°F ~ 131°F)

Power on the Product

Step1 Power on the power adapter that connected to this product.

Step2 Switch the power switch (#13 in Product Instruction) on the back of

this product to ON.

Insert SD Card

This product supports external SD card. Please insert your SD card into the

SD Card Slot (#3 in Product Instruction) on the top of this product.

Insert USB Devices

This product supports USB and Micro-USB to deal with your files.

USB

Plug your USB memory into the USB port (#11 in Product Instruction) on

the bottom of this product, and then you can do the file operations via the File

Browser. (See the details in Browse Files).

Micro-USB

Connect the Micro-USB port (#12 in Product Instruction) on the bottom of

this product and the USB port on your computer with a Micro-USB-to-USB

cable.

Click the “Turn on USB storage” button in the “USB mass storage” window

that pops up automatically to make the device memory visible in your

computer.

using the device.

 Do not put the product in high temperature, humid or dusty environment.

 Do not drop, crash or break down this product.

 Do not power off the device when it’s formatting or upgrading, otherwise it

will cause operation system error.

 This product is not waterproof.

 Use only approved add-on enhancements.

Product Instruction

1. Camera (optional): 2M pixel camera

2. LED Indicator:

Red

System is booting.

Green

System is working properly.

Light Off

Power supply is off.

3. SD Card Slot / Cover: support external SD card

4. Escape Button: return to the previous page

5. Function Keys (Up / Down): select the up/down item

6. Function Keys (Vol+ / Vol-): adjust the system volume

7. Speaker: audio output

8. VESA Mount Holes: for installing the bracket

9. DC In Jack: powered by 12V/2A DC input

10. Ethernet RJ45 Port: support Ethernet connection (10/100Mbps LAN)

11. USB Port: support USB 2.0 high speed 480Mbps

12. Micro-USB Port: support USB 2.0 high speed 480Mbps

Produkt Specifikationer

Mærke:	Mimo Monitors
Kategori:	overvåge
Model:	Adapt-IQ MCT-70QDS
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Produktfarve:	Sort
Skærm diagonal:	7 "
Skærmopløsning:	1024 x 600 pixel
Berøringsskærm:	Ja
Kompatible hukommelseskort:	SD, SDHC
Wi-Fi:	Ja
Bluetooth:	Ja
USB-port:	Ja
HD-type:	XGA
Skærmteknologi:	LCD
Naturligt aspektforhold:	16:9
Skærmens lysstyrke:	250 cd/m²
Indbyggede højttaler(e):	Ja
Opbevaringstemperatur (T-T):	-15 - 65 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	10 - 90 %
Udgangseffekt (RMS):	2 W
DVI-port:	Ingen
Ethernet LAN-porte (RJ-45):	1
Ethernet LAN:	Ja
Processorkerner:	4
Understøttede videoformater:	3GP, ASF, AVI, DAT, FLV, MKV, MOV, MP4, RM, TS, VOB, WMV
Understøttede lydformater:	AAC, ASF, MP2, OGG, WAV, WMA
VESA montering:	Ja
Panel montering grænseflade:	75 x 75 mm
Strømforbrug (standby):	- W
Strømforbrug (typisk):	7.5 W
Driftstemperatur (T-T):	-10 - 50 °C
Ethernet LAN-datahastigheder:	10, 100 Mbit/s
Intern hukommelse:	2 GB
Operativsystem installeret:	Android 5.1
Bluetooth-version:	4.0
Understøttede billedformater:	BMP, GIF, JPG
Certificering:	FCC, CE, & RoHS
DC-in-stik:	Ja
Indbygget kortlæser:	Ja
LED-baggrundsbelysning:	Ja
Antal indbyggede højttalere:	2
Indbygget kamera:	Ja
USB version:	2.0
Understøttet placering:	Indendørs
Antal USB-porte:	1
Indgangsspænding:	5 V
Processorfrekvens:	1.6 GHz
Processorserie:	ARM Cortex
Formål:	Universel
Intern lagerkapacitet:	8 GB
Kontrastforhold (typisk):	700:1
Gennemsnitstid mellem fejl (MTBF):	30000 t
Indbygget processer:	Ja
Produktdesign:	Digital fladpaneldisplay
Computersystem:	Ja
Antal simultane touchpunkter:	5
Berøringsskærm teknologi:	Kapacitiv
Multi-touch:	Ja
Skærmbredde:	207 mm
Skærm, dybde:	23 mm
Skærm, højde:	120 mm
Skærm, vægt:	450 g
Antal displays:	1
