Solar Charging System Controller

Installation, Operation and Maintenance Manual

www.morningstarcorp.com

EcoBoost MPPT

MAXIMUM POWER POINT TRACKING

For the most recent manual revisions, see the version at:

www.morningstarcorp.com

MODELS

EB-MPPT-20 EB-MPPT-20M

EB-MPPT-30 EB-MPPT-30M

EB-MPPT-40 EB-MPPT-40M

EcoBoost MPPT Operator’s Manual

iii

SPECIFICATION SUMMARY

EB-MPPT-20 EB-MPPT-30 EB-MPPT-40

Nominal Battery

Voltage

12/24V 12/24V 12/24V

Max. PV Open-

Circuit Voltage*

120V 120V 120V

Nominal Max.

InputPower**

300 / 600W 400 / 800W

560 /

1120W

Max. Battery

Charging Current

20A 30A 40A

Rated Load Current 20A 30A 30A

DIMENSIONS (centimeters)

TABLE OF CONTENTS

1.0 Important Safety Instructions ........................... 1

2.0 General Information

.... .................................... ... 5

2.1 Overview

................................................................5

2.2

Features

................................................................. 6

2.3 Optional Accessories

..............................................8

3.0 Installation ..............................................................9

3.1 General Installation Notes

.......................................9

3.2 Configuration

........................................................11

3.3 Mounting

..............................................................14

3.4 Wiring

..................................................................15

4.0 Operation ............................................................ 23

4.1 TrakStar MPPT Technology ......................................23

4.2 Battery Charging Information ..................................23

4.3 Load Control Information ....................................... 26

4.4 LED Indications......................................... .... .........28

4.4.1 Power-up....................................................... ...........28

4.4.2 Status LED.............................................................. 28

4.4.3 State-of-charge LEDs...............................................29

4.5 Alarms......................................................................29

4.6 Custom Settings.......................................................31

4.6.1 Adjusting Set-points with Meter Display................ 31

4.6.2 Meter Display Operation......................................... 32

4.6.2.1 Directional Key Use and Operation / Navigating

the Meter Map........................................................32

4.6.2.2 Adjusting the Meter Display................................. .32

4.7 Data Logging (future use).......................................32

4.8 Auxilliary USB Charging..........................................33

4.9 Inspection and Maintenance...................................33

Continued...

*Array voltage should never exceed this limit

**These power levels refer to the maximum wattage the EcoBoost MPPT

can process. Higher power arrays can be used without damaging the

controller.

(

14.8 )

( 17.0 )

( 19.6 )

(

18.1

)

(

7.1

)

Produkt Specifikationer

Mærke:	Morningstar
Kategori:	Ikke kategoriseret
Model:	EcoBoost MPPT
Kode for international beskyttelse (IP):	IP20
Bredde:	196 mm
Dybde:	71 mm
Højde:	173 mm
Vægt:	1400 g
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	0 - 100 %
Driftstemperatur (T-T):	-40 - 60 °C
Certificering:	CE, TUV Listed: IEC 62109, EN 62109-1, Emissions 55014-1, Immunity 55014-2
Ladespænding:	- V
Strømbeskyttelsesfunktioner:	Overheating, Overload, Short circuit
Opladningsstrøm:	30 A
