Side 1/94

Title page

User Guide

MIDI Express XT

MIDI Express 128

micro express

micro lite

1280 Massachusetts Avenue

Cambridge, MA 02138

Business voice: (617) 576-2760

Business fax: (617) 576-3609

Web site: www.motu.com

Tech support: www.motu.com/support

SAFETY PRECAUTIONS AND ELECTRICAL REQUIREMENTS

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR

OTHER MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE

PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING: DO NOT PERMIT FINGERS TO TOUCH THE TERMINALS OF PLUGS WHEN INSTALLING OR REMOVING

THE PLUG TO OR FROM THE OUTLET.

WARNING: IF NOT PROPERLY GROUNDED THE MOTU USB MIDI interface COULD CAUSE AN ELECTRICAL SHOCK.

The MOTU USB MIDI interface is equipped with a three-conductor cord and grounding type plug which has a grounding prong,

approved by Underwriters' Laboratories and the Canadian Standards Association. This plug requires a mating three-conductor

grounded type outlet as shown in Figure A below.

If the outlet you are planning to use for the MOTU USB MIDI interface is of the two prong type, DO NOT REMOVE OR ALTER THE

GROUNDING PRONG IN ANY MANNER. Use an adapter as shown below and always connect the grounding lug to a known

ground. It is recommended that you have a qualiﬁed electrician replace the TWO prong outlet with a properly grounded THREE prong

outlet. An adapter as illustrated below in Figure B is available for connecting plugs to two-prong receptacles.

WARNING: THE GREEN GROUNDING LUG EXTENDING FROM THE ADAPTER MUST BE CONNECTED TO A

PERMANENT GROUND SUCH AS TO A PROPERLY GROUNDED OUTLET BOX. NOT ALL OUTLET BOXES ARE

PROPERLY GROUNDED.

If you are not sure that your outlet box is properly grounded, have it checked by a qualiﬁed electrician. NOTE: The adapter illustrated is

for use only if you already have a properly grounded two-prong receptacle. Adapter is not allowed in Canada by the Canadian

Electrical Code. Use only three wire extension cords which have three-prong grounding type plugs and three-prong receptacles which

will accept the MOTU USB MIDI interface plug.

IMPORTANT SAFEGUARDS

1. Read instructions - All the safety and operating instructions should be read before operating the MOTU USB MIDI interface.

2. Retain instructions - The safety instructions and owner's manual should be retained for future reference.

3. Heed Warnings - All warnings on the MOTU USB MIDI interface and in the owner's manual should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Cleaning - Unplug the MOTU USB MIDI interface from the computer before cleaning and use a damp cloth. Do not use liquid or

aerosol cleaners.

6. Overloading - Do not overload wall outlets and extension cords as this can result in a risk of ﬁre or electrical shock.

7. Power Sources - This MOTU USB MIDI interface should be operated only from the type of power source indicated on the marking

label. If you are not sure of the type of power supply to your location, consult your local power company.

8. Power-Cord Protection - Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed

upon or against them. Pay particular attention to cords and plugs, convenience receptacles, and the point where they exit from the

MOTU USB MIDI interface.

9. Lightning - For added protection for the MOTU USB MIDI interface during a lightning storm, unplug it from the wall outlet. This will

prevent damage to the MOTU USB MIDI interface due to lightning and power line surges.

10. Servicing - Do not attempt to service this MOTU USB MIDI interface yourself as opening or removing covers will expose you to

dangerous voltage and other hazards. Refer all servicing to qualiﬁed service personnel.

11. Damage Requiring Service - Unplug the MOTU USB MIDI interface from the computer and refer servicing to qualiﬁed service

personnel under the following conditions.

a. When the power supply cord or plug is damaged.

b. If liquid has been spilled or objects have fallen into the MOTU USB MIDI interface.

c. If the MOTU USB MIDI interface has been exposed to rain or water.

d. If the MOTU USB MIDI interface does not operate normally by following the operating instructions in the owner's manual.

e. If the MOTU USB MIDI interface has been dropped or the cabinet has been damaged.

f. When the MOTU USB MIDI interface exhibits a distinct change in performance, this indicates a need for service.

12. Replacement Parts - When replacement parts are required, be sure the service technician has used replacement parts speciﬁed by

the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in ﬁre, electric shock or

other hazards.

13. Safety Check - Upon completion of any service or repairs to this MOTU USB MIDI interface, ask the service technician to perform

safety checks to determine that the product is in safe operating conditions.

ENVIRONMENT

Operating Temperature: 10°C to 40°C (50°F to 104°)

AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE

Do not handle the power cord with wet hands. Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by

the plug.

INPUT

Line Voltage: 100 - 120 volts AC, RMS (US and Japan) or 220 - 250 volts AC, RMS (Europe). Frequency: 47 - 63 Hz single phase.

Power: 7 watts maximum.

CAUTION: DANGER OF EXPLOSION IF BATTERY IS REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT

TYPE RECOMMENDED BYMANUFACTURER. DISPOSE OF USED BATTERY ACCORDING TO MANUFACTURER’S

INSTRUCTIONS.

3-prong plug

Grounding prong

Properly grounded 3-prong outlet

Grounding lug

Screw

3-prong plug

Adapter

Make sure this is connected to a

known ground.

Two-prong receptacle

Figure A

Figure B

Produkt Specifikationer

Mærke:	Motu
Kategori:	Midi-keyboard
Model:	Micro Lite
Bredde:	241.3 mm
Dybde:	177.8 mm
Højde:	44.5 mm
Produktfarve:	Sort
Formfaktor:	Rack monteret
Strømkilde:	USB
Enhedsgrænseflade:	USB
Antal USB-porte:	1
Lydindgang:	MIDI
Lydudgang:	MIDI
MIDI udgang:	Ja
MIDI indgang:	Ja
