Side 1/2

(release button)

PWR (Power button)

9/ button (Skip forward)

7/MOD button

SEL/VOL knob (Audio/Volume)

AMS/SCH button (Automatic stor-

ing)

TA button (Trafﬁ c alarm)

LCD display

USB slot

AUX in jack

0/DSP button (Display time)

6/DIR+ button (Directory up)

5/DIR- button (Directory down)

4/RDM button (Random)

3/RPT button (Repeat)

2/INT button (Intro)

1/PAU button (Pause)

BAND/LOUD button

PTY button (Program type select-

ing)

EQ button (equalizer)

8/ (skip backward)

AF button (Alternative Frequency)

Reset button

SD/MMC slot

Do not attempt to modify the unit, modifying the unit may cause an accident.

Installation or servicing of the unit by persons without training and experience in

electronic equipment and automotive accessories may be dangerous and could

expose you to the risk of electric shock or other hazards.

Stop the vehicle before carrying out any operation that could interfere with your

driving.

Keep the volume at a level which you could hear sounds from outside the vehicle.

Do not work in extremely high or low temperature. Be sure the temperature inside

the vehicle is between +60°C and -10°C before turning on your unit.

When replacing the fuse(s), the replacement must be of the same amperage as

shown on the fuse holder.

Do not block vents or radiator panels. Blocking them will cause heat to build up

inside and may result in ﬁ re.

Using this unit without running the engine can result in battery drainage

Use only in cars with a 12 volt negative ground.

After completing the installation and beginning to play the unit(including replacing

the battery), please remove the front panel at ﬁ rst, and then press RESET button

on the base with pointed object (such as ball-point pen) to set the unit to initial

status.

10.

11.

12.

13.

14.

15.

16.

17.

18.

19.

20.

21.

22.

23.

24.

10.

M-098 MR

GB - 1

User Manual

CAR RADIO WITH USB & SD/MMC

Please read the instruction carefully before

operating the unit

PRECAUTIONS

English GB - 2 GB - 3

1. Antenna Receptacle

2. Line out Right (red)

3. Line out Left (white)

4. Output plug (male)

5. Output plug (female)

6. FUSE holder (15 A)

Caution!

- Make sure to connect the color coded leads according to the diagram. Incorrect

connections may cause the unit to malfunction or damage the vehicle’s electrical system.

- Make sure to connect the speaker (-) leads to the speaker (-) terminal. Never

connect the left and right channel speaker cables each other or to the vehicle body.

- Make sure all the connections are completely correct before turning on your unit.

Do not connect the ignition wire (red) and the battery wire (yellow), it may cause a short circuit,

even result in ﬁ re.

Install the unit

- Method 1: DIN Front-Mount

1. Remove the outer trim frame

GB - 4 GB - 5

Install the front panel

Put notch A (Shown as picture) onto shaft B. And then slightly press into the right side.

Note: Never put any objects into the front panel.

3. Insert the keys supplied to the unit at the both sides of the unit (shown as illustrated)

until they click. Pulling the keys and makes them to remove the unit from the dash-

board.

GB - 6

LOCATION OF CONTROLS

Front panel

Base

When you unpack your new car radio, make sure that you have removed all the acces-

sories and information papers:

Main unit with connector

User manual

Accessories:

- Method 2 DIN Rear-mount (For Japanese car)

BASIC OPERATION

Turning on/oﬀ the unit

Press button (2) to turn on the unit. Press this button again to turn off the unit.PWR

Selecting the mode

After the unit is on, press MOD (4) button to select different sourcing mode: Radio

USB SD/MMC AUX

CONNECTION INSTALL AND DETACH THE UNIT

SOUND FEATURES

Setting the Sound Characteristics:

Repeatedly press knob (5) to select the desired mode in the following order: SEL/ VOL

“BAS” (Bass) -> “TRE” (Treble) -> “BAL” (Balance) -> “FAD“ (Fade) -> “TA VOL“ (TA

volume) ->”REG” (REG ON /OFF) -> “LOC” (LOC ON/ OFF) ->STEREO/ MONO ->

“VOL” (Volume). After selecting the desired mode, you can adjust the current level by

rotating the knob (5). SEL/ VOL

Note: -The unit will return to the precious mode if no adjusting within 3 seconds.

- Refer to radio section for REG, LOC and STEREO/MONO.

Time displaying

Press DSP button (11) to show the current time on display

Adjust time: Long press DSP (11) until clock time with ﬂ ashing hour digits appears.

Then Press and button to adjust the hour value and press DSP (11) to conﬁ rm.

Then minute digits ﬂ ash. Press and button to adjust the minute value and

press DSP (11) to conﬁ rm

Reset the unit

Operating the unit for the ﬁ rst time or after replacing the car battery, you must reset the

unit. To set the unit to initial status, press button (23) located on the base with RESET

a pointed object. When some errors occur in display, you can also reset the unit, but it

will erase the clock setting and some memorized functions.

Volume adjusting:

To increase or decrease the sound level, rotate knob (5) clockwise or SEL/VOL

anti-clockwise.

Preset equalizer

When you are listening to popular music, classic music or rock music, using EQ func-

tion to select relative status can adjust the sound quality perfectly. Repeatedly press

EQ (20) to select different equalizer mode in following order: FLAT->POP->ROCK

->CLASS -> EQ off.

Loudness On/oﬀ

Press and hold BAND/LOUD button (18) until “LOUD ON” shows on display to acti-

vate LOUD function. By this function, you can increase the low frequency, which can

improve sound sensitivity. Press and hold this button again until “LOUD OFF”to cancel

LOUD function.

Information display

- In case of receiving a RDS station.

The display will show: CT -> FREQ -> PTY -> PS

-In case of not receiving a RDS station

The display will show: CT -> FREQ -> NO PTY -> NO PS

Note: It will return to normal play mode if no key is pressed within 5 seconds.

1 2 3 5 6 74

8 9 11 1210

UNPACK YOUR UNIT

2. Select a position where the screw holes of the mounting bracket supplied with the

car and the screw holes of the main unit become aligned (are ﬁ tted).

Detach the Front Panel

Press button in the upper left corner, and then the front panel will be folded down.

When the front panel was turned down to the angle of 45°, hold and push the front

panel to left, and then pull it out.

Detach the Unit

1. Detach the front panel. (Please refer to upper part)

2. Take out the outer trim frame.

GB - 7

LISTENING TO THE RADIO

Selecting band

In tuner mode, repeatedly press BAND/ LOUD button (18) to select bands in

following order: FM1->FM2->FM3.

Manual/automatic tuning

- Manual Tuning

Press and hold button or (3/21) until “MANUAL” shows on display, then press

button or (3/21) continuously to select a station downward or upward. Press

and hold button or (3/21)to tune the station with a faster speed.

- Automatic Tuning

Press or (3/21) once, the radio automatically searches a station upward or

downward respectively and plays when it ﬁ nds a station. Press or (3/21)once to

stop scanning.

23 24

1 2

3 5 6 8 97

21 20 19 18 17 16 15 14 13 12 11 10

M5 X 21

3. Tighten the screws. And then fasten them to the car.

AR-3043 IB MUSE 001 REV0 GB.indd1 1

AR-3043 IB MUSE 001 REV0 GB.indd1 1AR-3043 IB MUSE 001 REV0 GB.indd1 1 2011-3-4 17:27:28

2011-3-4 17:27:28

2011-3-4 17:27:282011-3-4 17:27:28

Produkt Specifikationer

Mærke:	Muse
Kategori:	Bilradio
Model:	M-098 MR
Vægt:	530 g
Produktfarve:	Sort, sølv
Indbygget skærm:	Ja
Pakkevægt:	820 g
Pakkedybde:	90 mm
Pakkebredde:	219 mm
Pakkehøjde:	204 mm
Kompatible hukommelseskort:	MMC, SD, SDHC
Bluetooth:	Ingen
USB-port:	Ja
Equalizer:	Ja
Understøttede lydformater:	MP3
Volumenkontrol:	Dreje
Linie-udgang (RCA):	2
Dimensioner (BxDxH):	134 x 188 x 59 mm
Udgangseffekt:	40 W
Understøttede disktyper:	Ingen
Indbygget kortlæser:	Ja
USB version:	2.0
Antal USB-porte:	1
AUX-indgang:	Ja
Understøttede radiobånd:	FM, PLL
RDS Tuner inkluderet:	Ja
MP3-afspilning:	Ja
Direkte USB-afspilning:	Ja
CD-R-afspilning:	Ingen
CD-RW-afspilning:	Ingen
Skærmlys:	Ja
Antal forudindstillede stationer:	18
Aftageligt frontpanel:	Ja
Afspilning af DVD-lyd:	Ingen
