8495 Dalton Road, Mount Royal, Quebec, Canada. H4T 1V5

Tel: (514) 905-0588 Fax: (514) 905- 0589

Toll Free (North America): (877) 689- 5228

E-mail: videoease@muxlab.com URL: www.muxlab.com

Specications

Environment

HDMI 1.3a

Devices

DVD, plasma, projectors, monitors, TV, PC, laptops, servers supporting HDMI.

Transmission

Transparent to the user

Video Bandwidth

225MHz

Signals

HDMI 1.3a protocol

Connectors

One (1) HDMI receptacle.

One (1) RJ45S for Cat 5e/6 unshielded or shielded twisted pair.

One (1) 3.5mm jacks for IR emitter/sensor.

Four (4) DIP Switches for device ID addressing.

Note: HDMI cables not included.

Maximum Distance

Based on a maximum length

of 6.6ft ( m) of HDMI cable

per end.

Cat5e/6: 330ft (100m) up to 1080P

Note: When installed in an electrically noisy environment, an STP cable must be

used. Also, cross-connection reduces the eective distance depending on the

grade of twisted cable used.

Latency

One (1) Frame

Compression

Motion JPEG

Network Bandwidth

60Mbps

Network Requirement

100BaseT for Point to Point; 0BaseT for other configuration 100

IR Frequency

38 to 56KHz

RJ45 Pin Conguration

Reverse Polarity Sensitive.

Use EIA/TIA 568A or 586B

straight-through wiring.

RJ45 Link

Pin 1 (R) Pin 2 (T)

Pin 3 (R) Pin 6 (T)

Pin 4 (R) Pin 5 (T)

Pin 7 (R) Pin 8 (T)

Cable

One (1) Cat 5e/6 or better twisted pair cables required

Power Source

This device supports PoE (PD), an external power supply is not included. It is

intended to be powered via a PoE (PSE) Ethernet Switch. If required, an optional

power supply (500992) may be purchased separately.

PoE

IEEE 802.3af

Power Consumption

Transmitter: 2.9Watt Receiver: 1.8Watt

Temperature

Operating: 0° to 40°C Storage: -20° to 85°C

Humidity: Up to 95% non-condensing

Enclosure

Metal

Dimensions

3.70” x 3.68” x 0.97” (94 x 93.5 x 24.6mm)

Weight

1.1lbs (0.5kg)

Compliance

Regulatory: FCC, CE, RoHS Flammability: 94V0

Warranty

3 years

Order Information

500752 HDMI Over IP Extender Kit with PoE

500752-TX HDMI Over IP Encoder with PoE

500752-RX HDMI Over IP Decoder with PoE

Accessories

(These items are sold

separately)

500990 IR Emitter, and 500991 IR Sensor

500992 Univ. Power Supply 5VD 1.2A US/UK/EU Blade C/

HDMI over IP Extender Kit with PoE

500752

Quick Installation Guide

Overview

The HDMI over IP Extender Kit with PoE (500752) allows HDMI equipment to be connected up to

330ft (100m) @ 1080p via one (1) Cat5e/6 unshielded twisted pair cable in a point- -point to

conguration. Point- -multipoint and multipoint- -multipoint is possible by connecting several to to

Transmitters and Receivers to the same Ethernet network. The Transmitter (500752-TX) and

Receiver (500752-RX) also support PoE (PD) if used with a PoE (PSE) Ethernet Switch. The kit

comes with one (1) Transmitter and one (1) Receiver. The IR Emitter and IR Sensor, if required,

may be purchased separately for IR based remote control applications.

For the point- -multipoint and multipoint- -multipoint conguration the Ethernet Switch must to to

have Gigabit ports and DHCP Server capability and additionally support the IGMP communication

protocol for the multipoint- -multipoint case. MuxLab recommends using the Cisco SG300 to

Series Managed Switches.

The MuxLab ProDigital Network Controller (500811) is available to simplify the conguration and

utilization of the 500752 and other MuxLab IP based products via an Ethernet web interface.

Applications

Applications include commercial and residential AV systems, classroom projector systems, digital

signage, boardroom systems, collaborative PC systems, and medical information systems.

Installation

1. Identify the connectors on the Transmitter and Receiver as indicated on the product labels.

2. Verify that the distance between the HDMI Transmitter and Receiver is within MuxLab

specications (see Specications table for further details ).

3. To install the Transmitter:

3a. Connect the Transmitter to the HDMI video source with an HDMI compliant cable.

3b. If the application is point- -point, then connect one (1) length of Cat 5e/6 (or to

higher) grade UTP cable to the RJ45 LINK connector on the Transmitter. If

transmitting over the network, use an Ethernet Switch between the TX & RX unit.

4. To install the Receiver:

4a. Connect the Receiver to the HDMI display equipment with an HDMI compliant cable.

4b. If the application is point- -point, then connect one (1) Cat 5e/6 cable (or higher) to

coming from the Transmitter, to the RJ45 LINK connector on the Receiver. If

transmitting over the network, use an Ethernet Switch between the TX & RX unit.

5. If the conguration is a point- -multipoint or multipoint- -multipoint: to to

5a. You will need to use an Ethernet Switch with Gigabit ports and DHCP Server support.

In addition IGMP Protocol support is required for the multipoint- -multipoint case. to

Verify that the Ethernet Switch is congured correctly and that the DHCP Server

is enabled and that the IGMP Protocol enabled for multipoint- -multipoint is to

applications. See the operating manual for more information about conguring the

Ethernet Switch.

5b. Connect all Transmitters and Receivers to the Ethernet Switch.

5c. Use the DIP Switches to select a unique Device ID for each Transmitter present on the

network and congure each Receiver Device ID to the corresponding selected

Transmitter.

Note: This step is not necessary if the MuxLab ProDigital Network Controller (500811)

is used.

6. Powering the Transmitter or Receiver via an external power supply is only necessary where

PoE (PSE) is unavailable. If PoE is unavailable, connect the 5 VDC power supply (sold

separately) to each Receiver and to an AC power outlet. Next connect each Transmitter in the

same manner. If power is present, the green power LED on each Transmitter and Receiver

will illuminate.

Note: Power the HDMI over IP Extender only after all connections have been ‘ON’

made.

7. Power the HDMI equipment and verify the image quality. ‘ON’

8. This product supports IR pass-thru control. If infrared remote control is needed to control the

Source equipment from the Display, connect the IR Sensor (sold separately) to the 3.5mm

Stereo Jack of the Receiver and the IR Emitter (sold separately) to the 3.5mm Mono Jack of

the Transmitter.

Note: You can differentiate the IR Sensor and the IR Emitter by looking at the 3.5 mm

plug. The IR Sensor is using a Stereo Plug (3 Contacts) and the IR Emitter a

mono plug (2 Contacts).

9. Position the IR Sensor so that it is directed the hand-held remote control. For a clear IR at

signal reception, aim the hand-held remote control to the top of the IR Sensor enclosure.

10. Position the IR Emitter as close as possible to the source’s IR Sensor (i.e. DVD player). For a

clear IR signal reception, the IR Emitter can be glued on the source’s IR Sensor. The IR

Emitter’s signal is transmitted from the side of the enclosure.

11. The following diagram illustrates a typical point- -point LAN conguration.to

Troubleshooting

The following table describes some of the symptoms, probable causes and possible solutions in regard to

the installation of the HDMI over IP Extender Kit with PoE:

Symptom

Encoder LEDs

Decoder LEDs

Probable

Cause

Possible

Solutions

Power

Link

Power

Link

No Image

OFF

No power

• Check power connections

• Check PoE Ethernet Switch

Setup

No Image

OFF

Internal Error

• Reboot the Transmitter unit.

No Image

OFF

Internal Error

• Reboot the Receiver unit.

No Image

UTP Cable

• Check the Receiver UTP

cable.

No Image

BLINK

UTP Cable

• Check the Transmitter UTP

cable.

No Image

BLINK

HDMI Cable

• Check the HDMI Cable

Quality.

Choppy Image

BLINK

Ethernet Switch

• For Multipoint- -Multipoint to

enable the IGMP mode on the

Gigabit Ethernet Switch.

Choppy sound

BLINK

Synchronization

• Check cable length

• Check the HDMI Cable

Qualit y.

Image ickers

when powering

up nearby

equipment

BLINK

Interference

• Use STP cables

IR not

functioning *

BLINK

Remote control

not directed to

the IR Sensor or

IR Emitter not

directed to the

source.

• Make sure the IR Sensor is

directed towards the remote

and the IR Emitter to the

equipment.

IR not

functioning *

BLINK

Interference

from sunlight,

Fluorescent,

Neon or

Halogen lights

• Place the IR equipment away

for the interfering light

IR not

functioning *

BLINK

Interference

from RF

radiation from

the TV

• Place the IR equipment away

for the RF radiation

* IR Emitter and IR Sensor sold separately.

If you still cannot diagnose the problem, please call MuxLab Customer Technical Support at 877- -689

5228 (toll-free in North America) or (+1) 514- -0588 (International). 905
