Side 1/2

PC-CL200FR

Model No. : BB5038

Made in China

MULTIMEDIA FUNCTIONS

Your NACON CL-200 keyboard features several hot keys for common multimedia functions. These are located on

the function key section F5 – F12 and can be accessed by pressing the FN key and the according function key. The

functions are:

Fn + F5 : Media player – Stop playback

Fn + F6 : Media player – Skip to previous track

Fn + F7 : Media player – Playback / Pause

Fn + F8 : Media player – Skip to next track

Fn + F9 : Media player – Volume mute

Fn + F10 : Media player – Volume -

Fn + F11 : Media player – Volume +

Fn + F12 : WinLock (see “Lockable Windows key (WinLock)”)

RECYCLING

This product should not be disposed of in normal household rubbish. Please take it to a nominated collection point.

Recycling is important and will help to protect our environment from reduced landﬁ ll waste.

IMPORTANT SAFEGUARDS & PRECAUTIONS

1. This Unit is for indoor use only. Never expose to direct sunlight or wet weather conditions.

2. Do not expose the unit, to splashing, dripping, rain or moisture. Do not immerse in liquid.

3. Do not expose to dust, high humidity, high temperatures or mechanical shock.

4. Do not use if the equipment is damaged.

5. Do not disassemble; there are no serviceable parts inside.

6. For external cleaning, use a soft, clean, damp cloth only. Use of detergents may damage the ﬁ nish and leak inside.

ERGONOMICS

Holding your hand in the same position for a longer period of time can lead to aching and pain. If this occurs repeatedly

please consult your doctor.

• As a precaution we recommend that you take a 15 minute break every hour.

TECHNICAL SPECIFICATION

• USB keyboard

• 5 V, max. 200 mA power consumption

• Weight: 690 g

• Height x Width x Depth: 193 mm x 462 mm x 32 mm

TECHNICAL HELPLINE INFORMATION

For UK support contact: support@bigben.fr

LEGAL LINES

Windows

XP/VISTA

/7/8/10 are registered trademarks of Microsoft Corporation.

Thank you for purchasing this NACON product. In case of a malfunction please refer to the support information at

the end of this manual. We highly appreciate any feedback which helps us to improve our products. Please keep this

instruction manual for future reference.

WARRANTY

This product bearing the NACON trademark, is guaranteed by the manufacturer for a period of 1 year from the date

of purchase, and will, during this period, be replaced with the same or a similar model, at our option, free of charge if

there is a defect due to faulty material or workmanship. This guarantee does not cover defects arising from accidental

damage, misuse or wear and tear and is available only to the original purchaser of the product. This does not aﬀ ect your

statutory rights.

PRODUCT SPECIFICATIONS

• Gaming keyboard with 104/105 keys

• 5 dedicated macro keys

• Hardware based “on-the-ﬂ y” macro recording

• Up to 3 gaming proﬁ les

• WinLock function

• Blue backlighting (static or with pulse eﬀ ect)

• USB cable (app. 1.5m)

• Compatible with Windows 2000/XP/Vista/7/8/10

CONTENTS OF THE PACKAGE

• NACON CL-200 gaming keyboard

CONTROL ELEMENTS

1. Dedicated macro keys M1 – M5

2. Proﬁ le selection keys P1 – P3

3. Macro recording key MR

4. WINLOCK key

5. Function key FN

6. MULTIMEDIA Functions

7. Backlight control

8. Windows key

INSTALLATION

The NACON CL-200 is a plug’n’play device. This means no additional driver software is needed to operate it. Simply

insert the plug of your new keyboard into one of the free USB sockets of your computer and after some seconds the

keyboard should be operational.

LOCKABLE WINDOWS KEY (WINLOCK)

By default pressing the Windows key (8) the start menu will appear on your screen. If you´re in the middle of your game,

accidently pressing this key would therefore result in leaving your active game. To prevent this, you can deactivate this

function by pressing the WinLock (4) key.

LED CONTROLS

Your NACON CL-200 keyboard features backlit keys for enhanced gameplay in dark environments. You can control

the brightness of the LEDs or turn them completely oﬀ , by pressing [FN] and [ESC] simultaneously (7). The order of the

settings are:

Backlight oﬀ – dimmed – bright – bright with pulse eﬀ ect.

MACRO AND PROFILE KEYS

Macros are recordings of singular or a sequence of key presses. Usually these are regularly used in certain games or

applications, so it’s convenient to have them tied to one key and ﬁ re them up when needed.

Your NACON CL-200 features 5 dedicated macro keys, labeled M1 to M5 (1) which are located on the top of the

keyboard. After you have set up a macro and assigned it to one of those keys, you can execute it directly by pressing the

according key.

To record a macro ﬁ rst press [MR] (the WIN LED will start to ﬂ ash red), then press the macro key you the macro to be

recorded for. The WIN LED will now be constantly lit. Now enter the desired key sequence and save it by pressing [MR]

again.

Your NACON CL-200 also features three proﬁ les. Each proﬁ le can store its own set of ﬁ ve macro keys, backlight setting

and WINLOCK status. If you want to store your macros to a speciﬁ c proﬁ le, you need to press the corresponding key (P1

to P3) ﬁ rst, in order to activate that proﬁ le. NOTE: Final keys may change, waiting for conﬁ rmation.

oNACON

GAMING KEYBOARD

PC-CL200

BB5038

Produkt Specifikationer

Mærke:	Nacon
Kategori:	Tastatur
Model:	PCCL-200BE
Produktfarve:	Sort
Pakkevægt:	1160 g
Pakkedybde:	490 mm
Pakkebredde:	40 mm
Pakkehøjde:	220 mm
Formfaktor:	Højre hånd
Antal:	1
Pakketype:	Kasse
Anbefalet brug:	Spil
Forbindelsesteknologi:	Ledningsført
Pallens bruttobredde:	800 mm
Pallens bruttolængde:	1200 mm
Pallens bruttohøjde:	1800 mm
Produkter pr. palle:	240 stk
Strømkilde type:	USB
Kabellængde:	1.5 m
Baggrundsfarve:	Blå
Enhedsgrænseflade:	USB
Pegeredskab:	Ingen
Numerisk tastatur:	Ja
Formål:	PC/server
Hovedkassen højde (udvendigt):	245 mm
Hovedkassens længde (udvendigt):	500 mm
Hovedkassens bruttovægt (udvendigt):	12590 g
Hovedkassens bredde (udvendigt):	390 mm
Baggrundslys:	Ja
Type af baggrundslys:	LED
Produkter pr. hovedkasse (udvendigt):	10 stk
Tastatursprog:	Belgisk
Tastatur formfaktor:	Fuld størrelse (100 %)
Tastatur dimensioner (BxDxH):	480 x 215 x 35 mm
Tastatur vægt:	980 g
Tastatur stil:	Lige
Håndledsstøtte:	Ingen
Mus inkluderet:	Ingen
Fingeraftrykslæser:	Ingen
Tastaturopsætning:	AZERTY
Windows taster:	Ja
Pallens bruttovægt:	307000 g
USB stik:	Ingen
Antal programmeringsprofiler:	3
Antal programmerbare (makro) nøgler:	5
