RECEIVING AND INSPECTION

Immediately upon receipt of a shipment, carefully inspect for

damage and shortage. Turn impeller by hand to see that it

turns freely and does not bind. If any damage and/or shortage

is detected or suspected, the carrier must be asked to conduct

an inspection. The consignees representative should not accept

shipment without a notation on the delivery receipt indicating items

not delivered or apparent extent of damage.

When a shipment is opened and damage is found which was not

evident externally (concealed damage), it is mandatory that the

consignee request an immediate inspection by the carrier. Report

damage to the carrier within 15 days. Failure to report damage

within the above time limit will cause rejection of a claim.

HANDLING

When handling fans and their accessories, always use equipment

and methods that will not cause damage. Fans should be lifted

using slings and padding or spreaders to avoid damage.

CAUTION! Always make sure that all lifting and handling equipment

and techniques conform to current safety standards.

Avoid lifting fans in a way that will bend or distort fan parts. Never

pass slings or timbers through the orices of fan.

CAUTION! Do not lift by the fan hood. Fans with special coatings

or paints must be protected in handling to prevent damage.

STORAGE

Fans are protected against damage during shipment. If they

cannot be installed and put into operation immediately upon receipt

certain precautions are necessary to prevent deterioration during

storage. Responsibility for integrity of fans and accessories during

storage must be assumed by the user. The manufacturer will not

be responsible for damage during storage. These suggestions are

provided solely as a convenience to the user, who shall make his

own decision as to whether to use any or all of them.

INDOOR: The ideal storage environment for fans and accessories

is indoors, above grade, in a low humidity atmosphere which

is sealed to prevent the entry of blowing dust, rain, or snow.

Temperatures should be evenly maintained at between 70°F and

105°F (wide temperature swings may cause condensation and

“sweating” of metal parts). Windows should be covered to prevent

temperature variations caused by sunlight. Provide thermometers

and humidity indicators at several points and maintain the

atmosphere at 40% relative humidity, or lower.

It maybe necessary to use trays of renewable desiccant or portable

dehumidier to remove moisture from the air in the storage

enclosure.

Thermostatically controlled portable heaters (vented to outdoors)

may be required to maintain even temperatures inside the

enclosure.

CAUTION! Provide re extinguishers, or re alarms, or emergency

response communication to protect building and equipment against

re damage. Be sure that building and storage practices meet all

local, state and federal re and safety codes.

The following fans or accessories must be stored indoors, in a

clean dry atmosphere:

a. Any fan that is protected by a cardboard carton.

b. Spare wheels or propellers.

c. Boxes, bags or cartons of hardware.

d. Curbs

e. Dampers

Remove any accumulations of dirt, water, ice or snow and wipe

dry before moving indoor storage. Allow cold parts to reach room

temperature to avoid “sweating” of metal parts. Open boxes

or cartons. Remove any accumulated moisture; if necessary

use portable electric heaters to dry parts and packages. Leave

coverings loose to permit air circulation and to permit periodic

inspection.

Rotate wheels or propellers by hand to distribute bearing grease

over the entire bearing surfaces.

Store at least 3 ½” off the oor on wooden blocks covered with

moisture proof paper or polyethylene sheathing. Provide aisles

between parts and along all walls, to permit air circulation and

space for inspection.

OUTDOOR: Fans designed for outdoor use may be stored

outdoors, if absolutely necessary. The storage area should be

reasonably level and drained or ditched to prevent accumulation

of water. Fencing and lighting for security are desirable. Roads

or aisles for portable cranes and hauling equipment are needed.

Consider the use of drift fencing to minimize accumulation of

blowing snow or dirt.

The following fans may be stored outdoors, if dry indoor storage

space is not available:

a. Fans intended for outdoor use that are crated in wood.

b. Wall fans installed in wall housings.

All fans must be supported on wooden blocks or timbers above

water or normal snow levels. Provide enough blocking to prevent

settling into soft ground. Fans should be set in place using the

directional arrow markings on the crate as a guide.

Locate pieces far enough apart to permit air circulation, sunlight,

and space for periodic inspection. Place all parts on their supports

so that rain water will run off, or to minimize water accumulation. Do

not cover parts with plastic lm or tarps-these cause condensation

of moisture from the air passing through heating and cooling

cycles.

Fan wheels and propellers should be blocked to prevent spinning

caused by strong winds.

Read and Save These Instructions

NAKS Form 613157

INSTALLATION & MAINTENANCE INSTRUCTIONS

Direct Drive Exhaust Fans

______________________________________________________________________________________________________________________________

2017 © North American Kitchen Solutions

172 Reaser Court

Elyria, OH 44035

www.naksinc.com

Page 1 of 7
