Naxa NSH-1000 Manual

Naxa Ikke kategoriseret NSH-1000

Læs gratis den danske manual til Naxa NSH-1000 (1 sider) i kategorien Ikke kategoriseret. Denne vejledning er vurderet som hjælpsom af 76 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 38.5 anmeldelser. Har du et spørgsmål om Naxa NSH-1000, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/1

Wi-Fi Smart Plug

NSH-1000

User Manual

Using Google Assistant™

What’s in the Box

Note: The On/Off button can be used as a restore button. Hold it

to change the flashing speed and it will restore your smart plug to

its factory settings. Only do this if you are sure you want to erase

all of your settings.

Model Number: NSH-1000

Rated Voltage: 100-240V

Rated Current: 10 A (Max.)

AC Frequency: 50~60Hz

Working Temperature: -10 ~ 60° C

Wi-Fi: Frequency: 2.4 GHz

Total Power Output (Max.): 2200W

1. You can download the Smart Life app from the Google Play

Store™, Apple App Store™, or by scanning the QR code.

2. To register an account, input your email address or phone

number. If you choose to enter your phone number, a verification

code will be texted to you. No registration code is necessary via

email.

The Smart Life app is free. It is also compatible with mobile

devices that support iOS 8.0 and above, as well as Android 4.4

and above

A. Easy Mode (Recommended)

1. Make sure Easy Mode configuration is initiated: the indicator

light blinks rapidly (twice per second) when in Easy Mode. If the

light blinks slowly (once every two seconds), press and hold the

power button on the Smart Plug for 6 seconds, until the indicator

light begins to blink rapidly.

2. Tap the “+” icon in the upper right-hand corner of the Smart Life

app screen and choose your device type (Electrical Outlet) to add

the device.

3. Follow the in-app instructions to connect the Smart Plug to your

Wi-Fi network.

4. Once connected, the connection will prompt in the Smart Life

app. Click “Done”.

5. Now you may control the Smart Plug through the Smart Life

app.

B. AP Mode

1. Make sure AP Mode configuration is initiated: the indicator light

blinks slowly (once every two seconds) when in AP Mode. If not in

AP Mode, press and hold the power button on the Smart Plug for

6 seconds until the indicator light blinks slowly.

2. Tap the icon “+” in the upper right-hand corner of the Smart Life

app screen and select the device type (Electrical Outlet).

3. Click “AP Mode” in the top right-hand corner of the “Add

Device” tab to add the device.

4. Follow the in-app instructions to connect the Smart Plug to your

Wi-Fi network.

5. Once connected, the connection will prompt on the Smart Life

app. Click “Done”

6. You may now control the Smart Plug through the Smart Life app.

A. Devices

You can add devices to Smart Life by tapping the “+” icon in the

upper right-hand corner of the screen.

1. Switches

Switches allows you to turn your device on or off from anywhere.

As long as you have an internet connection, you can control the

device in your home.

Tap the icon in the upper right-hand corner of the page to access

the ability to modify the device’s name or even create a group, if

you have several smart devices, which means you can turn

mulitple devices on or off at the same time.

2. Timer

You can set your smart devices on or off at specific times at your

convenience with this function.

3. Countdown

With the countdown timer feature, you can automatically turn on

or off your household appliances

B. Scenes

With this function, you can create characteristics as you want.

C. Profile

Profile is where users can manage personal information, as

shown below:

The Smart Plug is recommended for use only indoors and in a dry

location. The power outlet should be used within it’s published

outlet rating, as detailed in the instructions.

Please contact the seller for a replacement if there is any damage

caused by transportation.

Please plug the Smart Plug into the outlet in proper condition, and

away from children.

Please plug into the outlet fully, while using caution for safety.

Please do not disassemble the Smart Plug, as it may cause

damage to the device or cause a safety concern.

1. Sign in to your Amazon Alexa account. If you do not have an

account, you must first download the Alexa app from the Google

Play Store™ or Apple App Store™. Once downloaded, register an

account.

2. After logging in, choose the local Wi-Fi network you wish to

operate from.

3. Choose the Skills option in the option bar and search for “Smart

Life” in the search bar.

4. Select “Smart Life” in the results, and click “Enable”

5. Input the user name and password you registered with. A

prompt will appear to tell you that Alexa™ has successfully been

linked with Smart Life.

Note: For further details regarding setting up smart devices on the

Alexa app, refer to the Amazon website.

You can also choose to voice control your Smart Plug via the Google

Assistant app. To set up, follow these steps:

1. Sign in to your Google Home™ account. If you do not have an

account, you must first download the Alexa app from the Google

Play Store™ or Apple App Store™. Once downloaded, register an

account.

2. After logging in, choose the local Wi-Fi network you wish to

operate from.

3. Choose the Skills option in the option bar and search for

“Smart Life” in the search bar.

4. Select “Smart Life” in the results, and click “Enable”

5. Input the user name and password you registered with. A

prompt will appear to tell you that Google Home has successfully

been linked with Smart Life.

Note: For further details regarding setting up smart devices on the

Google Home app, refer to the Google website.

1. Discovering devices: First, you need to discover the device

that has been linked via Smart Life on your Alexa or Google

Home app.

2. Once the device has been discovered, you will be notified of

a successful discovery.

3. You may now operate your plug by voice, saying “Hey Alexa”

or “Ok Google”.

4. Supported Skill List

You can control devices as detailed below:

“Alexa, turn on (Fridge Socket)”

“Alexa, turn off (Fridge Socket)”

Note: The name of the device must be consistent

with the addition of the Smart Life app.

This Wi-Fi Smart Plug is covered by a limited warranty from

NAXA for the original purchaser that covers the product from

defects in workmanship and materials for 12 months from the

date of purchase (damages through normal wear and tear,

aleration, misuse, neglect, accident, service by anyone other

than the authorized service center, or act of God are not

included).

During the warranty period and upon verification of defects, this

product will be replaced when returned with proper proof of

purchase.

If you have problems with your device, please consult the

instructions in this manual. Please also visit us on the web at

www.naxa.com to get the latest news, alerts, and

documentation for your device. For additional assistance,

please contact Naxa Technical Support.

NAXA Technical Support

230 East 49th St.

Vernon, CA 90058

Trademark & Regulatory Statements

Google Home™, Google Assistant™, and the Google Play Store™ and all Google

Brand Features are trademarks or distinctive brand features of Google Inc., LLC.

The Apple App Store™ is a trademark of Appl Inc.

"Amazon, Alexa, and all related logos are trademarks of Amazon.com, Inc. or its

affiliates.

At a Glance

Wi-Fi Smart Plug x 1

User Manual x 1

1. Socket Panel

2. Flame-Resistant Material

3.On/Off Button

4. Power Plug

Parameters

Installing the “Smart Life” App

Connecting Your Smart Plug

Getting to Know “Smart Life”

Safety Information

Using Amazon Alexa™

Controlling Your Smart Plug

After linking Amazon Alexa or Google Home to Smart Life, you will be

able to control your Smart Plug using just your voice.

Warranty

Support

You can also choose to voice control your Smart Plug via the Amazon

Alexa app. To set up, follow these steps:

Produkt Specifikationer

Mærke:	Naxa
Kategori:	Ikke kategoriseret
Model:	NSH-1000
Bredde:	48 mm
Dybde:	51 mm
Højde:	48 mm
Vægt:	54 g
Brugervejledning:	Ja
Produktfarve:	Hvid
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Forbindelsesteknologi:	Trådløs
Certificering:	ETL and FCC
Fungerer med Google Assistant:	Ja
Fungerer med Amazon Alexa:	Ja
Fjernbetjent:	Ja
Maksimal indgangseffekt:	- W
Understøttet placering:	Indendørs
Trådløs teknologi:	Wi-Fi
Hovedkassen højde (udvendigt):	297 mm
Hovedkassens længde (udvendigt):	361 mm
Hovedkassens bruttovægt (udvendigt):	1991 g
Hovedkassens bredde (udvendigt):	91 mm
Produkter pr. hovedkasse (udvendigt):	10 stk
Frekvens:	2400 MHz
Strøm (maks.):	10 A
