Side 1/4
© Nicolaudie Group 1989-2021. All rights reserved. We reserve the right without notice to amend the technical information and specifications.
DINA-DR2/LITE
DIN rail mounted DMX lighting controller
http://www.nicolaudie.com/dina-dr2.htm
Overview
e DINA-DR2 is built on the latest generation
lighting controllers from Nicolaudie
chitectural and combines all our recent
e DINA-DR2 is the perfect solution for mid-
nge lighting installations. Delivered with
24 DMX channels (512 for DINA-DR2 LITE), the
ntroller can be upgraded to 1536 by adding
3rd DMX universe.
e lighting levels, color and effects can be
ogrammed from a PC, Mac, Android, iPad or
hone using software from our website .
Key Features
• DMX Stand Alone controller
• Up to 3 x DMX512 universes (1536 channels)
• RDM compatible
• USB & Ethernet connectivity for programming/
control
• Stand Alone mode with 99 scenes
• Play scenes in 5 areas / zones
• microSD slot
• 8+3 dry contact trigger ports
• Test scenes rotary switch
• Windows/Mac software to set dynamic colors/
effects
• iPhone/iPad/Android remote and programming
apps
• SUT Technology allows the device to be used
with other Nicolaudie Group software via an
online upgrade
• LS cloud compatibility (optional with DINA-DR2
LITE)
Technical Data
Input Power 12v DC (8-15V range)
Output Protocol DMX512 (x3)
Programmability PC, Mac, Android, iOS
Connections USB-C
Ethernet
Screw terminals for :
- 3 DMX / RDM Universes
- 8+3 Contact ports
- 12v power-in
Battery holder (CR2032)
microSD slot
Memory SD Card
Environment IP20 / to 0 to +50°C
Buttons Rotary switch
Dim / Weight 160 x 91 x 62 mm 317g
OS Requirements Mac OS X 10.8-10.14
Windows 7/8/10
Standards CE, ETL, Low voltage, EMC,
and RoHS
Optional Accessories
POWER 12V AC/DC power supply
V 0.1
Dry contact ports
input
DC
input
Ethernet
DMX connectors
Up to 3 universes
(1536 channels)
Extra dry con-
tact ports
Rotary switch
microSD
(32Gb Max)
ndicators
LIR2032 3.6v
Rechargeable
battery Holder
1-digit
DISPLAY
www.nicolaudie.com
DIN rail mounted DMX lighting controller
DINA-DR2
© Nicolaudie Group 1989-2020. All rights reserved. We reserve the right without notice to amend the technical information and specifications.
Technical datasheet Revision date 3 Feb 2021
Connections
