BAYCO • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • www.baycoproducts.com

Model 4620 / 4622 Flashlight Instructions

Multiple Patents Pending

INS-4620-12

CAUTION: DO NOT use in explosive atmospheres, near flammable liquids,

or where explosion proof lamps are required

DO NOT use in the proximity of vehicles or equipment when there is a risk of flammable

liquids coming into contact with the hand-lamp

CAUTION: For Light Duty Use Only

WARNING: NOT FOR USE ABOVE HAZARDOUS LOCATIONS

Thank you for purchasing this Nightstick flashlight. Save these instructions.

Please read these instructions before using your flashlight.

INSTALLING BATTERIES

1. Remove the battery compartment cap located on the bottom of the flashlight. Unscrew

the cap by using a coin or similar shaped tool by inserting the coin into the cap slot

and rotating counter-clockwise until the cap separates from the flashlight body.

2. Insert the batteries as shown in the illustration. Observe the correct polarity of the

batteries.

3. Insert the battery cap back into the light and tighten the cap using the coin, turn in a

clockwise direction.

4. The flashlight is now ready for use.

BATTERY NOTES

 Batteries may lose power when stored for long periods.

 Alkaline batteries can leak and cause corrosion if stored for long periods. Always

remove batteries if the light will be unused for extended periods.

 Batteries should be stored between 68-78°F (20-25°C)

SAFETY

CAUTION BRIGHT LED RADIATION: AVOID DIRECT EYE EXPOSURE. The light is a

Class 2 LED product per IEC 60825-1 Edition 1.2.2001.

 Do not use this FLASHLIGHT in explosive or hazardous areas.

O-RING MAINTENANCE

1. O-rings should be cleaned with a soft clean cloth to insure that the sealing area is free

of dirt, dust or foreign matter that could destroy the waterproof seal.

2. Apply a light coat of clear silicone grease on the O-ring to extend the life of the O-ring.

OPERATION

Both models have two body switches that control the flashlight and the floodlight. The

flashlight and floodlight functions can be operated independently and together.

1. The upper switch controls the flashlight. Lightly press the switch for momentary

flashlight operation. For constant on, press the switch until it clicks. Press again for

off.

2. The lower switch controls the floodlight. Press for full power. Press again for half-

power. Press again to turn off.

3. For dual-light (flashlight & floodlight) operation, press the flashlight and the floodlight

buttons.

IMPACT BUMPERS & CLIP MAGNET

Install the orange impact bumpers on the top and bottom of the flashlight. The closed

bumper goes on the bottom of the flashlight.

For hands-free lighting attach the clip-magnet to the flashlight body.

WARRANTY

Limited Lifetime Warranty

Product is warranted to be free from defects in workmanship and materials for the

lifetime of the original owner. Includes the housing, lenses, electronics and switches.

Batteries, normal wear and abuse are excluded.

Not Covered

Consequential damages, incidental damages or incidental expenses, including damage

to property. Some states do not allow the exclusion or limitation of incidental or

consequential damages, so the above limitation or exclusion may not apply to you. This

warranty gives you specific legal rights, which may vary from state to state.

Warranty Claims - USA

Contact Bayco for USA warranty claims. Call 800-233-2155 or email

cs@baycoproducts.com and Bayco Customer Service will provide a Return Goods

Authorization (RGA) to facilitate rapid warranty action. After receiving the RGA, send the

product (shipping prepaid) to BAYCO • 640 S. SANDEN BLVD • WYLIE, TEXAS • 75098.

Include a dated proof of purchase and a brief description of the defect with your name,

address and phone number. Your product will either be repaired or replaced at the option

of Bayco and returned as soon as practical, but no later than 45 days after being

received by Bayco.

Warranty questions and international claims

If you live outside the USA or have questions about this warranty or an inquiry about

other Bayco products contact BAYCO • 640 S. SANDEN BLVD • WYLIE, TEXAS • 75098

or call 800-233-2155

Instructions Modèle Lampe de poche 4620/4622

Brevets multiples en attente

ATTENTION: NE PAS utiliser des lampes dans des atmosphères explosives, à proximité

de liquides inflammables, ou lorsque l'épreuve des explosions sont nécessaires

NE PAS utiliser à proximité de véhicules ou d'équipement quand il p1-ya un risque de

liquides inflammables d'entrer en contact avec la main-lampe

ATTENTION: Pour Light Duty Utilisez uniquement

AVERTISSEMENT: NE PAS UTILISER POUR CI-DESSUS DES ENDROITS

DANGEREUX

Merci d'avoir acheté cette lampe de poche Nightstick. Conservez ces instructions.

S'il vous plaît lire attentivement ces instructions avant d'utiliser votre lampe de poche.

INSTALLATION DES PILES

1. Retirez le couvercle du compartiment à piles situé sur le bas de la lampe de poche.

Dévisser le bouchon à l'aide d'une pièce ou un outil similaire en forme par l'insertion

de la pièce dans la fente capuchon et en rotation anti-horaire jusqu'à ce que le

bouchon se sépare du corps lampe de poche.

2. Insérez les piles comme indiqué dans l'illustration. Respectez la polarité des piles.

3. Insérez le capuchon de la pile de retour dans la lumière et serrer le bouchon à l'aide

de la pièce, tournant le sens horaire.

4. La lampe de poche est maintenant prêt à l'emploi.

REMARQUES SUR LA BATTERIE

 Les batteries peuvent perdre de la puissance lorsqu'il est stocké pendant de longues

périodes.

 Les piles alcalines peuvent fuir et provoquer la corrosion s'il est stocké pendant de

longues périodes. Toujours retirer les piles si la lumière ne sera pas utilisée pendant

de longues périodes.
