Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com

INS-T460XL-K01-21

Instruction Manual

TAC-460XL-K01

WARNINGS

y NOT FOR USE IN HAZARDOUS LOCATIONS. Do not use this product in explosive

atmospheres, near  ammable liquids, or where explosion proof or intrinsically safe lighting

is required.

y DO NOT use this product in the proximity of vehicles or equipment when there is a risk

of  ammable liquids coming into contact with the  ashlight.

y Light can become hot while on. To prevent damage DO NOT cover or place next to any

potentially  ammable materials while in use.

y Keep out of reach of children.

ASSEMBLY INSTRUCTIONS

The TAC-460XL includes the tail cap switch already attached. The light can be used

immediately as a hand-held tactical  ashlight once the included batteries and CR123 battery

carrier are installed. The light may be converted back to this con guration at any time.

1. Remove the tail cap switch (Figure 1-A) and the CR123 battery carrier (Figure 1-B).

NOTE: Keep the tail cap switch for future use so the light can be converted back to a

conventional hand-held tactical  ashlight in the future.

2. Install the two included CR123 batteries (Figure 2-A) into the battery carrier (Figure 2-B).

The positive terminals on each battery should be oriented in the direction of the arrow on

the battery carrier and then inserted into the  ashlight with the + end terminals pointing

in the direction of the  ashlight’s bezel (Figure 3-A).

3. Install the Remote Pressure Switch (RPS) cap and tighten into place (Figure 3-B).

4. Test the operation of the RPS (Figure 3-C) and the side switch (Figure 3-D). See section

titled Operation for how the switches work.

5. Determine location of the rail mount on the body of the light. Keep the mount clear of the

switch cap, otherwise changing the batteries will require removing the mount.

6. Once the location of the mount has been determined, loosen the screws using the

supplied Allen wrench and slide the mount onto the handle of the light (Figure 4).

Partially tighten the screws.

7. Test  t the rail mount on to the Picatinny or Weaver rail of the long gun. Determine the

desired location of the RPS (Figure 6) on the long gun. It can be attached to any clean,

dry,  at surface. Figure 6 is one example; choose the best location for your weapon’s

con guration and personal preferences.

8. Finish tightening the mount screws, alternating between each a small amount at a time

until the gap is equal on both sides (Figure 4).

9. Once the location of the mount and the RPS have been determined, thoroughly clean

the location on the weapon where the RPS will be located as well as the inside surface

of the RPS using the supplied alcohol swab.

10. Peel off the paper backing on one side of the Velcro

adhesive strip and press it into

place on the back side of the RPS (Figure 5).

11. Attach the light with mount onto the rail of the weapon and tighten the thumb screw.

12. Peel off the paper backing on the other side of the Velcro

adhesive strip and press it

onto onto the clean area of the long gun. (Figure 6).

IMPORTANT: Allow 24 hours for the adhesive to make a semi-permanent bond. Do not

move or remove the adhesive strips or separate the two Velcro

sections once they have been

placed until the adhesive is cured.

OPERATION

The Nightstick Tactical Long Gun Kit is now fully installed and ready for use.

The RPS provides momentary On/Off operation of the light only. Using this switch, gives

the operator full and instant control over when the light is on or off.

The side switch on the tail cap provides momentary On/Off operation by pressing slightly

on the button, or constant-on by pressing until the button clicks.

If the mount has been positioned correctly, changing the batteries may be accomplished

without removing the light from the weapon.

To change the batteries,  rst separate the two halves of the Velcro from each other so

that one half stays adhered to the weapon and the other remains attached to the back side

of the RPS. Next unscrew the tail cap, remove the CR123 battery carrier and replace the

batteries (see Step 2 above).

WARRANTY

LIMITED LIFETIME WARRANTY

Bayco Products, Inc. warrants this product to be free from defects in workmanship and

materials for the original purchaser’s lifetime. The Limited Lifetime Warranty includes the

LEDs, housing and lenses. Rechargeable batteries, chargers, switches, electronics and

included accessories are warranted for a period of two years with proof of purchase. Normal

wear and failures which are caused by accidents, misuse, abuse, faulty installation and

lightning damage are excluded.

We will repair or replace this product should we determine it to be defective. This is the

only warranty, expressed or implied, including any warranty of merchantability or  tness for

a particular purpose.

For a complete copy of the warranty, go to www.baycoproducts.com/bayco-product-

support/warranties. Retain your receipt for proof of purchase.

Mode d’emploi

TAC-460XL-K01

AVERTISSEMENTS

y NE PAS UTILISER DANS DES ENDROITS DANGEREUX. Ne pas utiliser ce produit

dans des atmosphères explosibles, à proximité de liquides in ammables, ou un endroit

antidé agrant ou un emplacement dont un éclairage à sécurité intrinsèque est requis.

y NE PAS utiliser ce produit à proximité de véhicules ou équipements quand il y a risque

de liquides in ammables entrant en contact avec la lampe de poche.

y La lumière peut être chaude lorsqu’elle est allumée. Pour éviter tout dommage NE PAS

couvrir ou placer à proximité de matériaux potentiellement in ammables pendant qu’elle

est allumée.

y Garder hors de la portée des enfants.

INSTRUCTIONS DE MONTAGE

La lampe torche tactique TAC-460XL est fournie avec le capuchon arrière déjà en place.

La torche peut donc être utilisée dès que vous la sortez de son emballage en tant que lampe

torche tactique conventionnelle une fois que les batteries CR123 et le porte-batterie CR123

inclus sont en place. La con guration de cette torche peut être changée à tout moment.

1. Enlevez l’interrupteur du capuchon arrière (illustration 1-A) et le porte-batterie CR123

(illustration 1-B). REMARQUE : Conservez le commutateur du capuchon arrière pour

utilisation ultérieure au cas où vous voudriez réutiliser cette torche en tant que lampe

torche tactique conventionnelle.

2. Installez les deux batteries CR123 comprises (illustration 2-A) dans le porte-batterie

Figure 6Figure 5Figure 4
