BAYCO • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 00+1+ 469-326-9400 • www.baycoproducts.com

Operating Instructions for Models

NSR-9910 / 9912 / 9914

Flashlight • Floodlight • Dual-Light • Strobe

Rechargeable Personal / Patrol Size Flashlight

Multiple Patents Pending

INS-9910-12B

CAUTION: DO NOT use in explosive atmospheres, near flammable liquids,

or where explosion proof lamps are required

DO NOT use in the proximity of vehicles or equipment when there is a risk of flammable

liquids coming into contact with the flashlight.

WARNING: NOT FOR USE ABOVE HAZARDOUS LOCATIONS

Thank you for selecting this Nightstick product. Save this instruction.

Please read these instructions before using your Nightstick. It includes

important safety and operation information. Be sure to charge the Nightstick

fully before the first use. A battery is fully charged when the charger light is

green.

Record the serial number and

date of purchase in the space

provided on the back. Then

for warranty coverage. See

information below.

Record the serial number and

date of purchase in the space

provided below.. Then register

your Nightstick online for

warranty coverage. See

information below.

Items in the box

CHARGING

Initial Use

Fully charge the Nightstick before the first use. If the battery is new or has been

unused for several months, several charge and discharge cycles may be

needed to reach full battery capacity. To reach maximum performance, run the

light to completely discharge the battery and then recharge. Each charge cycle

will extend the operation time until maximum capacity is achieved. The charge

time for maximum capacity is approximately 3 hours.

Regular Use

Use only the supplied Nightstick charge platform, battery and AC or DC

adapter. The maximum allowable DC input is 15VDC.

 For best performance, charge the Nightstick when the LED’s start to dim.

 Connect the AC power adapter to the charging platform. The green

indicator will light.

 With the floodlight facing forward, slide the Nightstick into the charging

platform until the contacts snap into place.

 The red light on the charging platform indicates the Nightstick is properly

inserted into the charging platform and charging. The light remains red until

the battery is fully charged. At full charge, the light turns green. The total

time to full charge varies depending on the remaining charge in the battery

pack.

 The charging platform provides a trickle charge to a fully charged battery

pack.

PERFORMANCE ALL MODELS

SAFETY

CAUTION BRIGHT LED RADIATION: AVOID DIRECT EYE EXPOSURE.

Nightstick is a Class 2 LED product per IEC 60825-1 Edition 1.2.2001.

 Do not use or charge this Nightstick in explosive or hazardous areas.

 Do not attempt to repair or disassemble the Nightstick, the charger

platform, battery or the power supply.

 Use only the Nightstick charging platform, AC or DC adapters and battery

pack.

 Using this Nightstick product for other than a lighting device is not

recommended. Bayco specifically disclaims liability for other than intended

use.

OPERATION of NSR-9910 / 9912 / 9914

There are two Nightstick product configurations. Both have the Flashlight •

Floodlight • Dual-Light • Strobe modes. For maximum user safety the flashlight

and floodlight can operate simultaneously in the Dual-Light mode. The strobe

flashes at approximately 2 flashes per second.

 NSR-9910 / 9912: Single body switch

 NSR-9914: Dual-Switches. Tandem control.

NSR-9910 / 9912 - Single body switch

The five light modes are controlled by the body switch. After being in any mode

longer than 3/4 second: The next press turns the light OFF. The strobe-light

function overrides any other mode. Strobe is accessed from any mode. Lightly

press the body switch for momentary flashlight operation.

First Press – Flashlight On

Second Press – Floodlight On

Third Press – Dual-light On

Fourth Press – All Off

Press and Hold– Strobe On

Press Again – Strobe Off

NSR-9914 – Dual Switches. Tandem control

The five light modes are identical to the NSR-9910 / 12 and controlled by either

the body or tail switch. Lightly press the body or tail switch for momentary

flashlight operation.

LIGHT MODE

NiMH Lithium CR123

Lumens

Run-time

Hrs

Lumens

Run-time

Hrs

FLASHLIGHT • Momentary

220 5 220

FLASHLIGHT • Constant

220 5 220

FLOODLIGHT • Constant

180 5 180

DUAL-LIGHT • Flashlight &

Floodli

230 5 230 2

FLASHLIGHT STROBE

220 16 220
