EC11

Features

· Utilizes CREE XM-L2 (U2) LED

· Maximum output of 900 lumens

· Integrated “Precision Digital Optics Technology” provides extreme reflector performance

· Boasts a peak beam intensity of 9000 cd and a throw distance of up to 190 meters

· Dual-switch design ensures unprecedented ease of use

· Secondary red LED provides constant / flashing illumination

· Indicates battery voltage with a red flashing LED (accurate to 0.1V)

· High efficiency constant current circuit enables maximum runtime of up to 20 hours

· Direct access to ultra-low and turbo output

· Reverse polarity protection prevents damage from an incorrectly inserted battery

· Detachable anti-rolling clip

· Toughened ultra-clear mineral glass with anti-reflective coating

· Constructed from aero grade aluminum alloy

· HAIII military grade hard-anodized

· Waterproof in accordance with IPX-8 (2 meters submersible)

· Impact resistant to 1.5 meters

· Tail stand capability

Dimensions

Length: 2.95” (75mm)

Head diameter: 1” (25.4mm)

Tail diameter: 1” (25.4mm)

Weight: 1.60oz (45.3 gram) (without battery)

Instant Ultra-low Output

With the light switched off, press and hold the ON/OFF button for more than one second to

access ultra-low mode (1 lumen).

Instant Turbo Output

With the light switched off, press and hold the MODE button for more than one second to access

turbo mode (900 lumens).

NOTE: When in turbo mode, the EC11 will adjust output luminance automatically within 3 minutes

of use to prevent overheating and extend battery longevity.

Red Light / Signal Light Mode

With the light switched off, press the MODE button to enter red light mode. In this mode, the

secondary red LED will illuminate steadily.

When in red light mode, press and hold the MODE button for more than one second to enter

signal light mode. In this mode, the secondary red LED will flash to serve as a signal light.

Simply press any button to exit the red light /signal light mode.

Special modes (Strobe/Location/SOS)

With the light switched on, press and hold the MODE button for more than one second to enter

Strobe mode. When in strobe mode, press and hold the MODE button for more than one second

again to cycle through Location Beacon, SOS and Strobe modes. To exit, simple press the MODE

button to resume the last used brightness level, or press the ON/OFF button to switch the

light off.

Strobe Ready

With the light switched off, press the MODE button twice in quick succession to enter Strobe

mode. To exit, simply press any button.

Lockout / Unlock

With the light switched on, press and hold the ON/OFF button and the MODE button

simultaneously for over one second to switch the light off and enter lockout mode. In lockout mode,

the EC11 conserves battery power for over 170 days; the two buttons on EC11 will not work, thus

preventing accidental activation of the light. To exit lockout mode, simply press and hold the

ON/OFF button and the MODE button simultaneously for over one second again.

NOTE:

1. When entering lockout mode, the secondary red LED will continuously flash to indicate battery

voltage. Please refer to the “Power Tips” section for more details.

2. When the EC11 is kept in a backpack or left unused for extended periods, Nitecore recommends

the tailcap is loosened or battery is removed to cut off the power entirely, thus preventing

accidental activation of the flashlight or battery leakage.

Power Tips

After battery installation or lockout mode activation, the secondary red LED will flash to indicate

battery voltage (accurate to 0.1V). For example, when battery voltage is at 4.2V, the red LED will

flash 4 times, followed by a one second pause and another 2 flashes. Different voltages represent

the corresponding remaining battery power levels:

Output & Runtime

NOTICE:

The stated data has been measured in accordance with the international flashlight testing

standards ANSI/NEMA FL1, using 1 x high quality IMR18350 battery (3.7V 700mAh) or 1 x

Nitecore CR123 battery (3V 1700mAh) under laboratory conditions. The data may vary during

real-world use due to different battery usage or environmental conditions

Operating Instructions

Battery installation

Insert one (R)CR123 battery or one IMR18350 battery as illustrated

NOTE: After loading the battery, the secondary red LED will flash to indicate

battery voltage. Please refer to the “Power Tips” section of this manual for

details.

WARNING:

1. Ensure the battery is inserted with the positive (+) end pointing towards the

head. The EC11 will not be operational with an incorrectly inserted battery.

2. The included battery magazine securely holds the (R)CR123 battery in

place, thus stopping battery movement in the compartment.

3. Please stop using and remove a depleted IMR18350 battery to avoid

potential battery damage.

Accessories

Quality holster, (R)CR123 battery magazine,

clip, lanyard, spare o ring

Battery Options

4.2V3.5V 3.7V 3.9V

Low Power Full Power

3.2V2.4V 2.8V 3.0V

Low Power Full Power

IMR18350:

CR123:

The All-Round Flashlight Expert

TYPE Nominal voltage Compatible

Primary Lithium battery CR123 3V Y (Recommended)

IMR18350 Rechargeable Li-ion battery IMR18350 3.7V Y

Rechargeable Li-ion battery RCR123 3.7V Y

Thanks for purchasing NITECORE!

User Manual

On / Off Operation

To switch ON: Press the ON/OFF button once.

To switch OFF: Press the ON/OFF button once again to switch the light off and enter standby mode

Standby Mode

With the light switched on, press and hold the ON/OFF button for more than one second to switch the

light off and activate the secondary red LED to flash once every three seconds, thus helping the user

locate the EC11 in dark conditions. When using a CR123 battery, the EC11 will operate for up to 6

consecutive days with the red LED on, or remain on standby for more than 170 days with the red LED off.

Brightness Levels

With the EC11 switched on, press the MODE button repeatedly to cycle through the following

brightness levels: ultra-low, low, medium, high and turbo. Once a mode is selected it will be saved

and resumed when the EC11 is reactivated.

Changing / Charging Battery

Battery should be replaced or recharged when output appears to be dim or the flashlight becomes

unresponsive.

Maintenance

Every 6 months, threads should be wiped with a clean cloth followed by a thin coating of

silicon-based lubricant.

Warranty Service

All NITECORE® products are warranted for quality. Any DOA/defective product can be exchanged

for a replacement through a local distributor/dealer within 15 days of purchase. After 15 days, all

defective/malfunctioning NITECORE® products will be repaired free of charge for a period of 60

months (5 years) from the date of purchase. Beyond 60 months (5 years), a limited warranty

applies, covering the cost of labor and maintenance, but not the cost of accessories or

replacement parts.

The warranty is nullified in all of the following situations:

1. The product(s) is/are broken down, reconstructed and/or modified by unauthorized parties.

2. The product(s) is/are damaged through improper use.

3. The product(s) is/are damaged by leakage of batteries.

For the latest information on NITECORE® products and services, please contact your national

NITECORE® distributor or send an email to service@nitecore.com

The Nitecore official website shall prevail in case of any product data changes.

SYSMAX Industry Co., Ltd.

TEL: +86-20-83862000

FAX: +86-20-83882723

E-mail: info@nitecore.com

Web: www.nitecore.com

Address： Rm1401-03, Glorious Tower, 850 East Dongfeng Road,

Guangzhou, China 510600

Please follow our facebook for

more info: NITECORE Flashlights

TURBO HIGH MID

LUMENS

300

LUMENS

900

LUMENS

160

min

LUMENS

230

LUMENS

430

LUMENS

100

min

LOW

LUMENS

min

LUMENS

min

LOWER

LUMEN

190m (Beam Distance)

9000cd (Peak Beam Intensity)

IPX-8, 2m

(Waterproof AND Submersible)

1.5m (Impact Resistant)

CR123 IMR18350

IMR 18350
