User Manual

The All-Round Flashlight Expert

EC20

Features

· Utilizes a CREE XM-L2 U2 LED

· Maximum output of up to 960 lumens

· Integrated “Precision Digital Optics Technology” provides extreme reflector performance

· Boasts a peak beam intensity of 12,450 cd and a throw distance of up to 222 meters

· Innovative single button offers access to seven brightness levels and modes.

· High efficiency constant current circuit board provides max runtime of 520 hours.

· Integrated power indicator light displays remaining battery power

(Patent NO. ZL201220057767.4)

· Power indicator’s secondary function displays battery voltage (accurate to 0.1V)

· Instant access to ultra-low output

· Reverse polarity protection prevents damage from incorrectly inserted batteries

· Constructed from aero grade aluminum alloy with HAIII military grade hard-anodized finish

· Waterproof in accordance to IPX-8 (two meters submersible)

· Impact resistant to 1.5 meters

· Tail stand capability

Dimensions

Length: 128mm (5”)

Head diameter: 25.4mm (1”)

Tube diameter: 25.4mm (1”)

Weight: 76g (2.68oz)(without battery)

Battery Options

Output & Runtime

Brightness Levels

With the EC20 switched on, press and hold the button for more than 0.5 second to cycle through

brightness levels of ultra-low, low, medium and turbo. To select a desired brightness level,

simply release the button when that level is being displayed. This mode provides an intelligent

memory function to ensure direct access to the previously used brightness level when the EC20

is reactivated.

Note: when in turbo mode, the EC20 will reduce output luminance automatically after 5 minutes

of use to prevent overheating and extend battery longevity

Instant Ultra Low

With the EC20 switched off, press and hold the button for more than one second to access an

ultra-low output mode of 1 lumen.

Special Strobe / SOS mode and Location

Beacon

Press the button twice in quick succession in any state to enter Strobe mode. When in strobe

mode, press the switch all the way down and hold for more than one second to cycle through

Strobe, SOS and Location Beacon modes. To exit any of these special modes, simply press the

button again. The EC20 does not have a memory function for special modes.

Power Tips

1. When the light is on, the power indicator will blink once every two seconds when power levels

reach 50%.

2. When the light is on, the power indicator will blink quickly when power levels are low.

3. Each time batteries are inserted, the power indicator light will blink in varying patterns to

indicate battery voltage (accurate to ±0.1V). For example, when battery voltage is at a

maximum charge of 4.2V, the power indicator will blink 4 times in quick succession, followed

by a one second pause, and then two more blinks, thus indicating the battery voltage

detected is 4.2V.Different voltages represent the corresponding remaining battery power

levels :

Replacing Batteries

Batteries should be replaced when any of the followings occurs: The power indicators blinks

rapidly, output appears to be dim or the flashlight becomes unresponsive.

Maintenance

Every 6 months, threads should be wiped with a clean cloth followed by a thin coating of

silicon-based lubricant.

Warranty Details

Our authorized dealers and distributors are responsible for warranty service. Should any problem

covered under warranty occurs, customers can contact their dealers or distributors in regards to their

warranty claims, as long as the product was purchased from an authorized dealer or distributor.

NITECORE’s Warranty is provided only for products purchased from an authorized source. This

applies to all NITECORE products.

Any DOA / defective product can be exchanged for a replacement through a local distributor/dealer

within the 15 days of purchase. After 15 days, all defective / malfunctioning NITECORE® products

can be repaired free of charge for a period of 60 months (5 years) from the date of purchase. Beyond

60 months (5 years), a limited warranty applies, covering the cost of labor and maintenance, but not

the cost of accessories or replacement parts.

The warranty is nullified if the product(s) is/are broken down, reconstructed and/or modified by

unauthorized parties, or damaged by batteries leakage.

For the latest information on NITECORE® products and services, please contact a local NITECORE®

distributor or send an email to service@nitecore.com.

※All images, text and statements specified herein this user manual are for reference purpose only.

Should any discrepancy occurs between this manual and information specified on www.nitecore.com.

Sysmax Industry Co., Ltd. reserves the rights to interpret and amend the content of this document at

any time without prior notice.

Thanks for purchasing NITECORE!

Accessories

Quality lanyard, spare O-ring

HIGH MID LOW

LUMENS

960

LUMENS

210

LUMENS

300

min

LOWER

LUMEN

520

222m

(Beam Distance)

12450cd

(Peak Beam Intensity)

IPX-8, 2m

(Waterproof AND Submersible)

1.5m

(Impact Resistant)

2×CR123

1×18650

TYPE

Nominal voltage

Compatible

Primary Lithium battery CR123 3V Y (Recommended)

18650 Rechargeable Li-ion battery 18650 3.7V Y (Recommended)

Rechargeable Li-ion battery RCR123 3.7V Y

NOTICE

Stated data has been measured according to the international flashlight testing standards

ANSI/NEMA FL1 using a quality Nitecore 18650 (3.7V 2600mAh) battery or two Nitecore CR123

(3V 1700mAh) batteries under laboratory conditions. The data may vary due to individual usage

habits and environmental conditions.

Operating Instructions

Battery Installation

Insert one 18650 battery or two CR123 batteries

with the positive poles pointing forward (toward

the head).

Note: After loading the batteries, the power

indicator light will blink to indicate battery voltage.

Please refer to the “Power Tips” section of this

manual for details.

WARNING

1. Ensure batteries are inserted with the positive (+)

end pointing to the head. The EC20 will not operate with incorrectly inserted batteries.

2. When the EC20 is kept in a backpack or left unused for extended periods of time, Nitecore

recommends all batteries are removed to prevent accidental activation of the flashlight or

battery leakage.

ON/OFF

Press the button until a click is heard to switch the light on.

Press the button once again until a click is heard to switch the light off.

SYSMAX Industry Co., Ltd.

TEL: +86-20-83862000

FAX: +86-20-83882723

E-mail: info@nitecore.com

Web: www.nitecore.com

Address： Rm1401-03, Glorious Tower, 850 East Dongfeng Road,

Guangzhou, China 510600

20161220

4.2V3.5V 3.7V 3.9V

Full powerLow power

6.4V4.8V 5.6V 6.0V

Full powerLow power

1 x 18650 battery

2 x CR123 batteries

Please find us on facebook:

Nitecore Flashlight
