Note: testing done with 3 x CR123A batteries(3.0V, 1500mAh）

Thank you for purchasing the Olight M3XS-UT

JAVELOT! Please read this manual carefully before

using this product.

M3XS-UT JAVELOT

EXTENDED-RANGE VARIABLE-OUTPUT LED FLASHLIGHT

USER MANUAL

WARRANTY

Within 30 days of purchase: Return to retailer

from which you purchased for repair or replacement.

Within 5 years of purchase: Return to Olight for

repair or replacement.

This warranty does not cover normal wear and tear,

modifications, misuse, disintegrations, negligence,

accidents, improper maintenance, or repair by anyone

other than an Authorized retailer or Olight itself.

Technical Support Inquiries

techsupport@olightworld.com

Customer Service

cs@olightworld.com

Visit www.olightworld.com to see our

complete product line of portable

illumination tools.

INSIDE THE BOX

M3XS-UT Javelot, Holster, Extended Tube, Battery

magazine, (2) O-rings, user manual

HOW TO OPERATE (

Figure2

)

a) Fully press then release the tail swith to turn on or off the light, the flashlight always starts at previous mode

set by side switch.

b) While the light is on, every click on the side switch, the brightness level changes to next level as preset

orders of moon – low – medium – high – low.... Holding the side switch over 1 second, the output enters into

strobe of 10HZ.

c) There are 4 speical operations can directly access the frequently-used modes from off status: half press the

tail switch enable momentary on, and twice click the tail switch activates maxium brightness, and triple

click the tail switch activates strobe, hold the side switch then press the tail switch down, the flashlight

turns at moon light.

SUPPORTED BATTERIES

• If using 3xCR123A batteries. First, insert the batteries

into the battery magazine, then place the battery

magazine into flashlight, finally tighten the tail cap.

Attention that the positive of battery should towards the

flashlight head.

• If using 4xCR123A batteries or 2x18650 batteries,

the extended tube need be assembled to the flashlight

before battery installation.

Attention: 18650 batteries must be with

protected board and protruding positive electrode

(18650 with flat positive electrode are not

suitable for serial nnect)co

BATTERY INSTALLATION (

Figure1

)

Ensure batteries are inserted with the positive (+)

end pointing to the head.

WARNING:

• Do not use unsupported batteries with

this flashlight.

• Do not mix batteries of different types/brands.

• Do not mix rechargeable and non-rechargeable

batteries.

• Use caution on high outputs or long runtimes as

flashlight may get hot.

SPECIFICATIONS

HIGH

MID

LOW

MOONLIGHT

STROBE

LED

VOLTAGE

CANDELA

BEAM DISTANCE

BATTERY TYPE

BODY TYPE

WATERPROOF

IMPACT RESISTANCE

DIMENSIONS

WEIGHT

1,200 lumens / 5 minutes+

720 lumens / 55 minutes

600 lumens / 1.5 hours

80 lumens / 12 hours

3 lumens / 360 hours

10 Hz / 1,200 lumens

Cree XP-L high Intensity

4v to 12v

250,000 cd

1000 meters / 3281 feet

3 or 4 x CR123A or 2 x 18650

type III hard anodized aluminum

IPX8 (up to 2 meters)

1 meters

L 211mm x (head)D 63mm,(tube)25mm

255 g/ 8.99 oz

(excluding batteries)

All performance claims to ANSI/NEMA FL1-2009 Standard.

APR 10, 2015

MADE IN CHINA

OUTPUT VS RUNTIME

( Figure 3)

Figure1

Figure2

User interface

CR123 A

Battery Magazine

3 x CR123A

18650 18650

CR12 3A CR 123 A CR123 A CR1 23A

4 x CR123A

2 x 18650

Gripper

Tail switch

Tail cap

On status

OFF

Fully press

OFF

High

Strobe

Slightly press

Momentary Light

Slightly press

Extended Tube

Low Battery Indicator

Side Switch

CR123A

1 x CLICK

LOW MED HIGH

STROBE

HOLD FOR 1 SEC

1xClick

HOLD

Moonlight

Tail Switch

Side Switch

Run Time ( minute )

100

200

300

400

500

600

700

800

900

1000

0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80

1100

1200

1300

Ambient: Temp. 25 Humd 55℃ . %RH

Battery: 3 x @CR123A 1500mAh Olight

High

lumen
