Side 1/2

Installation Instructions

Technical Data

THIS MIXER TAP MUST BE INSTALLED BY A LICENSED PLUMBER IN

ACCORDANCE WITH LOCAL REGULATIONS.

This Oliveri tap is manufactured to standard AS/NZS 3718.

Before attempting any work involving mains water supply lines, ensure the water supply is

shut off.

Stop valves must installing your mixer to (preferably with ﬁlters) be used when Oliveri allow

isolation (not supplied with mixer). Failure to do so where required will void warranty.

This mixer tap is already pre-assembled and tested. Do not disassemble, as this may void

the warranty.

This mixer tap must be installed in accordance with these instructions.

Oliveri Solutions Pty Ltd ABN 12 007 551 8

51 Naweena Rd, Regency Park SA 5010 P 08 8348 6444 E sales@oliveri.com.au

Where water pressure exceeds 500kPa, a pressure reducing device is required to be installed.

Note that water pressure overnight can reach 150% of the daytime pressure.

Note:

Installation of aerators containing ﬂow regulators.

Upon re-installation, the aerator should be tightened with an aerator key to prevent

removal by hand.

Note:

Ceramic Cartridges - Warranty claims will not be honoured where the ceramic

cartridge has malfunctioned due to the presence in the water supply of;

• Copper tube pieces, sand, dirt or stones

• Thread tape

• Other objects not normally present in potable water supplies.

Do not remove the cartridge from the body as it has been pressure tested and

tightened to a speciﬁc torque.

MAX OPERATING PRESSURE: ...................................................... 5 bar (500kPa)

RECOMMENDED OPERATION PRESSURE: ................................... 1.5-5 bar (150-500kPa)

MAX HOT WATER TEMPERATURE: ............................................. 65°C

RECOMMENDED HOT WATER TEMPERATURE: ............................ 50°C

TF 182 - SS 25 Installation Instructionse 316

Essente

Stainless Steel Goose Neck Pull Out Mixer

SS 25 / SS 25-AU / SS 25-BL / SS 25-GM316 316 316 316 / SS31625-CU

CARE & MAINTENANCE

Unscrew and clean the spout aerator periodically - especially if you notice a drop in water

pressure. The ﬁnish on your Oliveri mixer tap will resist stains and dirt build up.

Clean with a soft cloth and warm soapy water as necessary - rinse and dry after cleaning.

Avoid using abrasive or acid based cleaning products.-

WARRANTY FOR DOMESTIC USE

This mixer tap is warranted to be free from manufacturing defects for a period of

1 Years: Cartridge: 1 years replacement parts, 1 year labour; Body including handle: 5 5

7 years replacement parts and labour; Finish: 5 years replacement parts, 1 year labour;

Seals, tails, aerators, pull-out hoses and spray heads: 1 year replacement parts and labour.

Where a genuine manufacturing defect arises within the warranty period Oliveri will, at its

election, repair the defect or replace the product subject to the terms contained in the full

warranty information available at https://oliveri.com.au/service-and-warranty.

This warranty does not cover against normal wear and will be voided if the

product is misused or not installed in accordance with these instructions. Note:

Fitting spout-attached devices, including water filters, to this mixer will void warranty.

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law. You are entitled to a replacement or refund for a major failure and for

compensation for any other reasonably foreseeable loss or damage. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and

the failure does not amount to a major failure.

SERVICE

If the problem represents a danger, or damage to property may occur,

immediately shut off the water supply. If the mixer tap requires servicing, please

contact your plumber (preferably the one who installed it). Most problems occur due to

contaminated supply lines or water pressure exceeding 500kPa. Unscrew and clean the

spout aerator periodically - especially if you notice a drop in water pressure.

If the plumber / installer is satisfied that the problem is not due to poor installation,

contact Oliveri’s nominated Warranty Service Agent for assistance on:

Ph: (08) 8348 6444 (choose the after sales service and warranty option)

Email: warranty@oliveri.com.au

For full warranty information visit: https://oliveri.com.au/service-and-warranty

If a warranty service call finds that the product does not have a genuine

manufacturing fault, our Warranty Service Agent reserves the right to pass on

any call-out fee to the householder.

This product complies with the Lead Free requirements of the National

Construction Code Volume 3.

Installation Instructions

Max 37

TF 182 - SS 25 Installation Instructionse 316

GENERAL NOTE

This product is to be installed by

a licensed plumber, installation

must comply with AS/NZS 3500

and local plumbing codes.

PRESSURES & TEMPERATURES

Max

imum Hydrostatic Pressure – 500kPa. (As per AS/NZS3500)

Note: AS/NZS 3500.1-2003 (Clause 3.3.4) states that

”Provision shall be made to ensure that the maximum static

pressure at any outlet, other than a ﬁre service outlet, within a building does not exceed 500kPa.”

Note: Pressures above 500kPa can cause damage from water hammer, reduced life of appliances, taps

and ﬁttings, and cause excessive noise in the system. Minimum Hydrostatic Pressure 100kPa. :

Note: This Product may not be suitable for use with low pressure/gravity feed water supplies or with

some continuous flow/instantaneous hot water systems. The maximum operating temperature for the

Mixer Tap is 65ºC. The recommended maximum delivery temperature is 50ºC.

Please ensure that the lines are ﬂushed prior to installation as contaminates in the water can

damage the Ceramic Cartridge, ﬂow regulator and also affect the performance of the Mixer.

Note: This mixer is designed to have the handle to the right hand side of the mixer, doing so will put

the cold inlet to the front of the mixer, the purpose is to assist with accidental scalding if a child pulls

the handle forward trying to turn on the mixer, installing the handle to the centre will put the cold on

the left hand side which is not recommended.

1. Remove product from packaging and check for damages, if the product is damaged do not install

and return to store of purchase.

2. The WELS compliant aerator has been pre-assembled into the mixer outlet. To comply with

WELS

the ﬂow regulated aerator must remain in place.

3. Ensure product is complete as per exploded drawing.

4. A single 35mm hole is required in the mounting surface.

5. The maximum mounting surface thickness cannot exceed 37mm.

6. Fit O-ring (A) to bottom of mixer body.

7. Screw Mixer Tails (B) into the base of the mixer being careful not to damage the O-ring seals., Hand

tighten only.

8. Feed male end of Braided Hose (H) through top of mounting surface.

N.B. Hose Adaptor (J) and Washer (I) are lightly screwed to male end of Hose (H), this ﬁtting will

need to be removed for ease of feeding hose through mounting surface.

9. Feed the Mixer Tails (B) through the mounting surface, each tail alternatively.

10. The mixer inlet ports are colour coded, red for hot and blue for cold.

11. Position mixer on the mounting surface ensuring the Sealing Washer (A) is positioned correctly.

12. Feed mixer tails, each alternatively through Stabiliser Plate (C).

13. Slide Rubber Washer (D) onto mixer thread followed by Metal Washer (E).

14.Using Fixing Nut (F), tighten mixer to mounting surface, lock ﬁxing nut in place with Screws (G).

15.Screw Hose Adaptor (J) to male threaded end of Hose (H) ensuring Sealing Washer (I) is in place.

16.Screw Hose Adaptor (J) to Mixer Water Outlet port being careful to avoid damage to the

O-ring seals.

17.

18.

Connect Mixer tails (B) to mains water 1/2"stop cock. Tighten to 10Nm. Do NOT overtighten.

N.B. Ensure the Mixer Tails are not kinked, bent, stretched or twisted when assembling to

the mains water supply. The mixer tail connection between the mixer and the water

supply must hav

e a natural curve (minimum bend radius 30 mm). Ensure Mixer tails are

installed indoors, above-ground, and remain accessible - do not bury, submerge, nstall behind a i

wall, floor or ceiling. Do not not expose to abrasions, corrosive agents or the like. Test for leaks: If a

leak occurs, retighten slightly.

19.It is recommended that in-line ﬁlters be installed to ensure a cleaner ﬂow of water to the mixer.

20.The Braided hose will have a natural curve under the mounting surface, on the hand piece side of

the curve fit the Return Weight (K) using the two screws provided. Fit the weight approximately

100mm up from the bottom of the curve, the position can be adjusted to suit but the weight must

remain on the hand piece side of the curve.

TO THE CONSUMER

1. The mixer is to only be cleaned with warm soapy water.

2. Under no circumstances should any abrasive, cream or acid based cleaning agents be used as

these types of cleaners will damage the tap ﬁnish, cartridge, seals and aerators.
