Cabled scanners

Barcode CCD scanner

Related products

C37

OPR3001

Cabled device•

Barcode laser scanner•

RS232, Keyboard Wedge, USB•

OPR2001

Cabled device•

Barcode laser scanner•

RS232, Keyboard Wedge, USB•

With stand•

OPL7836

Cabled device•

Barcode laser scanner•

RS232, Keyboard Wedge, USB•

C37_002

Basic Product Speciﬁcations

Operating indicators

Visual: 1 LED (red/green/orange)•

Non-visual: Buzzer•

Operating keys

Entry options: •

1 scan key

Communication

RS232: DB9 PTF connector with external power •

supply

Keyboard Wedge: MiniDIN6 F/M connector•

USB: Ver. 1.1, HID/VCP, USB-A connector•

Power

Voltage requirement: 5V • ± 10% (Keyboard Wedge

and USB), 6V (min. 4.5, max. 6.6V) (RS232)

Barcode scanner Optics

Light source: 630 nm red LED•

Scan method: CCD linear Sensor 2500 Pixels•

Scan rate: 200 scans/sec•

Trigger mode: Manual, auto-trigger•

Reading pitch angle: -30 to 0°, 0 to +30°•

Reading skew angle: -70 to -20°, 20 to +70°•

Reading tilt angle: -25 to 0°, 0 to +25°•

Curvature: R>15 mm (EAN8), R>20 mm (EAN13) •

Min. resolution at PCS 0.9: 0.125 mm / 5 mil •

Depth of ﬁeld: At PCS 0.9, Code 39 •

0 - 15 mm / 0 - 0.59 in

Supported Symbologies

Barcode (1D): JAN/UPC/EAN incl. add on, Codabar/•

NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128

(EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5,

Interleaved 2of5, ISBN-ISSM-ISSN, Matrix 2of5, MSI/

Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey

Postal code: Chinese Post, Korean Postal Authority •

code

Durability

Temperature in operation: 0 to 50 °C / 32 to 122 °F•

Temperature in storage: -20 to 60 °C / -14 to 140 °F•

Humidity in operation: 5 - 95% (non-condensing)•

Humidity in storage: 5 - 95% (non-condensing)•

Ambient light immunity: • Fluoresecent 10,000 lx

max, Incandescent 10,000 lx max

Drop test: 1.5 m / 5 ft drop onto concrete surface•

Vibration test: 10 - 100 Hz with 2G for 1 hour•

Protection rate: IP 42•

Physical

Dimensions (w x h x d):•

75 x 150 x 53 mm / 2.95 x 5.91 x 2.09 in

Weight body: Ca. 90 g / 3.2 oz (excl. cable) •

Case: ABS, Black, White•

Regulatory & Safety

Product compliance: CE, FCC, VCCI, RoHS•

Enclosed items

Power supply 100-240V/0.5A, 50/60 Hz, 6V/2A (for •

RS232)

Models

Interface versions: RS232, Keyboard Wedge, USB•

Color versions: Black, White•

WWW . O P T I C ON. C O M

- The Netherlands: Hoofddorp

- France: Issy Les Moulineaux

- Germany: Dietzenbach

- Italy: Castel Maggiore (BO)

- Spain: Valencia

- Sweden: Järfälla

- United Kingdom: Luton, Bedfordshire

- U.S.A.: Renton, WA

- Japan: Warabi City

- Taiwan: Taipei

- P.R.China: Shanghai

- Australia: Kariong

- Brazil: São Paulo

Opticon Sensors Europe B.V

European headquarters

Opaallaan 35

2132 XV Hoofddorp

The Netherlands

phone: +31 (0)23-5692700

fax: +31 (0)23-5638266

email: sales@opticon.com

internet: www.opticon.com

Produkt Specifikationer

Mærke:	Opticon
Kategori:	Stregkodelæser
Model:	C37
Kode for international beskyttelse (IP):	IP42
Type:	Håndholdt stregkodelæser
Bredde:	75 mm
Dybde:	53 mm
Højde:	150 mm
Vægt:	90 g
Produktfarve:	Hvid
Indbygget skærm:	Ingen
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	5 - 95 %
Driftstemperatur (T-T):	0 - 50 °C
Scanner type:	1D
Husmateriale:	Syntetisk ABS
Forbindelsesteknologi:	Ledningsført
Certificering:	CE, FCC, VCCI
LED-indikatorer:	Ja
Strømkilde type:	USB
Harmoniseret systemkode (HS):	84716070
USB version:	1.1
Bæredygtighedscertifikater:	RoHS
Indgangsspænding:	5 V
Sensortype:	CCD
Standard grænseflader:	USB
Bølgelængde:	630 nm
Lydalarm:	Ja
Opløsning på optisk sensor:	2500 pixel
Læsehastighed (maks.):	200 læs/sek.
Tilt læsningsvinkel:	-20 - 20 °
Pitch læsningsvinkel:	-35 - 35 °
Understøtter lineær (1D) stregkoder:	Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), JAN, MSI, Plessey, Telepen, Trioptic, U.P.C.
Understøtter matrix (2D) stregkoder:	Ikke understøttet
