Data Collectors

Barcode laser scanner

Related products

OPL9712

Data Collector•

Barcode laser scanner•

IrDA, Bluetooth•

OPL9714

Data Collector•

Barcode laser scanner•

GPS•

3 key operation•

OPN2002

Data Collector•

Pocket memory scanner•

USB, Bluetooth•

OPL9724

GSM cradle

Serial cradle

Modem cradle

OPL9724_002

Basic Product Speciﬁcations

Operation

CPU: 16-bit•

O/S: Proprietary•

Software: Programmable in C-language. Ansi-C •

Cross compiler obtainable. Software development

kit free downloadable

RTC: Supports year, month, day, hour, minute, •

second (leap year supported)

Memory

FlashROM: 512 kB •

RAM: 128 kB•

Display

Type: Graphic LCD•

Size: 112 x 64 pixels•

Mode: Landscape / 180º rotation•

Font size: 6x6 / 6x12 / 8x8 / 8x16 dots•

Operating indicators

Visual: 1 LED (red/green/orange)•

Non-visual: Buzzer•

Operating keys

Entry options: 3 keys total,•

2 function keys,

1 scan key

Communication

IrDA: Ver. 1.2, baudrate 2400 bps - 115.2 kbps•

Bluetooth Ver. 2.0, SPP, DUN, range up to 10 m, 1 to 1 •

connection, master/slave mode, authentication and

encryption

Power

Rechargeable battery: Lithium-Ion 3.7V 600mAh•

Backup battery: Lithium rechargeable 3.5mAh•

Data retention time: Ca. 72 hours•

Charging method: Separate cradle CRD9720 series•

Barcode scanner Optics

Light source: 650 nm visible laser diode•

Scan method: Vibrating mirror•

Scan rate: 100 scans/sec•

Reading pitch angle: -25 to 0º, 0 to +25º•

Reading skew angle: -50 to -8º, +8 to +50º•

Reading tilt angle: -20 to 0º, 0 to +20º•

Curvature: R>15 mm (EAN8), R>20 mm (EAN13)•

Min. resolution at PCS 0.9: 0.15 mm / 6 mil•

Min. PCS value: 0.45•

Depth of ﬁeld: At PCS 0.9, Code 39•

60 - 300 mm / 2.36 - 11.81 in (1.0 mm / 39 mil),

35 - 210 mm / 1.38 - 8.27 in (0.5 mm / 20 mil),

35 - 120 mm / 1.38 - 4.72 in (0.25 mm / 10 mil),

35 - 70 mm / 1.38 - 2.76 in (0.15 mm / 6 mil)

Supported Symbologies

Barcode (1D): JAN/UPC/EAN incl. add on, Codabar/•

NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128

(EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5,

Interleaved 2of5, ISBN-ISSN, Matrix 2of5, MSI/

Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey

Postal code: Chinese Post, Korean Postal Authority •

code

2D code: Composite Codes, MicroPDF417, PDF417•

Durability

Temperature in operation: -5 to 40 ºC / 23 to 104 ºF•

Temperature in storage: -20 to 60 ºC / -4 to 140 ºF•

Humidity in operation: 20 - 80% (non-condensing)•

Humidity in storage: 20 - 90% (non-condensing)•

Ambient light immunity: White 3,000 lx max, •

Fluorescent 3,000 lx max, Direct sun 50,000 lx max

Vibration test: 12 - 100 Hz with 2G for 1 hour•

Protection rate: IP 54•

Physical

Dimensions (w x h x d):•

44 x 125 x 19 mm / 1.73 x 4.92 x 0.75 in

Weight body: Ca. 85 g / 3 oz (incl. battery)•

Case: ABS, Lilacgrey•

Regulatory & Safety

Product compliance: CE, FCC, VCCI, RoHS, •

JIS-C-6802 Class 1, IEC 60825-1 Class 1, FDA CDRH

Class I

Enclosed items

Rechargeable battery•

Hand strap•

Sold separately

CRD9722 Cradle: Charging•

CRD9723RU Cradle: Serial communication, charging•

CRD9723RU1 Cradle: Multi-cradle, 1x communication, •

5x charging

CRD9723RU5 Cradle: Multi-cradle, •

5x communication, 5x charging

CRD9726 Cradle: Modem communication, charging•

CRD9727 Cradle: GSM communication, charging•

OPL9700 Nylon case with swivel clip & window•

OPL9700 Nylon case with swivel clip•

OPL9700 Nylon case with ﬁxed clip•

WWW . O P T I C ON. C O M

- The Netherlands: Hoofddorp

- France: Issy Les Moulineaux

- Germany: Dietzenbach

- Italy: Castel Maggiore (BO)

- Spain: Valencia

- Sweden: Järfälla

- United Kingdom: Luton, Bedfordshire

- U.S.A.: Renton, WA

- Japan: Warabi City

- Taiwan: Taipei

- P.R.China: Shanghai

- Australia: Kariong

- Brazil: São Paulo

Opticon Sensors Europe B.V

European headquarters

Opaallaan 35

2132 XV Hoofddorp

The Netherlands

phone: +31 (0)23-5692700

fax: +31 (0)23-5638266

email: sales@opticon.com

internet: www.opticon.com

Produkt Specifikationer

Mærke:	Opticon
Kategori:	Stregkodelæser
Model:	OPL-9724
Vægt:	85 g
Produktfarve:	Grey, White
Batterikapacitet:	600 mAh
Skærmopløsning:	112 x 64 pixel
Bluetooth:	Ja
Batteriteknologi:	Lithium-Ion (Li-Ion)
Skærm:	LCD
Intern hukommelse:	0.128 MB
Dimensioner (BxDxH):	44 x 19 x 125 mm
Certificering:	CE, FCC, VCCI, RoHS, JIS-C-6802, IEC 60825-1, FDA CDRH
Indgangsspænding:	3.7 V
Bølgelængde:	650 nm
Hældningsvinkelområde:	0 - 20 °
Skanningshastighed:	100 sek./side
Tilt læsningsvinkel:	0 - 20 °
Pitch læsningsvinkel:	0 - 25 °
Afkodningsstandarder:	JAN/UPC/EAN, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
