Side 1/2

New SSVC2V7; 2 Zone, 70V Mono Speaker Selector with Built in 100W

70V Mono Volume Control x 2 and Straight Pass Thru Output

Zone 1

On/O

Switch

Specicaons

•Power Handling: 100 Was Per Channel/Zone Mono Single Channel

•Frequency Response: 20Hz-22KHz (+0 dB, -0 dB)

•Selector Type: Noise-Free, front access On/O Pushbuon and Rotary Knob

•Steps: 33 dB, 10 steps plus full of (step 11)f

•Connecon Type: Removable Input/output Connectors

•Wire Size Acceptance: 16 Gauge 2 Conductor,

•Amplier Protecon: 70V Mono only No Impedance Protecon Needed

Front Panel SSVC2V7

The SSVC2V7 is a unique 70V Speaker Selector featuring…

2 independent Zones each controlled by a 100Wa 70V Mono Volume Control featuring a Rotary style

Knob. Each zone has On/O switch as well. The unit has a single 2 conductor input and direct pass thru

allowing to stack additional SSVC27V Speaker selectors only limited by your applicaon. Standard 70V

rules apply to the number of speakers used per zone, matching the available power from the 70V

amplier

Zone 1

On/O

Switch

Zone 2

Volume

Knob

Note #2: The Thru output comes

directly from the Input, it does not

go through the transformer allowing

you to stack mulple SSVC7V.

Note #1: The On/O switch is supply so

you can turn o each zone completely

not just depend on the Volume Control

to turn so the sound down to inaudible

levels. The knob would need to be

turned all the way counterclockwise for

full o

Input

from Amplier

Straight Thru

Output

ZONE 1 Speaker

Output

ZONE 1 Speaker

Output

Back Panel SSVC2V7

Zone 1

Volume

Knob

OSD Audio Limited Warranty

OSD Audio will repair or replace any defect it in material or workmanship which occurs during normal use of this product

with new or rebuilt parts free of charge in the US for ve years from date of original purchase. This warranty does not

cover damages in shipment, failure caused by other products not supplied by OSD Audio or failures due to accident,

misuse, or alteraon of the equipment. This warranty is extended only to the original purchaser and a purchase receipt,

invoice or other proof of original date will be required before warranty repairs are provided

Mail in service can be obtained during period by emailing . A return authorizaon number must be RMA@osdaudio.com

obtained in advance and be marked on the outside of the shipping carton.

This warranty gives you specic legal rights and may have other rights (which vary from state to state). If a problem

with this product develops during or aer the warranty period please contact OSD Audio or your dealer

OSD Audio · 775 Columbia St., Brea CA 92821 · www.osdaudio.com

Power Rang:

The Internal Volume Controls (2) are rated at

100W so the speaker(s) connected to it needs the

transformer seng to be equal to or less than the

rated was of each MVC. You can have mulple

speakers connected to one MVC but total waage

must 80% or less than the rated Waage of the

each of the internal 100 Wa Volume Controls.

Picking the right Distribuon Amplier:

To start with the Amplier must have a 70Volt output. It must have an output power rang equal to or greater than the

total waage of the system once you have calculated what each speaker should be set to and the total sum of those

sengs. If you had four speakers at 5 was each (20 total) and one speaker set to 10 was (20 + 10 = 30) your amplier

must be rated at least 30 was minimum. If you had ve speakers at 10 was each (50 total) and another 5 ve speakers

at 5 was each (25 + 50 = 75) you would need a amplier rated at a minimum 75 was.

Some companies recommend the total should be closer to 80% of the minimum rang of the amplier. It is also a good

idea to install an amplier with more than enough power in case you want to add more speakers later.

Key Point: The Power rang of the amplier is determined by the transformer sengs, not the aenuator Rang, The

rated power of the Aenuator is based upon the minimum seng of the transformer taps which have to be equal to or less

than the rated waage of the respecve MVC Aenuator

STEP

ATTENUATION

Full Volume

0dB

9 3dB minus 3dB

8 3dB minus 6dB

7 3dB minus 9dB

6 3dB minus 12dB

5 3dB minus 15dB

4 3dB minus 18dB

3 3dB minus 21dB

2 6dB minus 27dB

1 6dB minus 33dB

0 0dB Speaker o

Internal Volume

Control Specs:

10 Step, 33dB

Plus Full O

Features and Specicaons

DECORA style high-quality auto transformer provides advantages of excellent frequency response, low inseron loss

and reliable performance for volume control applicaons in 25 and 70 volt systems. Aenuaon is accomplished in ten

make before break steps plus posive o posion (no stop between maximum and o posion to prevent switch

damage). The Aenuator features removable input/output terminal blocks, Two in, two out and two oponal for

through output for daisy chain opon. An aracve alternave to Commercial series aenuators mounts into most

single gang E.O boxes. UL Listed White, Almond and Ivory Plasc Plates with Matching Skirted Knobs in DECORA® Style

New SSVC2V7; 2 Zone, 70V

Mono Speaker Selector
