Input Voltage: 230-240V ~ 50Hz
Drilling Capacity: 32mm (Masonry)
Accessory Fitment: SDS-Plus
OZITO UK Unit 9 Stadium Court, Wirral International Business Park, Plantation Road, Bromborough, Wirral, CH62 3QG
All of our products undergo strict quality checks to ensure that they reach
you in perfect condition. In the unlikely event that your device develops a
fault, please contact our service department at the address shown on this
guarantee card. You can also contact us by telephone using the customer
service number shown. Please note the following terms under which
guarantee claims can be made:
1. These warranty terms regulate additional warranty services, which the
manufacturer mentioned below promises to buyers of its new products
in addition to their statutory guarantee claims are not affected by this
guarantee. Our guarantee is free of charge to you.
2. The warranty services only covers defects due to material or
manufacturing faults on a product which you have bought from the
manufacturer mentioned below are limited to either the rectication of said
defects on the product or the replacement of the product, whichever we
Please note that our devices are not designed for use in commercial, trade
or professional applications. A guarantee contract will not be created if the
device has been used by commercial, trade or industrial business or has
been exposed to similar stresses during the guarantee period.
3. The following are not covered by our guarantee:
- Damage to the device caused by a failure to follow the assembly
instructions or due to incorrect installation, a failure to follow the operating
instructions (for example connecting it to an incorrect mains voltage or
current type) or a failure to follow the maintenance and safety instructions
or by exposing the device to abnormal environmental conditions or by lack
- Damage to the device caused by abuse or incorrect use (for example
overloading the device or the use or unapproved tools or accessories),
ingress of foreign bodies into the device (such as sand, stones or dust,
transport damage), the use of force or damage caused by external forces
(for example by dropping it).
- Damage to the device or parts of the device caused by normal or natural
wear or tear or by normal use of the device.
4. Your Product is guaranteed for a period of 36 months from the original
date of purchase and is intended for DIY (Do It Yourself) use only. Warranty
excludes consumable parts. Guarantee claims should be submitted
before the end of the guarantee period within two weeks of the defect
being noticed. No guarantee claims will be accepted after the end of the
guarantee period. The original guarantee period remains applicable to the
device even if repairs are carried out or parts are replaced. In such cases,
the work performed or parts tted will not result in an extension of the
guarantee period, and no new guarantee will become active for the work
performed or parts tted. This also applies if an on-site service is used.
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST
RETURN THE PRODUCT TO THE PLACE OF PURCHASE WITH YOUR
Please refer to the restrictions of this warranty concerning wearing parts,
consumables and missing parts as set out in the service information in
these operating instructions.
CUSTOMER SERVICE HELPLINE
a) Wear ear protection. The impact of noise can cause damage to hearing.
b) Use the additional handles supplied with the tool. Losing control of the tool can cause
c) Hold the equipment by the insulated handles when carrying out work during which the
plug-in tool could strike concealed power cables or its own mains lead. Contact with a live
cable can also make the metal parts of the equipment live and will cause an electric shock.
• Check that your mains voltage is the same as that marked on the rating plate.
• If you use a cable reel, run all the cable off the reel. The minimum conductor cross section used
• If you use this electric hammer drill outdoors you must connect it using a suitable H07RNF 3G 1.5
extension cable with a spraywater protected plug.
• Make sure of your footing, particularly when working free-handed on ladders or scaffolding.
• Use a detector to localize pipes and/or cables in walls with concealed electric, water or gas lines.
Avoid any contact with conducting electrical parts or lines.
• Wear ear-muffs to protect your hearing: Risk of progressive loss of hearing!
• Wear goggles and use a breathing mask on dusty jobs.
• Never use the machine near vapors or combustible liquids.
• Always unplug the machine before cleaning it or changing drill bits etc.
• Keep the power cable safe from damage. Oil and acids can damage cables.
• Never overload the machine.
• Important! Follow all safety regulations in your country applicable to the installation, use and
maintenance of the machine.
• Chisel bits and drill bits can be inadvertently thrown out from the machine and cause serious
• Always check that the chisel bit or drill bit is rmly locked in the chuck before you start work.
• Check the chuck for wear or damage at regular intervals.
• Do not start a hammering tool until it is pressed against a workpiece (wall, ceiling, etc.).
• Always unplug the hammer drill when you have nished working and remove the chisel bit or drill
• Always unplug the machine before changing chisel bits or drill bits etc.
• Protect eyes and assistants from small ying parts and splinters. Wear a helmet! Erect a screen
• Use work gloves to protect ngers from crushing and skin from grazing.
• Vibrations can be harmful to the hand-arm system: Keep the impact time of vibrations to a
• Always keep the power cable away from where you want to drill.
• Keep the machine out of children’s reach.
• Always hold the machine with two hands when it is running and make sure of your footing.
• Make sure that the switch on the machine is set to the correct position for the work you want to
perform before you put the machine into operation. If the switch is not in the correct position you
risk suffering bodily injury when the machine starts to run.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
ROTARY HAMMER DRILL SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency,
before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
Before you connect the equipment to the mains supply make sure that the data on the rating plate are
identical to the mains data.
This tool is double insulated therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The
insulation system is for added protection against injury resulting from a possible electrical insulation failure
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not
suitable for the power input of the tool or which is damaged or defective may result in a risk of re and electric
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! “Read all safety warnings, instructions, illustrations and specications
provided with this power tool.” Failure to follow the warnings and instructions may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and
ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or remove the battery pack, if detachable, from
the power tool before making any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
e. Maintain power tools and accessories. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained power
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
a. Have your power tool serviced by a qualied repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
MAINTENANCE TROUBLE SHOOTING
• Keep the ventilation vents of the drill clean at all times.
• After each use, blow air through the drill housing to ensure it is free from all
dust particles which may build up. Build up of dust particles may cause the
drill to overheat and fail.
• If the enclosure of the drill requires cleaning, do not use solvents but a moist
soft cloth only. Never let any liquid get inside the drill; never immerse any part
of the drill into a liquid.
Gear Box Grease Replenishment
The grease in the gearbox will require replenishment after approximately 50
hours accumulative use. After this time, add approximately 50 grams (approx
2 – 3 teaspoons) of the grease, into the gearbox. First remove the grease
cap from the drill by using the pin spanner. Once removed, add the grease
through this hole. Ensure the grease cap is secured back into position prior
to operation. Further grease (normal ball bearing grease) can be purchased
through your local Bunnings Warehouse.
When the carbon brushes wear out, the drill will spark and/or stop. Discontinue
use as soon as this happens. They should be replaced prior to recommencing
use of the drill. Carbon brushes are a wearing
component of the drill therefore not covered under
warranty. Continuing to use the drill when carbon
brushes need to be replaced may cause permanent
damage to the drill. Carbon brushes will wear out
after many uses but when the carbon brushes
need to be replaced, take the drill to an electrician
or a power tool repairer for a quick and low cost
replacement. Always replace both carbon brushes at the same time.
Note: Ozito Industries will not be responsible for any damage or injuries caused
by the repair of the drill by an unauthorised person or by mishandling of the
No power supplied Make sure all plugs are
outlet is in working order
Spare parts can be ordered from the Special Orders
Desk at your local Bunnings Warehouse or Homebase
For further information, or any parts visit
www.ozito-diy.co.uk or contact Ozito Customer Service:
Great Britain: 0151 294 4488
E-mail: info@ozito-diy.co.uk
Danger! Read the operating instructions to reduce the risk of
Caution! Wear ear-muffs. The impact of noise can cause
Caution! Wear a breathing mask. Dust which is injurious to
health can be generated when working on wood and other
materials. Never use the device to work on any materials
Caution! Wear safety goggles. Sparks generated during
working or splinters, chips and dust emitted by the device can
Select between the individual functions only when the
equipment is at a standstill. If you fail to observe this
point, the equipment may be damaged.
Please note that the following parts of this product are subject to normal
or natural wear and that the following parts are therefore also required
* Not necessarily included in the scope of delivery!
Wear parts* Carbon brushes, chuck
Consumables* Drill bits, chisels
DECLARATION OF CONFORMITY
Never place any electric power tools in your household refuse.
To comply with European Directive 2012/19/EC concerning old electric
and electronic equipment and its implementation in national laws, old
electric power tools have to be separated from other waste and disposed
of in an environment-friendly fashion, e.g. by taking to a recycling depot.
Recycling alternative to the return request:
As an alternative to returning the equipment to the manufacturer, the
owner of the electrical equipment must make sure that the equipment is
properly disposed of if p1-he no longer wants to keep the equipment. The old
equipment can be returned to a suitable collection point that will dispose
of the equipment in accordance with the national recycling and waste
disposal regulations. This does not apply to any accessories or aids
without electrical components supplied with the old equipment.
The reprinting or reproduction by any other means, in whole or in part, of
documentation and papers accompanying products is permitted only with
the express consent of the iSC GmbH.
Subject to technical changes
Sound and vibration values were measured in accordance with EN
sound pressure level: 92.4 dB
The hammer drill is not designed for outdoors use as specied I Article 3
of Directive 2000/14/EC_2005/88/EC.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions) determined in
accordance with EN 60745.
Hammer drilling in concrete
Vibration emission value ah = 17.571 m/s
Vibration emission value ah = 17.120 m/s
Keep the noise emissions and vibrations to a minimum.
• Only use appliances which are in perfect working order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever necessary.
• Switch the appliance off when it is not in use.
• Wear protective gloves.
Yang/Product-ManagementWeichselgartner/General-Manager
explains the following conformity according to EU directives and norms for
Rotary Hammer RHD-1600U (Ozito)
Standard references: EN 60745-1; EN 60745-2-6; EN 55014-1; EN 55014-2;
EN 61000-3-2; EN 61000-3-3;
Landau/Isar, den 01.08.2017
First CE: 17 Archive-File/Record: NAPR016992
Art.-No.: 30.001.26 I.-No.: 11017 R. GehardDocuments registrar:
Subject to change without notice Wiesenweg 22, D-94405 Landau/Isar
ISC GmbH · Eschenstraße 6 · D-94405 Landau/Isar
