Panasonic FY-AC-STD-SPP Manual

Panasonic Ventilator FY-AC-STD-SPP

Læs gratis den danske manual til Panasonic FY-AC-STD-SPP (28 sider) i kategorien Ventilator. Denne vejledning er vurderet som hjælpsom af 57 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 29 anmeldelser. Har du et spørgsmål om Panasonic FY-AC-STD-SPP, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/28

INSTALLATION AND

OPERATING INSTRUCTIONS

HƯỚNG DẪN LẮP ĐẶT

VÀ SỬ DỤNG

Air Curtain

QỤAT CHẮN GIÓ

Model No.

Model

FY-3509U1 FY-3512U1

FY-4009U1 FY-4012U1

Contents

Safety instructions ....................... 2

Installation cautions .................2

Supplied accessories .................... 4

Parts name and dimensions ......... 4

Requirement of installation .......... 5

How to install ..........................6

Multiple products operate

in group ....................................... 8

Wiring diagram ............................ 8

Operation methods ............... 8

Routine maintenance ........10

Trouble shooting........................ 12

Specifications ............................. 13

Nội dung

Hướng dẫn an toàn ........................ 14

Chú ý khi lắp đặt .......................14~15

Phụ kiện kèm theo .........................16

Phụ tùng và kích thước ...................16

Yêu cầu lắp đặt .............................17

Cách lắp đặt ............................18~19

Kt hp nhiu qut chắn gi

hot đng .....................................20

Sơ đồ đi dây .................................20

Cách vận hành ......................20~21

Bảo dưỡng định kỳ .............. 22~23

Khắc phục sự cố ............................24

Thông số kỹ thuật ..........................25

Thank you for purchasing this Panasonic product.

Please read these installation and operating instructions carefully before attempting

to install, operate or service the Panasonic product. Please carefully read the

“Installation cautions” (P.2

3) of this installation and operating instructions before

installation. Failure to comply with installation and operating instructions could result

in personal injury or property damage. Please explain to users how to operate and

maintain the product after installation, and this booklet should be presented to users.

Please retain this booklet for future reference.

Cảm ơn Quý khách hàng đã mua sản phẩm của Panasonic.

Vui lòng đọc kỹ hướng dẫn lắp đặt và sử dụng này trước khi lắp, vận hành hoặc bảo dưỡng sản

phẩm Panasonic. Vui lòng đọc kỹ “Chú ý khi lắp đặt” (Trang 14~15) trong sách Hướng dẫn lắp đặt

và Hướng dẫn sử dụng này trước khi lắp. Vui lòng tuân thủ theo hướng dẫn lắp đặt và sử dụng để

tránh thương tích và thiệt hi v tài sản. Vui lòng giải thích cho người dùng cách vận hàng, bảo

dưỡng sản phẩm sau khi lắp đặt và đưa cuốn Hướng dẫn lắp đặt và sử dụng này cho người mua.

Đ nghị bảo quản cẩn thận sách hướng dẫn này.

■If the supply cord is damaged, it must be replaced by the manufacturer,

its service agent or similarly qualified persons in order to avoid a hazard.

■This product is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction

concerning use of the product by a person responsible for their safety.

■Children should be supervised to ensure that they do not play with the

product.

■Make sure to disconnect the power supply before cleaning the product.

The following explanations must always be observed in order to prevent harm to

users or other people and prevent damage to property.

■The following displays are classified and explained to what extent harm or damage

occurs when the display details are ignored and the unit in question is wrongly used.

WARNING

This indication means: Must be treated seriously that

this may result in death or serious injury.

CAUTION

This indication means: Must be treated seriously that

this may result in injury or property damage.

■The types of details to be observed are classified and explained in the following

illustrated displays. (Below are the series of illustrated displays)

This symbol indicates the

“COMPULSORY” item that must

be followed without failure.

This symbol indicates the item

“PROHIBITED” to do.

Safety instructions

Please observe strictly

Installation cautions

■Please install an all-pole switch which

the contact separation is more than

3mm (Double pole switch).

Otherwise, it may cause

a short circuit, thus

resulting a fire.

■Do not operate the product other

than the rated voltage.

Otherwise, it may damage the

product or cause fire.

■The product must be grounded.

Otherwise, it may cause electric

shock when there is any trouble

or electric leakage.

■Wiring should be firmly connected

without any loose.

Otherwise, it may cause a short

circuit, thus resulting a fire.

■Installation should be done by

authorized person. The product

should be installed firmly.

Otherwise, the product may fall

down and it may cause injury.

■Do not reconstruct this product.

Otherwise, it may cause damage

to the product or injury.

WARNING
