( RH Display)
Ref.No.
：
022016
PCE-780 Infrare ermometer with Relative Humidity Operati nstructiond Th ng I
PCE Americas Inc.
711 Commerce Way
Jupiter
FL-33458
USA
From outside US: +1
Tel: (561) 320-9162
Fax: (561) 320-9176
info@pce-americas.com
www.pce-instruments.com/english
www.pce-instruments.com
PCE Instruments UK Ltd.
Units 12/13
Southpoint Business Park
Ensign way
Hampshire / Southampton
United Kingdom, SO31 4RF
From outside UK: +44
Tel: (0) 2380 98703 0
Fax: (0) 2380 98703 9
info@industrial-needs.com
Manual
Infrared Thermometer
PCE-780
The thermometer is a non contact infrared thermometer. There are many mathematical modes for the Infrared function3&( - .
Please remember to keep away from children and don’t use it for safety related applications.
Simply aim the thermometer at the measure target with Lens (
○
○
○
○○
10
E
A
) and press Meas. key (
○
○
○
○○
8
E
A
) to display the surface
temperature. The Distance:Spot is 1 Please make sure the target area is within the field of view2:1. .
FUNCTION
Press Mode key (
○
○
○
○○
4
E
A
) for scrolling more display function as follows.
Here will show the emissivity data. (The default emissivity is 0.95.)
Press Mode key (
A
○
4
E
A
) , then press Up key (
A
○
2
E
A
) or Down key (
A
○
3
E
A
) to set the emissivity, then press Mode key (
A
○
4
E
A
)
to confirm it. The emissivity can be changed from 0.10 (10E) to 1 (100E).
Press Mode key (
A
○
4
E
A
) for the Maximum (MAX), Minimum (MIN), Different between MAX and MIN (DIF)
and
Average (AVG) modes. During the measurement, the special modes reading wi
ll be displayed beside the
mode icon.
Press Up key (
A
○
2
E
A
) or Down key (
A
○
3
E
A
) to change the High Alarm (HAL) or Lo Alarm (LAL), then press Meas. key
(
A
○
8
E
A
) to confirm it. When or the reading is outside the High Alarm (HAL) Lo Alarm (LAL)
limit. The High or Low
icon will flash and you will hear a beep sound.
Connect the thermocouple with Thermocouple socket (
A
○
5
E
A
) and put probe in/on the target, the thermometer will the
display the temperature automatically
without pressing any button. To see the minimum or maximum data during
the probe measurement, please hold down the Up key (
A
○
2
E
A
) or Down key (
A
○
3
E
A
).
After measure high temp, the probe may remain HOT for a while.
Press Mode key (
A
○
4
E
A
) for the RH% Mode, then press Up key (
A
○
2
E
A
) for (DBT dry bulb temperature), DPT (dew point
temperature), WBT(wet bulb temperature)
modes. During the measurement, the special modes reading will be
displayed beside the mode icon.
** The thermometer will automatically shut off if left idle for more than 60sec, unless in PRB mode. (In PRB mode, it will shut off if
left idle for more than 12 minutes.)
ADD VALUE
0B
In E,MAX, MIN, DIF, AVG
mode:
1B
Press Up key (
○
2
) ON/OFF.for LOCK mode The lock mode is particularly useful for continuous
monitoring of temperatures for up to 60 minutes.
2B
Press Down key (○
3
) for
o
C or
o
F transferred.
3B
In all modes: First hold
on the Meas. key (
○
○
○
○○
8
)
and press Up key (
A
○
2
E
A
) for backlight function ON/OFF.
and press Down key (
A
○
3
E
A
) for laser function ON/OFF.
CAUTION
1. WHEN DEVICE IS IN USE, DO NOT LOOK DIRECTLY INTO THE LASER BEAM PERMANENT EYE DAMAGE MAY RESULT.–
2. USE EXTREME CAUTION WHEN OPERATING THE LASER.
3. NEVER POINT THE DEVICE TOWARDS ANYONE’S EYES.
4. KEEP OUT OF REACH OF ALL CHILDREN.
STORAGE & CLEANING
It should be stored at room temperature. The sensor lens is the most delicate part of the thermometer. The lens should be kept
clean at all times, care should be taken when cleaning the lens using only a soft cloth or cotton swab with water or medical alcohol,
allowing the lens to fully dry before using the thermometer. Do not submerge any part of the thermometer.
LCD ERROR MESSAGES
The thermometer incorporates visual diagnostic messages as follows:
‘ ’ ’ ’ Hi or Lo is displayed when the temperature being measured is outside of the settings of HAL and
LAL.
「
」 「 」
‘Er2’ is displayed when the thermometer is exposed to rapid changes in the ambient temperature. ‘Er3’
is displayed when the ambient temperature exceeds 0
o
C °F) (32 or +50
o
C ( 122°F).
The thermometer
should be allowed plenty of time (minimum 30 minutes) to stabilize to the working/room temperature.
「
」
Error 5~9, for
all other error messages it is necessary to reset the thermometer. To reset it, turn the
instrument off, remove the battery and wait for a minimum of one minute, reinsert the battery and
turn
on. If the error message remains contact the Service Department for further assistance.please
「 」」「
‘ ’ ’ ’ Hi or Lo is displayed when the temperature being measured is outside of the measurement range.
BATTERIES
The thermometer incorporates visual low battery indication as follows:
‘ ’ Battery OK : measurements
are possible
‘ ’ Battery Low : battery needs to be
replaced, measurements are still possible
‘ ’Battery Exhausted : measurements are not
possible
‘ ’ When the Low Battery icon indicates the battery is low, the battery should be replaced immediately with AAA, 1.5V batteries.
Please note: It is important to turn the instrument off before replacing the battery otherwise the thermometer may malfunction.
Dispose of used battery promptly and keep away from children.
SPECIFICATION PCE-780
Item - Non contact Infrared Scan function
Thermocouple Probe Scan function
(K type; probe not included.)
Measurement Range
-60 to +500
o
C (-76 to +932
o
F)
- (- ) 64 to +1400°C 83.2 to +1999°F
Operating Range
0 ( t ) to +50°C 32 o +122°F
Accuracy
(Tobj=15~35°C, Tamb=25°C )
±1.0°C ° (1.8 F)
+/- °1% of reading or 1°C (1.8 F)
whichever
is greater (Test under
Tamb=23±6°C)
Accuracy
(Tobj= 33 500- ~ °C T, amb 23= ±3 ) °C
Tobj=0~500 2°C°C: ±2% of reading or °(4
F) whichever is
greater Tobj; =-60~0
o
C: +/- (2°C+0.05/degree) °C
Emissivity Range
0.95 default adjustable 0.1 to 1 step .01–
Resolution 9.9~199.9°C (- /°F)
0.1 1°F°C/0. , otherwise 1°C/1°F
Response Time (90%)
1sec
D istance pot:S 12:1(90% energy covered)
Relative Humidity Tamb=23+/ 5degC) ( -
1~ 5%99%, accuracy: +/ 3% from 20~80%, otherwise+/- -
Dew point
- 50~50°C, accuracy: ±2.5°C from 20~30%RH; ±2°C from 31~40%RH; ±1.5°C from 41~95 %RH
D ry bulb temperature
- 20~65°C, accuracy: ±2.5°C
W - et bulb temperature 20~65°C, accuracy: ±2.5°C
Battery Life
Typ.180, min 140 hours continuous use (Alkaline, without Laser and Back Light.)
Dimensions
46.0 x 143.0 x 184.8mm(1.81×5.63×7.28 inch)
Weight
2 40 grams(8.5 oz) including batteries (AAA*2pcs)
Note: Under the electromagnetic field of 3V/m from 200 to 600 MHz, the maximum error is 10
o
o
F).
EMC/RF
I
I
I
II
: Readings may be affected if the unit is operated within frequency electromagnetic fieldradio
strength of approximately 3 volts per , but the performance of the instrument will not meter
be permanently affected.
( T DP Display)
