Side 1/6

PRODUCT SPECIFICATION

camera solutions

C4066 / New 2-26-20

Sarix

IMP Indoor and Environmental Domes

UP TO 5 MP, H.265, H.264, WDR, DAY/NIGHT IP DOMES

Product Features

• H.265, H.264 Main, High, MJPEG video encoding

• Up to 5 MP resolution at 30 frames per second

• Up to 60 frames per second (ips) at 4 MP for 5 MP cameras

• Autofocus motorized remote zoom lens

• Integrated adaptive IR illumination up to 50 m (some models)

• Operating temperature up to 60°C (140°F) (environmental models)

• Micro SDHC and SDXC card up to 2 TB addressable, 128 GB testable

• Pelco Pro Analytics Suite including Adaptive Motion, Object

Counting, Motion Detection, Camera Sabotage

• Power over Ethernet (PoE or PoE+), 24 VAC, 12 VDC

• Pelco Smart Compression Technology

• All models vandal resistant to IK10

• Compatible with Pelco and third-party video management systems

• ONVIF Profile S, Profile G, Profile Q, and Profile T conformant

• Full 3-year warranty

Sarix Professional Range

Powerful, versatile, and affordable, the Sarix

Professional (P)

range cameras pack the most popular features and functionality of

Sarix technology into a wide range of indoor and outdoor options,

including bullet cameras and domes. There is also a vandal resistant

wedge camera and a box camera. Mix and match the performance

options and form factor you need for almost any lighting condition,

environment, and application.

IMP Dome Series Camera

Within the Sarix Professional range, the Sarix IMP Series dome

cameras feature a remote zoom lens for wide angle or long range

surveillance needs. Autofocus capability ensures the camera can be

automatically refocused when needed. Additionally, the Sarix IMP

Series features advanced color science and true WDR, optional

adaptive IR illumination for increased visibility in difficult lighting

conditions. IK10 vandal resistant on both indoor and outdoor domes

and IP66/IP67 on the outdoor dome ensures enough robustness for

installation in challenging environments.

Video

Sarix Professional provides options for three simultaneous video

streams. The three streams can be compressed with efficient H.265,

H.264 High or Main profiles, or MJPEG formats. The streams can be

configured to a variety of frame rates and variable bit rates to

optimize image quality with bandwidth and storage efficiency. Pelco

Smart Compression is available on both H.264 and H.265, minimizing

storage and bandwidth utilization.

Edge Storage

Sarix Professional range cameras feature onboard edge storage

with a micro SDHC and SDXC card. Video clips of varying lengths can

be stored to the card upon alarm, or video can be written

continuously to the SD card in the case of network outage. Video can

be retrieved from the card through the FTP protocol or by using an

ONVIF Profile G compliant client.

Open and Integrated

Sarix Professional range cameras seamlessly connect to Pelco

video management systems such as VideoXpert

™

, VXToolbox,

Endura

version 2.0 (or later), and Digital Sentry

version 7.3 (or

later). Sarix Professional range cameras integrate with major

third-party systems through the open Pelco API or the ONVIF Profile

S, Profile G, Profile Q, and Profile T standards.

Standard Web Interface

Pelco cameras use a standard Web browser interface for easy

remote setup and administration. Controls are optimized for

convenient one-step camera configuration for features including

color, exposure, flicker control, backlight compensation, and

streaming.

TECHNICAL SPECIFICATIONS

BACK BOX FEATURES

VALUES IN PARENTHESES ARE INCHES; ALL OTHERS ARE CENTIMETERS.

Indoor Surface Mount

• Aluminum Body and Trim Ring; Polycarbonate Bubble

• RAL 9003

• IK10 (20J) Impact Resistance

• IEEE802.3af PoE, 18 ~ 32 VAC, 12 +/-10% VDC

• IR Illumination 50 m

• IP 64 Ingress Protection

Environmental Surface Mount

• Aluminum Body and Trim Ring; Polycarbonate Bubble

• RAL 9003

• Type 4X, When Used with IMP3EBAP

• IK10 (20J) Impact Resistance

• IEEE802.3at PoE, 18 ~ 32 VAC, 12 +/-10% VDC

• IR Illumination 50 Meters

• IP66, IP67 Ingress Protection

12.41

(4.88)

8.73

(3.44)

6.19

(2.44)

13.50

(5.31)

6.21

(2.45)

3.67

(1.44)

12.41

(4.88)

8.73

(3.44)

6.19

(2.44)

13.50

(5.31)

6.21

(2.45)

3.67

(1.44)

9003

18.0

(7.09)

12.0

(4.72)

8.1

(3.19)

3.5

(1.38)

11.15

(4.39)

14.0

(5.5)

14.0

(5.5)

4.375

(1.72)

4.15

(1.63)

2.85

(1.12)

11. 0

(4.33)

2.3

(0.9)

4.1

(1.61)

4.1

(1.61)

2.3

(0.9)

0.3

(0.12)

Ø 3.0

(1.18)

Ø 0.43

(0.170)

17.95

(7.07)

16.3

(6.41)

6.0

(2.4)

6.34

(2.50)

6.79

(2.67)

19.1

(7.52)

3.43

(1.35)

3.0

(1.18)

2.3

(0.9)

4.4

(1.73)

4.15

(1.63)

8.15

(3.21)

21.59

(8.50)

NPT 1 1/2"-11.5

15.07

(5.93)

8.30

(3.27)

Ø 4.4

(1.73)

5.0

(1.96)

10.01

(3.98)

8.3

(3.27)

4.6

(1.81)

IMP3PMB-1I WALL MOUNT BRACKET

IMP3PM-1E PENDANT MOUNT

IMP3ICM-1E IN-CEILING BRACKET

Color: RAL 9003

Ø 22.21

(8.75)

ØA

0.73

(0.29)

1.45

(0.57)

IMP3ICM-1E CEILING PLATE

Color: RAL 9003
