Side 1/47

www.philips.com/welcome

55BDL3202H

V1.00

User Manual (English)

55BDL3202H

Safety Instructions

Safety precautions and maintenance

WARNING: Use of controls, adjustments or procedures other than those specied in this documentation may

result in exposure to shock, electrical hazards and/or mechanical hazards.

Read and follow these instructions when connecting and using your display:

Operation:

• Keep the display out of direct sunlight and away from stoves or any other heat sources.

• It is recommended to set the display up in the well-ventilated place.

• Ultra-violet ray lter is necessary of outdoor operation.

• If the product will be used in extreme conditions such as high temperature, humidity, display patterns or operation time

etc... It is strongly recommended to contact Philips for Application engineering advice. Otherwise, its reliability and function

may not be guaranteed. Extreme conditions are commonly found at Airports, Transit Stations, Banks, Stock market, and

Controlling systems.

• Remove any object that could fall into ventilation holes or prevent proper cooling of the display’s electronics.

• Do not block the ventilation holes on the cabinet.

• When positioning the display, make sure the power plug and outlet are easily accessible.

• When turning o the display by detaching the power cord, wait 6 seconds before re-attaching the power cord for normal

operation.

• Ensure the use of an approved power cord provided by Philips at all times. If your power cord is missing, please contact your

local service center.

• Do not subject the display to severe vibration or high impact conditions during operation.

• Do not knock or drop the display during operation or transportation.

• The eye bolt is for usage in short-time maintenance and installation. We suggest not to use the eye bolt for more than 1 hour.

Prolong usage is prohibited. Please keep a clear safety area under the display while using the eye bolt.

Maintenance:

• To protect your display from possible damage, do not put excessive pressure on the LCD panel. When moving your display,

grasp the frame to lift; do not lift the display by placing your hand or ngers on the LCD panel.

• Unplug the display if you are not going to use it for an extensive period of time.

• Unplug the display if you need to clean it with a slightly damp cloth. The screen may be wiped with a dry cloth when the

power is o. However, never use organic solvent, such as, alcohol, or ammonia-based liquids to clean your display.

• To avoid the risk of shock or permanent damage to the set, do not expose the display to dust, rain, water or an excessively

moist environment.

• If your display becomes wet, wipe it with dry cloth as soon as possible.

• If a foreign substance or water gets in your display, turn the power o immediately and disconnect the power cord. Then

remove the foreign substance or water, and send the unit to the maintenance center.

• Do not store or use the display in locations exposed to heat, direct sunlight or extreme cold.

• In order to maintain the best performance of your display and ensure a longer lifetime, we strongly recommend using the

display in a location that falls within the following temperature and humidity ranges.

Environmental absolute ratings

Item Min. Max. Unit

Storage temperature -20 65 °C

Operation temperature 0 40 °C

Glass Suraface temperature

(Operation)

0 65 °C

Storage humidity 5 90 % RH

Operating humidity 20 80 % RH

• LCD panel temperature need to be 25 degrees Celsius at all time for better luminance performance.

Produkt Specifikationer

Mærke:	Philips
Kategori:	Skærm
Model:	Signage Solutions 55BDL3202H
Bredde:	1243.2 mm
Dybde:	137.9 mm
Højde:	714 mm
Vægt:	32200 g
Produktfarve:	Sort
Skærm diagonal:	54.6 "
Skærmopløsning:	1920 x 1080 pixel
Berøringsskærm:	Ingen
Wi-Fi:	Ingen
USB-port:	Ja
HD-type:	Fuld HD
Skærmteknologi:	LED
Naturligt aspektforhold:	16:9
Skærmens lysstyrke:	2500 cd/m²
Responstid:	6 ms
Synsvinkel, horisontal:	178 °
Synsvinkel, vertikal:	178 °
Skærm diagonal (metrisk):	138.7 cm
LED-baggrundsbelysning type:	Direct-LED
Indbyggede højttaler(e):	Ja
Relativ luftfugtighed ved drift (H-H):	20 - 80 %
Udgangseffekt (RMS):	20 W
Antal HDMI-porte:	2
DVI-port:	Ja
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	1
Komponentvideo (YPbPr/YCbCr) indgang:	1
Ethernet LAN:	Ja
Skærmvisning (OSD):	Ja
Antal OSD sprog:	14
OSD-sprog:	ARA, CHI (SIMPL), CHI (TR), DEU, DUT, ENG, FRE, ITA, JPN, POL, POR, RUS, TUR
Understøttede videoformater:	M2TS, M4V, MKV, MP4, MPEG, MPG, MTS, TS, VOB
Understøttede lydformater:	AAC, LPCM, M4A, MP3, WMA
VESA montering:	Ja
Panel montering grænseflade:	400 x 400 mm
Strømforbrug (standby):	0.5 W
Strømforbrug (typisk):	280 W
Driftstemperatur (T-T):	0 - 40 °C
Kabler inkluderet:	RS-232
Batterier inkluderet:	Ja
Understøttede billedformater:	BMP, GIF, JPEG, PNG
Fjernbetjening inkluderet:	Ja
Kan monteres på væggen:	Ja
Harmoniseret systemkode (HS):	85285210
Antal indbyggede højttalere:	2
Billedformat:	16:9
Vis antal farver:	16,78 millioner farver
Maksimum billedhastighed:	60 fps
Lyd (L, R) indgang:	1
Kontrastforhold (typisk):	5000:1
Kontrastforhold (dynamisk):	500000:1
Pixel pitch:	0.63 x 0.63 mm
HDMI-version:	1.4
DisplayPort-version:	1.2
Antal DisplayPorts:	2
AC (strøm) indgang:	Ja
Lyd (L, R) udgang:	1
Monteringssæt:	Ja
Gennemsnitstid mellem fejl (MTBF):	50000 t
Indbygget processer:	Ingen
Produktdesign:	Digital fladpaneldisplay
VGA (D-Sub) indgangsporte:	1
RS-232 indgangsporte:	1
Antal DVI-I-porte:	1
Egnet til udendørs brug:	Ja
RS-232 grænseflade:	Ja
Antal HDMI-indgangsporte:	2
RS-232 udgangsporte:	1
Computersystem:	Ja
RS-232C:	Ja
Orientering:	Landskab/portræt
Grundfarve:	Sort
RJ-45 udgangs-porte:	1
DVI indgangs-porte:	1
DVI udgangs-porte:	1
DisplayPorts indgang:	1
DisplayPorts udgang:	1
Skærmbredde:	1243.2 mm
Skærm, dybde:	137.9 mm
Skærm, højde:	714 mm
Skærm, vægt:	32200 g
Antal displays:	1
Computersystem type:	System på chip (SoC)
Flisebelagt bredde:	15.8 mm
