Side 1/5

45$"GP

%GGLDCAQGML4LGQ

indoor

50Hz

60Hz

220V

240V

Max.

40 °C

Min.

°C

89&$

1/5

Type Desc

Power

Lamp

Holder

Ballast

Shading cloth

UVCA200 EU

UVCA200 UKI

120W

4×TUV PL-L 18W

9279 030 04007

2G11

HF-P218

/236

9114 0

18 21890

9114 018 20890 12.3

V-C wavelength

54nm

1 – Control panel

2 – Air outlet

3 – Body

4 – Air inlet

5 – Timing

6 – Fan speed light

7 – UV working light

8 – Power switch

9 – Lock

10 – Timing switch

11 – Fan speed control

Operation

1. Plug in

Plug in the power cord, power the machine, the buzzer will beep, at the same time, the power key indicator is always on, indicating the success of power.

2. Power on/off

Power on: touch the power on key to start the machine when it is off. Default display mode is:

A. The fan speed indicator is on 2/3, and the fan speed is in gear 2;

B. The UV indicator is on and the UV lamp is in working state;

C. The time indicator is "060", indicating that the disinfection time is 60 minutes, and the machine will automatically shut down after 60 minutes.

Power off: to shut down the product before disinfection duration is finished, please press the power switch button. Only the power indicator will remain on

while all the rest will turn off with notification tone.

3. Fan Speed Button

Press fan speed button to select the fan speed, 1 (low speed), /2 (medium speed), /3 (Max speed). The product starts quickly and smoothly and can reach the

maximum air volume within 20 seconds (if set to the maximum speed).

4. Timing Settings

Press Timer button to select disinfection duration, ON-30min-60min-120min as a cycle.

5. Lock

Long press the lock key above 3s, and the lock indicator light will always be on, indicating that the lock mode has started. At this point, pressing any key is

invalid (the lock indicator will flash 3 times when pressing any key). Long press the lock key above 3s to exit the lock mode. You can also exit the lock mode by

removing the power or when disinfection duration is finished.

UKI

12NC

9114 015 48581

9114 015 48681

5

Visible marking on product:

Application and safety precautions

• Warning: UV-C emitted from this product. Avoid eye and skin exposure to unshielded product. Follow installation instructions and user

manual.

• Warning: these UV-C products are not meant to be used in applications or activities which may cause and/or lead to death, personal injury

and/or damage to the environment.

• Warning: Products not designed and/or intended to be used to disinfect medical devices or for medical purposes; Signify excludes any and

all liability for any such improper use.

• This UV-C product is intended to be used for the disinfection of Indoor air.

• The back cover must be closed properly before disinfection, otherwise the UVC lamp will not work.

• There should be no light leakage at the air inlet on the side of the body. If there is, please check whether the carbon cloth is installed

correctly.

• Contact manufacturer or its maintenance department and other similar professionals for repair.

• If the power cord is damaged, it must be replaced with a dedicated cord or with a dedicated component purchased from its manufacturer

or maintenance department.

• Lamps include Mercury. If a lamp breaks, ventilate the room for 30 minutes and remove the parts, preferably with gloves. Put them in a

sealed plastic bag and take it to your local waste facilities for recycling. Do not use a vacuum cleaner. Please follow User Manual.

• UVC Exposed luminaire parts (other than metal parts), like Lamp holder, end cap etc. might change color after a certain period of usage due

to the UV-C light property.

• UV-C light emitted from UVC lamp is much “stronger” than normal sunlight and can cause a severe sunburn-like reaction to your skin, and

similarly, could damage the retina of your eye, if exposed.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible

for their safety.

• Children should be supervised to ensure that they do not play with the appliance.

Lamp/Ballast/Shading cloth replacement

1. Only those who have received instruction training can replace the relevant parts. Contact Signify dealer or the designated after-sales

service.

2. Turn off the power supply and unplug product before changing the lamp or connection! Ensure to put on gloves when installing the device

or replacing the lamp.

*Use only Philips brand TUV lamps. TUV lamp type: 927903004007 TUV PL-L 18W/4P 1CT/25; TUV lamp lifetime: 9000h

UVC lamp error code

The UVC light will be on after power on, the UV working light will be kept on. When the lamp is damaged, the UV indicator flashes, and the display area is showing

the following error code:

Shading cloth error code

Error code will be displayed after the accumulated working time of the product reaches 9000 hours. The product cannot be started. At this time, the shading cloth

must be replaced.

For example, the panel displays

"E8", indicating that the lamps

1, 3 and 4 are broken. The tube

indicator code is at the base of

the UV lamp holder.

* Display will show the error code when max. 3pcs lamps are failure for UVCA200

or max. Meanwhile the product can keep at working status with error code display.

The display will show the timing for 10secs after pressing timer button, then come

back to error code display mode.

If all the lamps are damaged, the product cannot start with dedicated error code

display.
