Models: Z150.2 - Z300.1 - Z300.4 - Z600.5 - Z1000.1
Z-Series
Ampliers
Integrated Cooling Fan - Regulates amplier temperature for sustained performance
High & Low Level Inputs - Versatile connectivity to suit any vehicle (ZRHC High Level Adaptor required) - sold separately
OEM Connection Ready - Compatible with aftermarket or original t source units
High Level Auto-Turn On - Powers on the amplier when an audio signal is supplied (via the ZRHC High Level Adaptor)
Remote Bass Ready - Control the Bass Level with the ZRBC (sold separately)
4-Way Protection Circuit - Thermal / Reversed Power and Speaker Polarity / Low Voltage
Heavy Duty Connector Block - Enables Maximum Current Supply
Ventilateur de refroidissement intégré - Régule la température de l’amplicateur pour une performance soutenue
Entrées haute et basse - Connectivité polyvalente pour tous les véhicules (ZRHC Haut niveau Adaptateur
requis) - vendu séparément
Prêt pour une connexion OEM - Compatible avec les unités d’origine et de rechange.
Mise sous tension automatique à haut niveau - Allume l’amplicateur lorsqu’un signal audio est détecté
(via l’adaptateur ZRHC de haut niveau)
Prêt pour la commande des graves à distance - Contrôle du niveau des graves avec le ZRBC (vendu séparément)
Circuit de protection 4-voies - Puissance thermale/inversée et haut-parleur Polarité/Basse tension.
Bloc de connecteur robuste - Permet une alimentation maximale
Ventilador de Refrigeración Integrado - Regula la temperatura del amplicador para mantener su buen rendimiento
Entradas de Alto y Bajo Nivel - Conectividad versátil para adaptarse a cualquier vehículo (Se requiere de un
Adaptador ZRHC de Alto Nivel) – El mismo se vende por separado
Conexión de OEM Lista - Compatible con unidades originales o de segunda mano.
Encendido Automático de Alto Nivel - Se enciende el amplicador cuando se suministra una señal de audio (A través
del Adaptador de Alto Nivel ZRHC)
Control Remoto de Bajos - Controle el nivel de graves con el ZRBC (se vende por separado)
Circuito de Protección de 4 vías - Potencia térmica / retroceso y altavoz Polaridad / baja tensión.
Bloque de conector robusto - Permite una máxima potencia
Les amplicateurs de la série Z
Los amplicadores series Z
CARACTÉRISTIQUES
FEATURES
CARACTERÍSTICAS
Z-Series Ampliers
© 2017 Phoenix Gold • www.phoenixgold.com
Z300.4 Z150.2 Z300.1 Z600.5 Z1000.1
Class Class A/B Class A/B Class A/B Class A/B Class D
Power (MAX) 1200 Watts 600 Watts 1200 Watts 2400 Watts 2000 Watts
Frequency
Response
20Hz-20KHz 20Hz-20KHz 20Hz-400Hz 20Hz-20KHz 20Hz-300MHz
Dimensions (mm) 312x186x49 232x186x49 312x186x49 372x186x49 312x186x49
RMS Power
Ratings
60W x 4 @ 4ohm
75W x 4 @ 2ohm
150W x 2 @ 4ohm
bridged
60W x 2 @ 4ohm
75W x 2 @ 2ohm
150W x 1 @ 4ohm
bridged
200W x 1 @ 4ohm
300W x 1 @ 2ohm
60W x 4 @ 4ohm
+1 x 200W @ 4ohm
75W x 4 @ 2ohm
+1 x 300W @2ohm
150 x 2 @ 4ohm
bridged
+1 x 300 @ 2ohm
400w p2-x1 @ 4 ohm
700w x 1 @ 2 ohm
1000w x 1 @ 1 ohm
Signal to
Noise Ratio
>50dB >50dB >50dB >50dB >90dB
High & Low Pass
Crossover
12dB per Octave 12dB per Octave 12dB per Octave 12dB per Octave 12dB per Octave
Subsonic Filter N/A N/A 12dB per Octave 12dB per Octave 12dB per Octave
Crossover
Range
50Hz-250Hz 50Hz-250Hz 50Hz-400MHz 50Hz-250Hz (CH1,2,3,4)
50Hz-400Hz (Sub-
woofer)
30Hz to 300Hz
Subsonic
Crossover Range
N/A N/A 10Hz-40Hz 10Hz-40Hz 10Hz to 55Hz
Bass Boost
@ 45Hz
N/A N/A 0 to +18dB 0 to +18dB 0 to +18dB
Low Level
Input Range
0.35 Volts
to 10 Volts
0.35Volts to
10 Volts
0.35 Volts to
10 Volts
0.35 Volts to
10 Volts
200 millivolts to 8 volts
High Level
Input Range
1 Volt to 30 Volts 1 Volt to 30 Volts 1 Volt to 30 Volts 1 Volt to 30 Volts 200 millivolts to 20 volts
Minimum Load
Impedance
2 ohm Stereo &
4 ohm bridged
2 ohm Stereo &
4 ohm bridged
2 ohm 2 ohm Stereo &
4 ohm bridged
1 Ohm
Note:
Phoenix Gold Ampliers have a minimum load impedance
of 2ohm per channel 4ohm bridged
(except Z1000.1 - which is 1 Ohm)
