Planar LC1913RTI Manual

Planar overvåge LC1913RTI

Læs gratis den danske manual til Planar LC1913RTI (1 sider) i kategorien overvåge. Denne vejledning er vurderet som hjælpsom af 9 personer og har en gennemsnitlig bedømmelse på 4.5 stjerner ud af 5 anmeldelser. Har du et spørgsmål om Planar LC1913RTI, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/1

USB (Touch Versions)

Touch Controller

US or EU Power Supply

Video Cable







LC SERIES

QUICK START GUIDE

LC Series

Thank you for choosing Planar’s very high-bright LC

series embedded LCD monitor family.

Customer Service:

To view online documentation and frequently

asked questions, or to send an email to our

technical support staff, please visit:

http://www.planar.com/support or call

1-866-PLANAR1 (1-866-752-6271).

To receive advanced notiﬁ cation of product

updates, please register your monitor at

www.planar.com/support.

Planar is one of the world’s most accomplished

providers of ﬂ at-panel displays, with over 24

years’ expertise in ﬂ at-panel innovation. The

company provides the most dependable display

solutions for various applications in industrial,

medical, and commercial markets.

Monitor Set-up

1. If it is necessary, clean the front surface of

the display by using clean, compressed air or

by using only a clean, dry soft cloth.

2. Mount the monitor to your enclosure using

your hardware. Detailed mechanical draw-

ings, including mounting hole patterns,

may be found at:

http://www.planar.com/support

3. Securely tighten all mounting hardware.

4. Connect the video and power cables. The

unit will display a test screen the ﬁ rst time

power is applied without a video signal.

5. Power up the computer.

See the user’s guide for your product at

http://www.planar.com/support for

advanced set-up instructions.

Optional Auto Dimming

The LC17/LC19 is available with optional

auto dimming. This feature allows

the display to automatically adjust its

brightness for optimal viewing at a wide

range of ambient lighting conditions.

For additional information please

view the LC series User Guide at

www.planar.com/support.

Package Overview

Contents -

Important Recycle Instruction -

LCD Lamp(s) inside this

product contain mercury.

This product may contain other

electronic waste that can be

hazardous if not disposed of

properly. Recycle or dispose in ac-

cordance with local, state, or federal

Laws. For more information, contact

the Electronic Industries

Alliance at WWW.EIAE.ORG. For

lamp speciﬁ c disposal information

check WWW.LAMPRECYCLE.ORG.

LCD Display DVI-D Cable

The test results show that this device meets the FCC rules. Refer to the

product operation manual for FCC classiﬁ cation found at:

http://www.planar.com/support. Those limits are set to protect residential

areas from the devices with harmful emission. This device will produce,

use and radiate radio frequency energy. In addition, failure to follow

the user’s manual to install or use this device might produce harmful

interference with radio communication. Notwithstanding the foregoing,

it does not guarantee that this type of harmful interference does not

occur in some special installations. The interference caused by this device

to the reception of radio or television signals may be veriﬁ ed by turning it

on and off. Any changes or modiﬁ cations to this TFT LCD would void the

user’s authority to operate this device.

020-0605-00

36.61702G001

For best performance, set your computer video

graphics resolution to: 1280 x 1024.

European Union 2002/95/EC Directive on the Restriction

of Hazardous Substances (RoHS)

In February 2003, the European Union issued Directive 2002/95/EC on

the Restriction of Hazardous Substances, commonly known as RoHS,

in certain electrical and electronic equipment. It restricts the use of six

hazardous substances, including lead (Pb). The Directive states that all

new products within its scope, placed on the European market after

July 1, 2006 must be compliant with its requirements.

Planar Systems Inc. is fully in support of and compliant with EU Direc-

tive 2002/95/EC for applicable products within its scope. A Planar part

number will be modiﬁ ed with an “LF” sufﬁ x designation to indicate

RoHS compliance, as shown on the part number label afﬁ xed to the

display and on the box containing the display.

Power Supply

Europe & NA AC Cord

S-Video Cable Composite Video Cable

Produkt Specifikationer

Mærke:	Planar
Kategori:	overvåge
Model:	LC1913RTI
Produktfarve:	Grå
Skærm diagonal:	19 "
Skærmopløsning:	1280 x 1024 pixel
Berøringsskærm:	Ja
HD-type:	HD
Naturligt aspektforhold:	4:3
Responstid:	20 ms
Synsvinkel, horisontal:	140 °
Synsvinkel, vertikal:	140 °
Skærm form:	Flad
3D:	Ingen
Indbyggede højttaler(e):	Ingen
Udgangseffekt (RMS):	1 W
HDCP:	Ingen
VESA montering:	Ja
Panel montering grænseflade:	- mm
Strømforbrug (typisk):	70 W
Bredde (uden stativ):	410 mm
Dybde (uden stativ):	88 mm
Højde (uden stativ):	334 mm
Vægt (uden stativ):	6800 g
Driftstemperatur (T-T):	0 - 50 °C
Kabler inkluderet:	AC, Composite, DVI, VGA
Understøttede grafikopløsninger:	1280 x 1024 (SXGA)
Certificering:	CE, UL/cUL, TUV, FCC Class B, RoHS
Indbygget kamera:	Ingen
Slot til kabellås:	Ja
Billedformat:	4:3
Skærmens lysstyrke (typisk):	1150 cd/m²
Kontrastforhold (typisk):	500:1
AMD FreeSync:	Ingen
NVIDIA G-SYNC:	Ingen
Antal VGA-porte (D-sub):	1
USB-hub-version:	2.0
Antal USB type-A downstream-porte:	1
AC (strøm) indgang:	Ja
TV-tuner, integreret:	Ingen
Synlig størrelse, diagonal:	483 mm
Antal af S-video-indgange:	1
Lydudgang:	Ja
Antal DVI-D-porte:	1
Tynd klient installeret:	Ingen
