Side 1/4

C1030

LCR Ceiling Speaker

Audio Systems

OWNER’S MANUAL

Thank you for purchasing the C1030 LCR Ceiling Speaker. The

directional woofer and pivoting midrange and tweeter make

the C1030 a perfect choice for in-ceiling home cinema speaker

setups, from stereo and LCR (left-center-right), to 3.1, 5.1 and

7.1 configurations. The three-way speaker system with 10"

woofer brings you an extraordinarily robust music or cinema

experience, while the ±3dB midrange and tweeter adjustments

provide ultimate fine-tuning to room size and acoustics, or

according to personal preference.

• (1) C1030 LCR Ceiling Speaker & Grille

• (1) PCB-C1000 Mounting Bracket

• (1) Hole-Cutting Template

• (1) Paint Mask Insert

WARNING: To avoid possible injury, the PCB-C1000

Mounting Bracket must be used with the C1030

speaker for both new construction and retrofit

installations. The included mounting bracket

was specifically designed to support the weight and size of the

C1030, and to prevent it from coming loose and dropping from

the ceiling. Always use the PCB-C1000 Mounting Bracket when

installing the C1030 speaker.

INTRODUCTION PACKAGE CONTENTS

Before installing your C1030 LCR Ceiling Speaker, you should

consider its placement carefully, taking into account the

location of HVAC ducts, electrical conduit, plumbing lines,

and other fixtures. For retrofit installations, this can best be

determined by noting the placement of fixtures and gaining

access to an attic or crawl space for further analysis of the

location of such obstacles.

Prior to the actual installation of the speaker, it will be

necessary to run wiring to the speaker location. After the

wire has been properly installed, you are ready to install the

mounting bracket. For new construction, mount the speaker

after the drywall installation is complete.

Placement in Ceiling: When placing your speaker into the

ceiling, it should be located so that the fixed 15˚ angle woofer

is pointed toward the primary listening area. If the speaker is

positioned away from the primary listening area, simply adjust

the pivoting midrange and tweeter so they are pointed toward it.

Note: To avoid possible damage to the pivoting midrange and

tweeter, read the section entitled “SPEAKER ADJUSTMENTS”

in this manual prior to performing the adjustment. In very

large rooms with low ceilings, it may be necessary to place

additional speakers throughout the room for better coverage.

SPEAKER PLACEMENT & SETUP

The included PCB-C1000 Mounting Bracket is designed for both

new construction & retrofit installations. The PCB-C1000 Mounting

Bracket may be installed prior to drywall application across joists

(from 16" to 24" on-center) where a speaker will be located.

For new construction, the PCB-C1000 Mounting Bracket is also

available separately, in the event that the C1030 speaker has not

yet arrived on-site, or is otherwise not available. Always use the

PCB-C1000 Mounting Bracket when installing the C1030 speaker.

To install the mounting bracket in new construction:

1. Find the joists nearest the desired speaker mounting

location. If you need to align the speaker to some other object

or molding in the room, be sure to consider the size of the

baffle flange which extends beyond the mounting hole.

2. Line up bottom of one of the mounting bars with the

bottom of the joist. This will place the screw holes in an “L”

position, flush with the side of the joist, and the mounting ring

“lip” will be facing downward. Attach the mounting bar to the

joist using appropriate wood screws.

3. Make sure that the mounting ring is in a perfectly circular

shape by opening the bracket until the arms come in contact

with the stoppers. Then, line up the bottom of the other

mounting bar with the bottom of the same joist. Attach the

mounting bar to the joist using appropriate wood screws.

MOUNTING BRACKET INSTALLATION – NEW CONSTRUCTION (See Diagram 1)

The included PCB-C1000 Mounting Bracket is designed for

both new construction and retrofit installations. The intelligent

folding design facilitates mounting the bracket through a

speaker cut-out, therefore the mounting bracket may be

installed across 16" to 24" on-center joists after drywall is

installed. Always use the PCB-C1000 Mounting Bracket when

installing the C1030 speaker.

Retrofit Installation - Finished Ceilings

Follow the first set of instructions to prepare the mounting

surface for a professional looking installation. Then, follow the

second set of instructions for the mounting bracket installation.

To prepare the mounting surface in a retrofit installation:

1. Find the joists nearest the desired speaker mounting

location. We highly recommend using a good stud-finder tool

for this procedure. If you need to align the speakers to some

other object or molding in the room, be sure to consider the

size of the baffle flange which extends beyond the mounting

hole. Please allow 1¼" space from the joist.

2. Mark the hole. A template for setting the hole is provided in

the box (along with a paint mask insert for use when painting).

Position the template in the desired position and pencil an

outline on the ceiling.

3. Cut the hole. CAUTION: This is the most important part

of the entire installation. If you are not certain whether any

obstructions exist behind the desired mounting area, you

should start by cutting a small hole in the center of your

penciled mounting hole with a drywall saw, cutting at a 45°

angle towards the inside of the hole. (See Diagram 3) Cutting

the small hole at this angle will make drywall repair much

easier, using the piece cut out. Once you have determined that

there aren’t any obstructions in your desired mounting location,

cut the finished hole at a 90° angle to the ceiling surface.

To install the mounting bracket in a retrofit:

1. Move the mounting bars in opposite directions, so that the

mounting ring folds down to its narrowest width. Collapse the

mounting bars to their shortest length.

2. With the mounting ring lip facing downward, insert

the mounting bracket into the ceiling cavity through the

previously cut hole in the ceiling drywall.

3. Make sure that the mounting ring is in a perfectly circular

shape by opening the bracket until the arms come in contact

with the stoppers, then set it into the ceiling hole. Push one

of the mounting bar L-shaped edges until it is flush with the

joist, and the bottom of the mounting bar lines up with the

bottom of the joist. Attach the mounting bar to the joist using

appropriate wood screws.

4. Push the other mounting bar L-shaped edge until it is flush

with the same joist, and the bottom of the mounting bar lines

up with the bottom of the joist. Attach the mounting bar to

the joist using appropriate wood screws.

5. Stretch both mounting bars to reach the opposite joist, then

line up the bottoms of each mounting bar with the bottom

of the joist. Attach each mounting bar to the joist using

appropriate wood screws.

6. If the area in the ceiling is not already insulated, add an

adequate amount of insulation material to loosely cover where

the speaker will be positioned, being sure that the speaker wire

remains accessible. If the insulation material used is faced with

foil or paper, position the foil or paper away from the speaker.

4. Stretch both mounting bars to reach the opposite joist, then

line up the bottoms of each mounting bar with the bottom

of the joist. Attach each mounting bar to the joist using

appropriate wood screws.

5. To adjust the position of the mounting ring between the

joists, grab both sides of the mounting ring, where it connects

to the mounting bar, then move the mounting ring into the

desired position.

6. If the area in the ceiling is not already insulated, add an

adequate amount of insulation material to loosely cover where

the speaker will be positioned, being sure that the speaker wire

remains accessible. If the insulation material used is faced with

foil or paper, position the foil or paper away from the speaker.

Adding insulation may also be done after drywall installation.

The protruding lip of the mounting ring will force the drywall

installers to hang the drywall with an appropriate hole cut out

around the mounting ring lip. After the drywall has been hung

and finished, the speakers are then easily installed following the

instructions for mounting in “SPEAKER INSTALLATION” below.

MOUNTING BRACKET INSTALLATION – RETROFIT (See Diagrams 1, 2 & 3)

Diagram 3

Diagram 2

PCB-C1000 Closed Position

Mounting Ring Lip

Screw Holes

Mounting Ring

Mounting Bar

Diagram 1

PCB-C1000 Open Position
