Side 1/23
QS20.361
Q-Series
36V, 13A, SINGLE PHASE INPUT
May 2007 / Rev. 1.1 DS-QS20.361-EN
All parameters are specified at 36V, 13.3A, 230Vac, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone +49 89 9278 0 Germany
1/23
POWER SUPPLY
■ AC 100-240V Wide-range Input
■ Efficiency up to 94.0%
■ Width only 82mm
■ 150% Peak Load Capability
■ Active Power Factor Correction, PFC
■ DC Input from 88 to 375Vdc
■ Short-term Operation from 60Vac to 300Vac
■ Full Power Between -25°C and +60°C
■ Negligibly Low Inrush Current
■ DC-OK Relay Contact
■ Quick-connect Spring-clamp Terminals
■ 3 Year Warranty
1. GENERAL DESCRIPTION
2. SHORT-FORM DATA
Output voltage DC 36V
Adjustment range 36-42V
Output current 13.3A continuous, 36V
20.0A for typ. 4s, 36V
Output power 480W continuous, 36V
720W for typ. 4s, 36V
Output ripple < 100mVpp 20Hz to 20MHz
Input voltage AC 100-240V ±15%
Mains frequency 50-60Hz ±6%
AC Input current 4.56 / 2.48A at 120 / 230Vac
Power factor 0.95 / 0.90 at 120 / 230Vac
AC Inrush current typ. 9 / 7A peak at 120 / 230Vac
DC Input voltage DC 110-300V
-
-20%/+25%
DC Input current 4.7 / 1.7A at 110 / 300Vdc
Efficiency 92.5 / 94.0% at 120 / 230Vac
Losses 38.9 / 30.6W at 120 / 230Vac
Temperature range -25°C to +70°C operational
Derating 12W/°C +60 to +70°C
Hold-up time typ. 32 / 51ms at 120 / 230Vac
The most outstanding features of this Dimension Q-
Series power supply are the high efficiency and the
small size, which are achieved by a synchronous
rectification and further novel design details.
With short-term power capability of 150% and built-
in large sized output capacitors, these features help
start motors, charge capacitors and absorb reverse
energy. A wide range input voltage design and a
negligible low input inrush current make installation
and usage simple. Diagnostics are easy due to the
DC-ok relay, a green DC-ok and a red overload LED.
Unique quick-connect spring-clamp terminals allow a
safe and fast installation. Many global approvals
make this unit suitable for nearly every situation.
QS20.241 QS20.481
QS20.244
QS10.241
QS20.361
Less
Power
QS20-Series
Related products
only 200-240V
Input, no PFC
36V Output
48V Output
Dimensions 82x124x127mm WxHxD
3. ORDER NUMBERS
4. MARKINGS
QS20.361
36-42V unit
Power Supply
Accessory ZM1.WALL Wall mount bracket
IND. CONT. EQ.
18WM
LISTED
UL 508
UL 60950-1
GL
Marine, pending
ZM15.SIDE Side mount bracket
YR2.DIODE Decoupling module
EMC, LVD
QS20.361
Q-Series
36V, 13A, SINGLE PHASE INPUT
May 2007 / Rev. 1.1 DS-QS20.361-EN
All parameters are specified at 36V, 13.3A, 230Vac, 25°C ambient and after a 5 minutes run-in time unless otherwise noted.
www.pulspower.com Phone +49 89 9278 0 Germany
2/23
INDEX PAGE
INDEX PAGE
1.
General Description ............................................1
2. Short-form Data ..................................................1
3. Order Numbers....................................................1
4. Markings..............................................................1
5. AC-Input...............................................................3
6. Input Inrush Current ...........................................4
7. DC-Input...............................................................4
8. Output .................................................................5
9. Hold-up Time.......................................................7
10. DC-OK Relay Contact ..........................................7
11. Efficiency and Power Losses................................8
12. Functional Diagram.............................................9
13. Front Side and User Elements.............................9
14. Terminals and Wiring........................................10
15. Reliability...........................................................10
16. EMC....................................................................11
17. Environment......................................................12
18. Protection Features ...........................................13
19. Safety .................................................................13
20. Dielectric Strength ............................................13
21. Approvals...........................................................14
22. Fulfilled Standards............................................ 14
23. Used Substances ............................................... 14
24. Physical Dimensions and Weight..................... 15
25. Installation and Operation Instructions .......... 15
26. Accessory........................................................... 16
27. Application Notes............................................. 17
27.1. Repetitive Pulse Loading........................ 17
27.2. Peak Current Capability ......................... 18
27.3. Back-feeding Loads ................................ 18
27.4. Charging of Batteries............................. 18
27.5. Output Circuit Breakers ......................... 19
27.6. External Input Protection....................... 20
27.7. Parallel Use to Increase Output Power . 20
27.8. Parallel Use for Redundancy.................. 20
27.9. Daisy-Chaining of Outputs..................... 21
27.10. Series Operation..................................... 21
27.11. Inductive and Capacitive Loads ............. 21
27.12. Operation on Two Phases...................... 22
27.13. Use in a Tightly Sealed Enclosure .......... 22
27.14. Mounting Orientations.......................... 23
INTENDED USE
The power supply shall only be installed and put into operation by qualified personnel.
This power supply is designed for installation in an enclosure and is intended for the general use, such as in industrial
control, office, communication, and instrumentation equipment. Do not use this device in aircraft, trains and nuclear
equipment, where malfunctioning of the power supply may cause severe personal injury or threaten human life.
TERMINOLOGY AND ABREVIATIONS
PE and symbol PE is the abbreviation for Protective Earth and has the same meaning as the symbol .
Earth, Ground This document uses the term “earth” which is the same as the U.S. term “ground”.
T.b.d. To be defined, value or description will follow later.
AC 230V A figure displayed with the AC or DC before the value represents a nominal voltage with
standard tolerances (usually ±20%) included.
E.g.: DC 12V describes a 12V battery disregarding whether it is full (13.7V) or flat (10V)
As long as not otherwise stated, AC 100V and AC 230V parameters are valid at 50Hz and AC
120V parameters are valid at 60Hz mains frequency.
230Vac A figure with the unit (Vac) at the end is a momentary figure without any additional
tolerances included.
DISCLAIMER
The information presented in this document is believed to be accurate and reliable and may change without notice.
Some parts of this unit are patent by PULS (US patent No 091662,063, Des. 424,529, …).
No part of this document may be reproduced or utilized in any form without permission in writing from the
publisher.
