User Manual

PT-TOOL-500

User Manual

HDMI 2.0 LCD Test Pattern Monitor

Model PT-TOOL-500

Designed in Germany

User Manual

PT-TOOL-500

The PT-TOOL-500 HDMI 2.0 LCD Test Pattern Monitor has been tested for conformance to safety regulations

and requirements, and has been certied for international use. However, like all electronic equipments, the PT-

TOOL-500 should be used with care. Please read and follow the safety instructions to protect yourself from possi-

ble injury and to minimize the risk of damage to the unit.

• Follow all instructions and warnings marked on this unit.

• Do not attempt to service this unit yourself, except where explained in this manual.

• Provide proper ventilation and air circulation and do not use near water.

• Keep objects that might damage the device and assure that the placement of this unit is on a stable surface.

• Use only the power adapter and power cords and connection cables designed for this unit.

• Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning.

Table of Contents

1. Safety and Notice 2 ..................................................................................

2. Introduction ....................................................................................... 3

3. Features ........................................................................................... 3

4. Package Contents 3 ..................................................................................

5. Specication ....................................................................................... 4

6. Connection Diagram 5 ................................................................................

7. Panel Description 6 ..................................................................................

8. Menu Operation 7 ....................................................................................

9. Generator ......................................................................................... 8

10. Receiver ........................................................................................... 9

11. HDCP Test 10 ........................................................................................

12. EDID Analysis 11 .....................................................................................

13. LOOP Test 12 .........................................................................................

14. Ethernet Control (Tcp/Ip) 13 ..........................................................................

15. Upgrade PT-TOOL-500 17 .............................................................................

16. EYE Pattern 20 .......................................................................................

17. Warranty .........................................................................................22
