For your safety, please do not watch videos on the monitor
when driving. Except professional repair-men, do not modify
the machine. lf the machine doesn‘t work, please consult
customer services or send the machine to local maintenance
WARNING: Please install this machine in the place where laws
and regulations allows it, our company take no responsibility for
illegal product installation.
The machine may appear darkscreen phenomenon when
starting up in the cold days, after power on and machine's
temperature gradually rises up, the display screen would
gradually return to normal.
● Multi-Camera & Monitor Video System Kit
● 7’’ -inch LCD Monitor Display Screen
● DVR Video Recording via SD Memory Card Slot
● Quad View Camera Selectable:
Choose Your Camera, View it On-Screen
● Compatible with Up to 4-Camera Video Input Support
● Universal Exterior Mount Rearview Backup Cameras
● Marine Grade Waterproof Rated Cams
● Night Vision Illumination
● Angle Adjustable Camera Lens
● Rugged & Heavy-Duty Construction
● Perfect for Large Production Vehicles
● DVR Recording: 4-Channel Video Signal
● VGA Resolution：720 x 480, PAL
● Recording speed: 50FPS (NTSC, 60FPS)
● Video System: PAL/NTSC Auto Switching
● Image Sensor: 1/4'' Color CMD
● LED Light: 12 IR LED Lights
● Eective Pixel: 580 x 540 Pixels
● Lens Angle: 170° Degree
● Marine Grade Rating: IP-69
● Camera Dimensions (W x H x D): 3.2'' x 3.2'' x 2.2'' inches
● Video System: PAL/NTSC Auto Switching
● Image Sensor: 1/4'' Color CMD
● LED Light: 18 IR LED Lights
● Eective Pixel: 580 x 540 Pixels
● Lens Angle: 170° Degree
● Marine Grade Rating: IP-69
● Camera Dimensions (W x H x D): 3.2'' x 3.2'' x 2.2'' inches
● LCD Screen: 7’’ -inch 16:9 Image
● Micro SD Card Support: Up to 32 GB *Not Included
● OSD Control: Color, Brightness, Contrast, Volume, Language
● Power Cord Length: 4-Pin Cable 49.2’ ft.
● Brightness: 350-400cd/m2
● Power Supply: DC 12-24V
● Monitor Dimensions (L x W x H ): 7.08’’ x 4.76’’ x 1.02’’ inches
This product adopts digital TFT color LCD of high denition
real-time monitoring, stored in SD card; built-in DVR recording
function with one single image or quad split images; supports
1way AV recording; built-in speaker and with remote control.
The installation is convenient and the connection is simple.
