Side 1/5

www.PyleUSA.com

www.PyleUSA.com www.PyleUSA.com

Status

POWER ON

RCA/AUX-IN

Bluetooth Connection

Active Speaker

BLUE

GREEN

RED

240mmx185mm

Dual 6.5’’ Waterproof-Rated

Wireless BT Streaming Marine Speakers

2-Way Coaxial Full Range Amplified Speaker System (600 Watt)

PLMRBT65B - PLMRBT65W

PLMRBT65B

PLMRBT65W

PLMRBT65B - PLMRBT65W

Installation Guide

LED INDICATOR

PLMRBT65B/PLMRBT65W Installation

Ways to Connect

• Bluetooth Connection

Connect the active speaker to a power source via a 12V cable.

Upon successful connection a red light will illuminate in active speaker. Recommend to

install a powerswitch and a 10amp fuse between the power and active speaker.

Switch on Bluetooth on your phone/tablet and select Bluetooth connection name ‘PyleUSA’.

Upon successful connection you will hear a connection tone and a blue light will illuminate

on active speaker.

Conversely upon Bluetooth disconnection, you will hear a disconnection tone and red light

illuminates on active speaker.

• Using included speaker wire to daisy Chain connection in between Active and Passive

speakers to build up the complete stereo system

• RCA Low level input allow user to have any AUX-IN option additionally while Bluetooth

feature is disconnected.

The active speaker stays at green light illumination while RCA AUX-IN. Vice Versa, while

Bluetooth is connected, the Bluetooth signal dominates the audio system.

• Optional ‘RCA Output’ allows user to wire and extend wider audio system.

The added pair is to receive audio signal via ‘Low Level Input’ and turn Bluetooth pin o on

added active speaker to avoid Bluetooth connection confusion. The way of daisy chain

connection in between active and passive speaker on added pair audio system is same as

above point 2 method. The active speaker on added speaker system stays at green light

illumination.

User can use ‘RCA Output’ and ‘Low Level Input’ to add up numerous pair speakers to build

up optimal audio system for dierent places.

“ Bluetooth

Pairing Tone”

1.“Turn on Bluetooth”

2.“Choose PyleUSA”

III

Active Speaker

RCA Output

to added

Audio System

Audio Signal

AUX-IN

Passive Speaker

PLMRBT65B-PLMRBT65W

Dual 6.5’’ Waterproof-Rated Wireless BT Streaming Marine Speakers

2-Way Coaxial Full Range Amplied Speaker System (600 Watt)

Features:

• Includes (2) 6.5'' Coaxial Speakers

(Active + Passive)

• Bluetooth Wireless Music

Streaming Ability

• Marine Grade Waterproof-Rated Construction

• Water-Resistant & Weatherproof Design

• Amplied Master Speaker with Built-in 2-Ch.

Digital Amplier

• 2-Way Active Powered Speaker System

• Impressive Wide-Bass Response

• Full Range Stereo Sound Reproduction

• Universal Standard OEM Replacement Size

• Ability to Connect External Devices

• RCA Audio Aux (L/R) Connectors

• Hassle-Free Easy Access Speaker Terminals

• Daisy-Chain Ability (Active to Passive Speaker)

as Stereo System

• Reinforced Surround with Dense Speaker Cone

• Rugged Machined Basket & Grill

with UV Resistant Housing

• Used For Car, Boat, O-Road

& Marine Vehicle Applications

Sizes / Dimensions:

• Total Diameter: 6.9’’ -inches

• Cut-Out Diameter: 6.75’’ –inches

• Total Depth: 3.97’’ -inches

Technical Specs:

• Power Output: 600 Watt MAX (300 Watt RMS)

• Marine Grade Rating: IP-X4

• Speaker Composition: Polypropylene Cone, Butyl Rubber Surround

• Voice Coil: 1.0'', Aluminum (x2)

• Tweeters: 0.5'', Neodymium Dome (x2)

• Impedance: 4 Ohm

• Sensitivity: 90 dB

• Circuit Magnet: 20 oz.

• Frequency Response: 85Hz-20kHz

• Power Supply: DC 12V

• Active Speaker Weight: 1.56 lbs.

• Passive Speaker Weight: 1.34 lbs.

• Sold as: Kit

What’s in the Box:

• (1) 6.5’’ -inch Active Speaker

• (1) 6.5’’ -inch Passive Speaker

• (2) Speaker Connection Wires, 9.8’ ft.

• Cut-Out Template

• Mounting Screws

Bluetooth Connectivity:

• Receiver Built-into Active /

Master Speaker

• Allows Instant Wireless Music Streaming

• Simple Setup & Hassle-Free Pairing Ability

• Works with All of Today’s Latest Devices

(Smartphones, Tablets, Laptops, PC)

• Bluetooth Version: 4.2

• Bluetooth Network Name: ‘PyleUSA’

• Wireless Range: 30’+ ft.

• Active Speaker Mounting Depth: 3.1’’ -inches

• Passive Speaker Mounting Depth: 2.3’’ -inches
