READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT.
RETAIN THIS OWNER’S MANUAL FOR FUTURE REFERENCE.
• Pro Audio PowerSport Speakers
• Amplied (Active + Passive) Speaker System
• Bluetooth Wireless Music Streaming Ability
• Marine Grade Waterproof Rated Construction
• Weatherproof & Water-Resistant Housing
• 2-Way Full Range Stereo Sound Reproduction
• Built-in Digital Sound Processing Amplier
• Compact Size & High-Powered Output
• Impressive Bass Response
• Integrated Power & Wiring Harness
• Connect & Stream Audio from External Devices
• Sleek Design, Machine Molded Speaker Cabinet Housing)
• Rugged, Universal Mount Bracket Design for Roll-Bar / Roll-Cage
• Built-Into Amplier of Main / Active Speaker
• Used for O-Road Outdoor Vehicles: ATV, UTV, 4x4, Jeeps, Marine Watercraft
• *Bluetooth Receiver Module
Bluetooth Wireless Streaming:
• Simple & Hassle-Free Pairing
• Instant Wireless Audio Streaming Ability
• Works with All of Today’s Latest Devices Smartphones, Tablets, Laptops, etc.
• Bluetooth Version: V5.0
• Bluetooth Network Name:‘PyleUSA’
• Wireless Range: 30+ ft.
• (1) Active O-Road Speaker
• (1) Passive O-Road Speaker
• (1) 2.5M Speaker Wire Between Active and Passive Speakers
• (6) Rubber Pads 4.53'' x 1.18'' x 0.12'' -inches
• Speaker Power: 900 Watt MAX
• Amp Power: 2 x 450 Watt MAX @ 4 Ohms (2 x 225 Watt RMS)
• Amp Type: 2-Channel, Class D
• Bridged Sound System: (2) x 4.0'' Woofers + (2) x 1'' Tweeters
• Marine Grade Waterproof Rating: IP-X5
• Speaker Type: Polypropylene Cone, Butyl Rubber Surround (x2)
• Tweeter Type: Neodymium Dome (x2)
• Frequency Response: 105Hz-20kHz
• Magnet Type: 30 oz. Circuit
• Mid-Woofer Voice Coil Type: 1.0'', KSV
• Sensitivity: 90 dB +/- 2 dB @ 1M/1W
• Channel Separation: >65dB
• Amp Freq. Response: 20Hz- 30kHz
• Universal Mounting Brackets Roll-Bar / Roll-Cage Diameter: 1.5” ~ 2.0” -inches
• Speaker Dimensions (L x W x H): 5.5” x 8.0” x 7.4” -inches, with Bracket (Each)
California Prop 65 Warning
This product contains Di (2-ethylhexyl) phthalate (DEHP) which
is known to the state of California to cause cancer birth
defects and other reproductive harm. Do not ingest.
For more info go to: www.P65warnings.ca.gov
