Side 1/3

Current draw—120 VAC Page 1 of 3

February 2016

Idle

Current

draw at

idle or

with very

low signal

level.

8Ω 4Ω 2Ω 8Ω 4Ω 2Ω 8Ω 4Ω 2Ω25V-70V-100V 25V-70V-100V 25V-70V-100V

Model Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes

CX302 0.9 3.5 5.4 8.6 na 5.1 8.7 12.9 na 8.4 13.9 22.2 na

CX502 0.9 5.1 8.0 11.9 na 7.6 12.1 18.2 na 12.6 21.2 32.2 na

CX702 0.8 5.0 7.7 11.5 na 8.3 13.2 19.8 na 15.9 26.7 41.1 na

CX902 0.9 5.9 9.2 13.2 na 10.5 16.8 24.6 na 20.4 34.3 52.3 na

CX1102 0.9 7.6 11.6 16.6 na 13.1 20.3 30.4 na 25.1 40.6 58.6 na

CX302V 1.0 nr nr nr 5.6 nr nr nr 8.0 nr nr nr 12.0

CX602V 0.9 8.7 nr nr 8.7 13.0 nr nr 13.0 20.5 nr nr 20.5

CX1202V 1.0 7.7 11.9 nr 11.9 12.5 19.2 nr 19.2 25.2 38.7 nr 38.7

CX254 0.7 5.8 9.2 14.3 na 8.8 14.2 21.7 na 14.8 24.0 38.2 na

CX404 0.7 8.1 12.4 nr na 12.2 19.3 nr na 21.7 33.4 nr na

CX204V 0.8 nr nr nr 8.3 nr nr nr 12.7 nr nr nr 20.1

CX168 0.6 6.4 10.0 nr na 9.9 15.1 nr na 16.5 26.0 nr na

CX108V 0.6 nr nr nr 6.4 nr nr nr 10.2 nr nr nr 15.6

CX Series Amplifier Current Draw—120 VAC

Current draw at 1/8 of full power is measured

with pink noise as a signal. It approximates

operating with music or voice with light clipping

and repesents the amplifier's typical "clean"

maximum level, without audible clipping. Use

these figures for typical maximum level

operation.

Current draw at 1/3 of full power is measured

with pink noise as a signal. It approximates

operating with music or voice with very heavy

clipping and a very compressed dynamic range.

Current draw at full power is measured with a 1

kHz sine wave. However, it does not represent

any real-world operating condition.

"Current draw" is the amount of AC current an amplifier demands while it is operating.

Measurements are provided for various loads at idle, 1/8 of average full power, 1/3 of average full

power, and full power, with all channels driven simultaneously. The figures shown on this sheet are

for 120 VAC usage; for 230- and 100-volt operation, see the companion sheets. For typical usage,

use the idle and 1/8 power figures.

Where an asterisk (*) appears, the data was not available at press time. The designations "na" and

"nr" respectively mean "not applicable" to the particular amplifier model and "not rated" for the

particular load impedance. Bridged mono into 8 ohms is equivalent to 4 ohms per channel; into 4

ohms is equivalent to 2 ohms per channel.

1/8 Power

1/3 Power

Full Power

Load per channel ->

Current draw—230 VAC Page 2 of 3

February 2016

Idle

Current

draw at

idle or

with very

low signal

level.

8Ω 4Ω 2Ω 8Ω 4Ω 2Ω 8Ω 4Ω 2Ω25V-70V-100V 25V-70V-100V 25V-70V-100V

Model Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes Amperes

CX302 0.5 1.8 2.7 4.3 na 2.6 4.4 6.5 na 4.2 7.0 11.1 na

CX502 0.5 2.6 4.0 6.0 na 3.8 6.1 9.1 na 6.3 10.6 16.1 na

CX702 0.4 2.5 3.9 5.8 na 4.2 6.6 9.9 na 8.0 13.4 20.6 na

CX902 0.5 3.0 4.6 6.6 na 5.3 8.4 12.3 na 10.2 17.2 26.2 na

CX1102 0.5 3.8 5.8 8.3 na 6.6 10.2 15.2 na 12.6 20.3 29.3 na

CX302V 0.5 nr nr nr 2.8 nr nr nr 4.0 nr nr nr 6.0

CX602V 0.5 4.4 nr nr 4.4 6.5 nr nr 6.5 10.3 nr nr 10.3

CX1202V 0.5 3.9 6.0 nr 6.0 6.3 9.6 nr 9.6 12.6 19.4 nr 19.4

CX254 0.4 2.9 4.6 7.2 na 4.4 7.1 10.9 na 7.4 12.0 19.1 na

CX404 0.4 4.1 6.2 nr na 6.1 9.7 nr na 10.9 16.7 nr na

CX204V 0.4 nr nr nr 4.2 nr nr nr 6.4 nr nr nr 10.1

CX168 0.3 3.2 5.0 nr na 5.0 7.6 nr na 8.3 13.0 nr na

CX108V 0.3 nr nr nr 3.2 nr nr nr 5.1 nr nr nr 7.8

Load per channel ->

"Current draw" is the amount of AC current an amplifier demands while it is operating.

Measurements are provided for various loads at idle, 1/8 of average full power, 1/3 of average full

power, and full power, with all channels driven simultaneously. The figures shown on this sheet are

for 230 VAC usage; for 120- and 100-volt operation, see the companion sheets. For typical usage,

use the idle and 1/8 power figures.

Where an asterisk (*) appears, the data was not available at press time. The designations "na" and

"nr" respectively mean "not applicable" to the particular amplifier model and "not rated" for the

particular load impedance. Bridged mono into 8 ohms is equivalent to 4 ohms per channel; into 4

ohms is equivalent to 2 ohms per channel.

CX Series Amplifier Current Draw—230 VAC

Current draw at 1/8 of full power is measured

with pink noise as a signal. It approximates

operating with music or voice with light clipping

and repesents the amplifier's typical "clean"

maximum level, without audible clipping. Use

these figures for typical maximum level

operation.

Current draw at 1/3 of full power is measured

with pink noise as a signal. It approximates

operating with music or voice with very heavy

clipping and a very compressed dynamic range.

Current draw at full power is measured with a 1

kHz sine wave. However, it does not represent

any real-world operating condition.

1/8 Power

1/3 Power

Full Power
