RAM_OCS v3 Quick Guide
INSTALLATION AND FIRST STEPS
Welcome to RAM OCS, the Online Control System for RAM Audio V/W Series DSP amplifiers. By using it you can control
and monitor the DSP unit of a V/W amplifier through an Ethernet network or a USB connection, in a Windows system.
To start, install the software in a Windows system (XP, Vista, 7, 8 or 10) and connect the amplifiers to the Ethernet network or
the USB port. Each amplifier is programmed from factory with a unique IP number inside the range 192.168.xxx.xxx. To de-
tect initially the amplifiers you have to work inside this range. Change the computer IP to 192.168.0.10 for example, and use
Execute the RAM OCS software using the Shortcut created in the desktop and start scanning the network. To do that, click in
the loupe (1) icon placed near to the left top side of the window. The system has to detect all amplifiers you have connected
in your network or connected using the USB port. To open an amplifier you have to do a double click on the amplifier showed
in the devices tree (2).
Create a virtual amplifier: if you do not have any amplifier connected to the system, you can add an offline amplifier clicking
with the right mouse button on the “Amplifiers” section of the devices tree (3), and selecting the Add device option.
To obtain some help for the different button functions, you can maintain the cursor over a button for two seconds to show a
hint which can help you.
The elements of the main screen are as follows:
Project Menu Tab
Amp Menu Tab
Devices Tree:
show a list of all
amplifiers detected
in your Ethernet
network or USB
connection
Amp Information:
show the model,
serial number,
name, IP address
and firmware ver-
sion of the selec-
ted amplifier
Amps Scan - Tree
management icons
Poject/Amp Menu
Icons
Frequency response graphic window
Amplifier configuration main window
3
2
1
1
