BB 22

BALANCE BUDDY

Recycle cardboard and paper.

Cartons et papier à recycler.

Contents

Features 2

General Description 2

BB 22 Application Information 3

BB 22 Specications 4

Designator Drawing 5

Block Diagram 6

Schematic 7

Sound System Interconnection 8

Warranty 24

11259

BB 22

BALANCE BUDDY

Data Sheet / Manual

General Description

e Rane BB 22 Balance Buddy is a handy professional-grade tool used to

provide isolation for and convert unbalanced -10 dBV consumer level RCA

outputs up to balanced +4 dBu professional XLR inputs. e BB 22 converts

one pair from -10 dBV to +4 dBu. ere are two male XLR connectors and

two RCA jacks.

Unbalanced lines should always be kept under 10 feet (3 meters) to pre-

vent undesirable eects such as hum and noise. e BB 22 allows conversion

to balanced lines that can be run across a studio or a house without loss of

signal quality. For instance, a BB 22 may be mounted to the back of a jukebox

converting its unbalanced outputs to balanced lines, feeding an amplier in

another room.

Signal-to-noise performance is perfectly preserved using the BB 22, since

it uses only passive transformers to convert signal levels. It adds no additional

noise whatsoever. Use of professional quality nickel core (“80” Ni) transform-

ers guarantee low distortion, wide bandwidth and high signal level handling

capability.

e BB 22’s isolation transformers provide a quick and aordable answer

to most jobs requiring signal level conversion and output balancing.

WEAR PARTS: is product contains no wear parts.

Features

• 2 Channels of -10 dBV (RCA) to +4 dBu (XLR) Conversion

• Nickel Core “80” Ni Transformers — Wide Bandwidth and Low Distortion

• +24 dBu Maximum Levels
